INSTRUCTION MANUAL

●This manual is for the EOS-1D X installed with firmware

version 2.0.0 or later.

●The “Software Start Guide” is included at the end of this

manual.

INSTRUCTION

MANUAL

ENGLISH

CEL-SS4YA214 © CANON INC. 2013 PRINTED IN THE EU

The lenses and accessories mentioned in this Instruction Manual are current as of

November 2013. For information on the camera’s compatibility with any lenses

and accessories introduced after this date, contact any Canon Service Center.

CANON INC.

30-2 Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan

Europe, Africa & Middle East

CANON EUROPA N.V.

PO Box 2262, 1180 EG Amstelveen, The Netherlands

For your local Canon office, please refer to your warranty card or to www.canon-europe.com/Support

The product and associated warranty are provided in European countries by Canon Europa N.V.

The EOS-1D X is the top-of-the-line EOS high-performance digital

single-lens reflex camera featuring a full-frame (approx. 36 x 24 mm)

CMOS sensor with approx. 18.1 effective megapixels, Dual DIGIC 5+,

normal ISO speed range of ISO 100 - 51200, approx. 100% viewfinder

coverage, high-precision and high-speed 61-point AF, approx. 12 fps

high-speed continuous shooting, RGB metering sensor, 8.1 cm (3.2-in.)

LCD monitor, Live View shooting, and Full High-Definition (Full HD)

movie shooting.

The camera is highly responsive to any shooting situation, provides

many features for demanding shots, is highly reliable even in harsh

environments, and is compatible with a wide range of accessories that

expand shooting possibilities.

Refer to This Manual while Using the Camera to Further

Familiarize Yourself with the Camera

With a digital camera, you can immediately view the image you have

captured. While reading this manual, take a few test shots and see how

they come out. You can then better understand the camera.

To avoid botched pictures and accidents, first read the “Safety

Warnings” (p.413, 414) and “Handling Precautions” (p.14, 15).

Testing the Camera Before Use and Liability

After shooting, play images back and check whether they have been

properly recorded. If the camera or memory card is faulty and the

images cannot be recorded or downloaded to a computer, Canon

cannot be held liable for any loss or inconvenience caused.

Copyrights

images of people and certain subjects for anything but private

enjoyment. Also be aware that certain public performances, exhibitions,

etc., may prohibit photography even for private enjoyment.

CF Card

In this manual, “card” refers to a CF card. The CF card (for recording

images) is not included. Please purchase it separately.

Introduction

Before starting, check that all the following items have been included

with your camera. If anything is missing, contact your dealer.

* Attach Eyecup Eg to the viewfinder eyepiece.

* Be careful not to lose any of the above items.

Item Check List

Battery Pack

LP-E4N

(with protective cover)

Battery Charger

LC-E4N

(with protective covers)

Interface Cable

IFC-200U

Stereo AV Cable

AVC-DC400ST

EOS Solution Disk

(Software)

EOS Software Instruction

Manuals Disk

Camera

(with body cap and

battery compartment cap)

EOSSoftware Instruction Manuals Disk XXX

XXXXX

CEL-XXXXXX

EOSSolution Disk XXX

CEL-XXXXXX

WindowsXXX XXX

MacOS X XXX XXX

XXXXX

Wide Strap L7

Eyecup Eg

Cable Protector

Wired LAN

To set up a wired LAN using the Ethernet RJ-45 terminal (p.21), refer to the separate

“Wired LAN Instruction Manual” on the EOS Wired LAN Instruction Manuals Disk.

Software Instruction Manuals

The Software Instruction Manuals are included on the CD-ROM as

PDF files. See page 417 for instructions on using the EOS Software

Instruction Manuals disk.

EOSSoftware Instruction Manuals Disk XXX

XXXXX

CEL-XXXXXX

(1) Camera Instruction Manual

(this booklet)

(2) Pocket Guide

(1) (2)

EOS Wired LAN

Instruction Manuals Disk

CEL-XXXXXX

Icons in this Manual

<6> : Indicates the Main Dial.

<5> : Indicates the Quick Control Dial.

<9> : Indicates the Multi-controller.

<0> : Indicates the Setting button.

0, 9, 7, 8: Indicates that the corresponding function remains

active for 4 sec., 6 sec., 10 sec., or 16 sec.

respectively after you let go of the button.

* In this manual, the icons and markings indicating the camera’s buttons, dials,

and settings correspond to the icons and markings on the camera and on the

LCD monitor.

3: Indicates a function that can be changed by pressing the

<M> button and changing the setting.

(p.**) : Reference page numbers for more information.

: Warning to prevent shooting problems.

: Supplemental information.

: Tips or advice for better shooting.

: Problem-solving advice.

Basic Assumptions

All operations explained in this manual assume that the power switch

is already set to <1> (p.38).

It is assumed that all the menu settings and Custom Functions are

set to their defaults.

The illustrations in this manual show the camera attached with the

EF50mm f/1.4 USM lens as an example.

Conventions Used in this Manual

Chapters

Introduction 2

Getting Started 29

Setting the AF and Drive Modes 65

Image Settings 119

Exposure Control 169

Flash Photography 195

Shooting with the LCD Monitor (Live View Shooting) 205

Shooting Movies 225

Image Playback 251

Post-Processing Images 291

Sensor Cleaning 299

Printing Images and Transferring Images to a Computer

305

Customizing the Camera 323

Reference 365

Software Start Guide 417

Introduction 2

Item Check List................................................................................. 3

Conventions Used in this Manual..................................................... 4

Chapters........................................................................................... 5

Index to Features ........................................................................... 12

Handling Precautions ..................................................................... 14

Quick Start Guide ........................................................................... 16

Nomenclature ................................................................................. 18

Getting Started 29

Charging the Battery ...................................................................... 30

Installing and Removing the Battery............................................... 34

Installing and Removing the Card .................................................. 35

Turning on the Power ..................................................................... 38

Setting the Date, Time, and Zone .................................................. 40

Selecting the Interface Language................................................... 42

Attaching and Detaching a Lens .................................................... 43

Basic Operation.............................................................................. 45

QQuick Control for Shooting Functions ....................................... 51

3Menu Operations.................................................................. 53

Before You Start............................................................................. 55

Formatting the Card..................................................................... 55

Setting the Power-off Time/Auto Power Off................................. 57

Setting the Image Review Time................................................... 57

Reverting the Camera to the Default Settings ............................. 58

Displaying the Grid and Electronic Level........................................ 61

Feature Guide............................................................................ 63

Contents

Setting the AF and Drive Modes 65

2: Selecting the AF Mode............................................................66

SSelecting the AF Area...............................................................69

AF Area Selection Modes ...............................................................73

About the AF Sensor.......................................................................76

Lenses and Usable AF Points.........................................................77

Selecting AI Servo AF Characteristics (For a Subject) ...................85

Customizing AF Functions ..............................................................94

Fine Adjustment of AF’s Point of Focus (AF Microadjustment) ....107

When Autofocus Fails ...................................................................113

MF: Manual Focusing.................................................................114

R: Selecting the Drive Mode...................................................115

jUsing the Self-timer .................................................................117

Image Settings 119

Selecting the Card for Recording and Playback ...........................120

Setting the Image-Recording Quality ............................................123

i: Setting the ISO Speed .........................................................130

Selecting a Picture Style ............................................................... 135

Customizing a Picture Style ..........................................................138

Registering a Picture Style............................................................141

B: Setting the White Balance....................................................143

OCustom White Balance...........................................................144

PSetting the Color Temperature...............................................149

uWhite Balance Correction ........................................................150

Correcting the Brightness and Contrast Automatically (Auto Lighting Optimizer)

..152

Noise Reduction Settings..............................................................153

Highlight Tone Priority...................................................................156

Lens Peripheral Illumination / Chromatic Aberration Correction ... 157

Contents

Creating and Selecting a Folder................................................... 160

Changing the File Name............................................................... 162

File Numbering Methods .............................................................. 164

Setting Copyright Information....................................................... 166

Setting the Color Space ............................................................... 168

Exposure Control 169

d: Program AE............................................................................. 170

s: Shutter-Priority AE ................................................................ 173

f: Aperture-Priority AE ............................................................. 175

Depth of Field Preview............................................................... 176

a: Manual Exposure ................................................................... 177

qSelecting the Metering Mode.................................................. 179

OSetting Exposure Compensation............................................. 181

hAuto Exposure Bracketing (AEB)........................................... 182

AAE Lock................................................................................... 183

Bulb Exposures ............................................................................ 184

PMultiple Exposures ................................................................. 186

2Mirror Lockup ........................................................................ 193

Flash Photography 195

DFlash Photography ................................................................... 196

Setting the Flash .......................................................................... 199

Shooting with the LCD Monitor (Live View Shooting) 205

APreparing for Live View Shooting........................................... 206

AShooting with the LCD Monitor .............................................. 207

Shooting Function Settings .......................................................... 211

Menu Function Settings................................................................ 212

Contents

Using AF to Focus ........................................................................215

Focusing Manually ........................................................................222

Shooting Movies 225

kPreparing to Shoot Movies .....................................................226

kShooting Movies .....................................................................227

Autoexposure Shooting..............................................................227

Shutter-priority AE......................................................................228

Aperture-priority AE....................................................................229

Manual Exposure Shooting ........................................................231

Shooting Still Photos ..................................................................236

Shooting Function Settings ...........................................................238

Setting the Movie-Recording Size.................................................239

Setting the Sound Recording ........................................................242

Silent Control ................................................................................244

Setting the Time Code ..................................................................245

Menu Function Settings ................................................................247

Image Playback 251

xImage Playback ......................................................................252

B: Shooting Information Display ..............................................254

HISearching for Images Quickly.............................................257

uMagnified View ........................................................................259

bRotating the Image ..................................................................261

Setting Ratings..............................................................................262

QQuick Control During Playback ...............................................264

kEnjoying Movies......................................................................266

kPlaying Movies........................................................................268

XEditing the Movie’s First and Last Scenes...............................270

Slide Show (Auto Playback)..........................................................272

Contents

Viewing the Images on TV ........................................................... 275

JProtecting Images................................................................... 279

KRecording and Playing Voice Memos ..................................... 281

aCopying Images ...................................................................... 283

LErasing Images........................................................................ 286

Changing Image Playback Settings ............................................. 288

Adjusting the LCD Monitor Brightness....................................... 288

Auto Rotation of Vertical Images ............................................... 289

Post-Processing Images 291

RProcessing RAW Images with the Camera .......................... 292

SResize..................................................................................... 297

Sensor Cleaning 299

fAutomatic Sensor Cleaning .................................................. 300

Appending Dust Delete Data........................................................ 301

Manual Sensor Cleaning .............................................................. 303

Printing Images and Transferring Images to a Computer

305

Preparing to Print ......................................................................... 306

wPrinting.................................................................................... 308

Trimming the Image................................................................... 313

WDigital Print Order Format (DPOF) ......................................... 315

WDirect Printing with DPOF....................................................... 318

dTransferring Images to a Personal Computer........................ 319

Customizing the Camera 323

Custom Functions ........................................................................ 324

Altri manuali per EOS-1D Mark II Digial

Indice

Altri manuali Canon Macchina fotografica digitale

Canon

Canon PowerShot 600 Manuale utente

Canon

Canon EOS 7D Mark II (G) Manuale utente

Canon

Canon DIGITAL IXUS i5 PowerShot SD20 Manuale utente

Canon

Canon POWERSHOT A700 Manuale utente

Canon

Canon EOS M6 Mark II Istruzioni per il montaggio

Canon

Canon PowerShot SD430 DIGITAL ELPH WIRELESS Manuale di servizio

Canon

Canon Powershot SX150 IS Manuale utente

Canon

Canon EOS REBEL K2 3000V DATE Manuale utente

Canon

Canon PowerShot G6 Manuale utente

Canon

Canon Powershot SX120 IS Manuale utente

Canon

Canon WP-DC49 Manuale utente

Canon

Canon Sure Shot WP-1 Manuale utente

Canon

Canon Powershot SD40 Manuale utente

Canon

Canon PowerShot ELPH 500 HS Manuale utente

Canon

Canon REBEL SL1 EOS 100D Manuale utente

Canon

Canon PowerShot A510 Manuale utente

Canon

Canon EOS Rebel SL2 Guida all'installazione

Canon

Canon POWERSHOT A75 Guida all'installazione

Canon

Canon EOS REBEL T5I EOS 700D Manuale utente

Canon

Canon PowerShot A1000 IS Manuale utente

Canon

Canon Ixus 240 hs Manuale utente

Canon

Canon EOS-1D Mark II Digial Manuale utente

Canon

Canon EOS1 Ds MARKII Guida

Canon

Canon RebelT3i EOS 600D Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Nikon

Nikon Coolpix 100 Manuale utente
