Channel Vision Aria IC607 Manuale utente

Channel Vision Technology will repair or replace any defect in

material or workmanship which occurs during normal use of this

roduct with new or rebuilt parts, free of charge in the USA, for ten

years from the date of original purchase. This is a no hassle warranty

with no mail in warranty card needed. This warranty does not cover

damages in shipment, failures caused by other products not supplied

by Channel Vision Technology, or failures due to accident, misuse,

abuse, or alteration of the equipment. This warranty is extended only

to the original purchaser, and a purchase receipt, invoice, or other

roof of original purchase date will be required before warranty

repairs are provided.

Mail in service can be obtained during the warranty period by calling

(800) 840-0288 toll free. A Return Authorization number must be

obtained in advance and can be marked on the outside of the shipping

carton.

This warranty gives you specific legal rights and you may have other

rights (which vary from state to state). If a problem with this product

develops during or after the warranty period, please contact Channel

Vision Technology, your dealer or any factory-authorized service

center.

500-075 rev D

IC607

6.5” IN-CEILING SPEAKER

Model IC607

Installation:

Use the provided template to mark and cut a 7.7” hole in

drywall away from ceiling joists.

We recommend wiring with AWG 16 or larger, stranded

wire.

For proper phasing, both voice coils must be wired alike.

Connect red wires to red terminals on speaker and to red

or plus terminals on amplifier.

Install IC607 in the hole. Tighten the mounting screws.

The mounting dog legs will rotate outward and grip the

drywall.

To control the volume of the speaker locally, use an

impedance matching volume control, such as the

Channel Vision VC302.

Mounting screws (4)

Specifications:

Frequency range:

Power Handling:

Drivers:

Impedance:

Finish:

Dimensions:

50Hz - 20kHz ± 3dB

70 Watts

1- .5” Mylar tweeter

1- 6.5” polypropylene woofer

8 ohms

ABS plastic

9” OD. 3.3

(Depth from surface of wall board)

”Deep

Specifications subject to change without notice.

Features:

Cost Effective

Easy to install

6.5” In-ceiling loudspeaker

Mica-filled polypropylene woofer with butyl rubber surround

Small perforated designer grille

Recommended power: 70W (peak)

Rough-in bracket kit sold separately Model: IC65RB-2
