Bushnell CELLUCORE 24 Manuale utente

CELLUCORE 24 MODEL # 119906A (AT&T) / 119906V (VERIZON)

INSTRUCTION MANUAL

CELLUCORE 24 TRAIL CAMERA

WELCOME

Welcome to your Bushnell Trail Camera! This manual has all

the instructions you need to set up your camera and your

account, plus quick answers to your questions.

If your camera does not seem to be functioning properly

or if you are having image quality issues, please check the

Troubleshooting Tips section.

If your problem continues after trying the solutions in

Troubleshooting Tips, please call Bushnell Customer Service

at (800) 423-3537. In Canada, call (800) 361-5702.

Note: This Bushnell trail camera model is not designed

or intended for operation or sale outside of the United

States.

TABLE OF CONTENTS

Camera Overview 4

Viewscreen Indicator Guide 6

Quick Start Guide 6

Settings Menu 9

Mounting & Positioning 14

Using An External Power Source 16

Frequently Asked Questions 16

Technical Specifications 18

Two-Year Limited Warranty 19

Lens

Control Panel

Cover

DC In

(For optional solar panel accessory)

Motion

Indicator

Antenna

LED IR Flash

Light Sensor

Latch

CAMERA OVERVIEW

PIR Sensor

Ok Button

Power On/Off

Down Menu

Left

Right

View

Screen

Lock Hole

Battery Tray

SD Card Slot

SD Card not included

Battery

Panel Door

VIEWSCREEN INDICATORS

1. Download the free Bushnell Trail

Camera app on your smartphone from

the App Store (iPhone®) or Google

Play® (Android®).

2. Open the app, then sign in or create

a new account.

QUICK START GUIDE

Current Mode Camera signal

Time Stamp

Battery Life Countdown Timer

SD Card

Inserted


Capacity Left

Current Images

Captured

Current Image Resolution

(Megapixels)

3. Log in and click the Camera icon

at the bottom of the screen, then

click “+” to add a new camera. Scan

the QR code on the veiw screen of

your Cellucore 24 or manually or

enter its serial # to associate this

camera with your account.

4. Install 12 AA batteries (Energizer®

lithium batteries are recommended.

Alkaline batteries may be used

but battery life will be shorter.

Rechargeable batteries are not

recommended). Be sure to position

the batteries for correct polarity

(+/-) when installing.

5. Install a new SD card, up to 32GB.

High speed cards (class 6 or higher)

are recommended if you plan to

record video clips.

6. At the location where you

will place the camera, move the

power switch to the On position.

The camera’s default settings

were chosen for typical usage as

a scouting camera for hunters:

photo mode at 2MP resolution,

with a 10 second interval between

photos, and “Medium” LED flash

power output. These settings may

x12

onoff

Your wireless camera is now ready to use. You can now

utilize the mobile application or management website to

review images, change camera settings, monitor battery life

and other functions of the camera.

Android® and Google Play® are registered trademarks of Google Inc. iPhone® is a

registered trademark of Apple, Inc.

be easily changed to suit your

individual preferences or application

(for example, if you would rather

capture videos, or photos at a

different resolution, spaced further

apart), using the app on your

smartphone or home computer.

7. Prior to closing the camera,

ensure the camera has acquired

cellular signal. Lower signal strength

can cause interruptions in service

and shorten battery life. Mount the

camera using the provided tree

strap or 1/4”-20 mounting socket. A

leveling arm to adjust the camera’s

angle is provided near the lower rear

of the camera.

Camera signal

(Check your app for these settings)

SETTINGS MENU

Time and Date

Sets the hour (24-hr format only,

“00”=midnight, “12”=noon), minute,

year, month, and date.

Mode

Selects the format your camera will

record in.

Camera: For photos only.

Hybrid: A photo (multiple photos, if

NUM PICS is set >1) followed by a

video clip will be captured for each PIR

trigger event.

Image Size

Chooses the image resolution and

size.

Note: Larger sizes mean higher

image resolutions that take up more

space on the SD card. Medium is

the recommended default for good

resolution and smaller size.

Capture Number

Selects how many photos are taken

in sequence per trigger. This setting

affects photos taken in Camera,

Hybrid, and Field Scan mode.

Camera Name

Allows you to enter a name for your

camera that will appear on the image

time stamp. Press the OK button to

choose “Input” and go to the name

input screen. If necessary, select

the arrow in the upper right of the

keyboard to erase the current camera

name, then enter the new name using

the arrow buttons and keyboard.

Press the OK button to select a letter.

Press MENU to save the name to

memory.

Video Size

Selects video resolution.

1920x1080: Maximum resolution,

takes up the most space on your SD

card. 1280x720: The recommended

default resolution, clear resolution

without filling up your SD too fast.

640x360: Lowest resolution. Good for

videos when resolution is not critical.

Note: We recommend SanDisk® SDHC

class 10 or higher.

Video Length

Sets length per video clip. 10 seconds

is the recommended default. Press OK

to see other options.

Nighttime limit of 15 seconds when

Illumination Mode = “Long Range”. The

“Dynamic” setting provides a variable

video length, based on animal activity

within PIR range and your Interval and

Illumination Mode settings.
