Bosch EX27 Manuale utente

EX27/EX27N/EX27D

All-Weather Cameras

INSTALLATION INSTRUCTIONS

MAN-27/27N/27D-01

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep this instruction.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with manufacturer instructions.

8. Do not install near any heat sources such as

radiators, heat registers, stoves or other

apparatus (including amplifiers) that produce

heat.

9. Do not defeat the safety purpose of the polarized

or grounding-type plug. A polarized plug has two

blades with one wider than the other. A

grounding type plug has two blades and a third

grounding prong. The wide blade or the third

prong is provided for your safety. If the provided

plug does not fit into your outlet, consult an

electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or

pinched particularly at plugs, convenience

receptacles, and the power where they exit from

the apparatus.

11. Only use attachments/accessories specified by

the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or

when unused for long periods of time.

14. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has

been damaged in a way, such as power-supply

cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

IMPORTANT

For best results, please read this Instruction Booklet prior

to installing the EX27 camera.

This installation should be made by a qualified service

person and conform to all local codes.

Bosch Security Systems will not be responsible for

injuries or damages resulting from the improper installation

or use of any camera sold by Bosch Security Systems,

their agents, distributors or dealers.

EU Directives covered by this declaration:

72/9/EC Low Voltage Directives

89/336/EEC Electromagnetic Compatibility Directive

NOTE: This equipment has been tested and found to

comply with the limits for a digital device, pursuant to part

15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. As part of its’ normal operation this

device can generate radio frequency energy and if not

installed and used in accordance with the installation

manual may cause interference to radio communications.

However, there is no guarantee that interference will not

occur on a particular installation. If the device does cause

interference to radio or television reception the user is

encouraged to try to correct the interference by one or

more of the following measures:

1) Fit Ferrite beads on all cable to and from the power

supply box, within the box walls.

2) Route the composite cable between the camera and the

power supply in steel conduit piping over the entire run of

the cable up to and including connection to a deep conduit

base fitted under the camera and a conduit fitting adaptor in

the wall of the PSU box.

3) Contact a Bosch Service Center for further advice.

INDEX – EX27/27N/EX27D

1. DESCRIPTION....................................................... 7

2. UNPACKING .......................................................... 8

3. EX27/EX27N MECHANICAL SPECIFICATIONS ... 9

4. EX27D MECHANICAL SPECIFICATIONS........... 10

5. INITIAL PREPARATIONS .................................... 11

6. GUIDELINES........................................................ 12

7. VOLTAGE INPUT................................................. 13

8. CAMERA AND LENS ACCESS ........................... 14

9. PHOTOCELL ADJUSTMENTS ............................ 17

10. LENS ADJUSTMENTS......................................... 19

11. OSD MENU SYSTEM .......................................... 21

12. TROUBLESHOOTING GUIDE ............................. 40

13. GENERAL SPECIFICATIONS ............................. 43

1. DESCRIPTION

The EX27 camera is an all-weather system that

includes all of the best features of a “plug and

play” camera without compromise to CCD optics

and lens quality.

Full size vari-focal auto-iris lenses are integrated

as standard equipment for simplified

installations. High resolution extended day/night

CCDs ensure that a picture is received under

extreme outdoor lighting conditions.

The EX27 is rugged, compact, power protected,

weather sealed, easily installed and designed for

use in industrial applications.

A voltage regulator circuit automatically allows

for 12VDC or 24VAC operation without any

wiring changes. Its wider voltage range also

provides protection from voltage surge, transient

spikes, and reverse voltage.

The EX27 is available in several models to meet

individual requirements or specific needs.

2. UNPACKING

Care should be taken when unpacking. Check the

parts list and confirm all items have been located.

Inspect the equipment thoroughly to ensure nothing

was damaged in transit.

Contact a Bosch Service Center if a problem is

noted, see the rear page of this booklet for contact

numbers.

PARTS LIST (items supplied with unit)

- EX27/EX27N/EX27D camera assembly

- Installation Instructions

- Universal type pan/tilt mounting bracket with

¼ - 20 captive nut

-3mm Allen key

ITEMS REQUIRED FOR INSTALLATION

(not supplied with unit)

- Hardware for camera mounting (bolts, etc.)

- Mounting tools and wrenches

- Optional mounting brackets (contact

Bosch for details and prices)

3. EX27/EX27N MECHANICAL

SPECIFICATIONS

4. EX27D MECHANICAL SPECIFICATIONS
