Buffalo TS-XL Manuale utente
TeraStation User Manual
TS-XL/R5, TS-RXL/R5, and TS-WXL/R1 models
www.buffalotech.com v2.86
2
Introduction
Congratulations on your new TeraStation! The TeraStation is a powerful le server that’s
as easy to use as a hard drive. With its straightforward Web Admin Tool, anyone can
easily congure the TeraStation’s settings. You don’t even necessarily need to congure it
at all; right out of the box it’s ready to be plugged in and put to work. But the TeraStation
remains a fast, reliable, Linux-based server, with multiple hard drives that may be
congured in RAID arrays. This user manual is intended to assist you in conguring your
new TeraStation.
Because we’re constantly updating our product, the images and text in this manual may
vary slightly from the images and text displayed by your TeraStation. These changes
are minor and should not affect the ease of setup adversely. As time passes, future user
interfaces, updated software, and later versions of this manual may be freely available for
download at our web site: http://www.buffalotech.com.
3
Introduction
Diagrams and Layout 4
TS-XL/R5 4
TS-WXL/R1 7
TS-RXL/R5 10
Power Mode 13
Using your TeraStation
Using your TeraStation with a PC 14
Using your TeraStation with a Mac 17
Finding your TeraStation’s IP address 20
Settings and Conguration
Web Admin Tool 21
Users/Groups
Adding Users 24
Adding Groups 27
Disk Quotas 28
Network
Settings 29
Port Trunking 30
Workgroup/Domain 32
NFS 34
DFS 35
System
Settings 36
Disks
RAID Conguration 37
Hot Spare 39
Hot Swap 40
USB Hard Drives 41
Formatting Hard Drives 42
Encryption 42
Adding Shares 43
Mapping Additional Shares 46
TeraSearch 48
Maintenance 51
Replication 52
Backup Jobs 53
Initialization 54
NS-SHFT 57
EXT3 Reader 59
UPS 60
Extensions
Sleep Timer 61
Print Server 62
Time Machine 66
DLNA Media Server 71
Bittorrent Client 73
Direct Copy 75
Remote Access
WebAccess 76
FTP 81
Troubleshooting
Error codes 82
Troubleshooting Multiple Shares 84
Replacing a Hard Drive 86
Appendix
Specications 88
Factory Defaults 89
Contact Information 90
GPL Information 91
4
TeraStation Quick Setup
Front Panel (TS-XL/R5)
Power On/Off
LCD Display
Door Lock
Display Button
Status LEDs
Function Button
5
TeraStation Quick Setup
Open Front Panel (TS-XL/R5)
Diagnostic Port
(Buffalo factory use
only)
Drive Lock
(Press left to
open drive)
Drive LED
Init Button
6
Serial Port for UPS
TeraStation Quick Setup
Rear Panel (TS-XL/R5)
USB
Ethernet 1
Ethernet 2
Power Connector
Security Mount
Power Mode Auto
Manual
7
TeraStation Quick Setup
Front Panel (TS-WXL/R1)
Power On/Off
LCD Display
Door Lock
Display Button
Status LEDs
Function Button
8
TeraStation Quick Setup
Open Front Panel (TS-WXL/R1)
Diagnostic Port
(Buffalo factory use
only)
Drive Lock
(Press left to
open drive)
Drive LED
Init Button
9
Serial Port
for UPS
TeraStation Quick Setup
Rear Panel (TS-WXL/R1)
USB Ports
Ethernet 1
Ethernet 2
Power
Connector
Security
Mount
Power Mode
Auto Manual
10
TeraStation Quick Setup
Front Panel (TS-RXL/R5)
Power On/Off
LCD Display Door Lock
Display Button
Status LEDs
UID LED On/Off
