Co2meter AZ-0002 Manuale utente

 

PORTABLE CO2 METER

INTRODUCTION

Features:

asy calibration

humidity

PC connect

Triple displays of CO2 level, temp.

and humidity.

Stable NDIR sensor for CO2 detection

Statistics of weighted averages

TWA (8 hours weighted average)

STEL(15 minutes weighted average)

Backlight for working in dark area

Audible CO 2 warning alarm

Battery and adaptor power supply

E manual on CO and

via RS232 interface

Thank you for purchasing this portable

CO meter. The meter measures CO

2 2

level, air temp., dew point, wet bulb temp.

and humidity(DP, WB, RH are for models

7755/77535) and is an ideal instrument

for indoor air quality (IAQ) diagnosis.

Poor indoor air quality is considered

unhealthy because it causes tiredness,

loss of ability to concentrate, and even

illness(ex. Sick Building Syndrome). IAQ

monitoring and survey, especially on CO

level and air ventilation become widely

applied in public areas such as offices,

classrooms, factories, hospitals and

hotels. It is also suggested in regulations

of industrial hygiene in some countries.

(Appendix)

The portable CO meter uses NDIR (non-

dispersive infrared) technology to ensure

the reliability and long term stability. It’s

useful in verifying HVAC system perform-

ance and air ventilation control.

MATERIAL SUPPLIED

Meter

4pcs AA batteries

Operation manual

Hard carrying case

This package contains:

Optional accessory:

33% calibration salt (VZ0033AZ1)

75% calibration salt (VZ0075AZ1)

RS232 cable and software

Adaptor (9V/100~240Vac)

POWER SUPPLY

The meter is powered by either 4 AA

batteries or a DC adaptor(9V/1A output).

Install the batteries into the battery

compartment on the rear and make sure

they are in correct polarity and good

contact.

“Lob” will appear on the LCD .

And beeper sounds.

atter

When an adaptor is used, it will

cut off the power supply from batteries.

The adaptor can’t be used as a battery

charger.

When battery voltage gets low, a

(Fig.1)

The CO sensor

can’t work under low voltage, so it beeps

to indicate failed CO measurement

(press any key but to stop the beeps)

and the readings won’t be displayed.

Please replace with fresh b ies or

connect with an adaptor.

CO2

7752/77532 7755/77535

Fig.1

SET

LCD DISPLAY

TWA Time weighted average(

STEL hort-term exposure limit

(15 minutes weighted

MIN/MAX Minimum/Maximun readings

Low battery indicator

DP Dew point temperature

AIR Air temperature

WBT Wet bulb temperature

% Unit of relative humidity

oE (C/F) Celsius/Fahrenheit

AVG/ftm/m/s Vain icons in these models

8 hours)

average)

HOLD Readings are freezed unchanged

TWA

STEL

HOLD

ftm

m/s

CO2

concentration

in ppm

Relative

humidity in %

Air temp.

Dew point

Wet bulb

temp. in

oC or F

Symbols

Turns on and off the meter.

Enters setup mode.

Sets as non-sleep mode with .

SET

CAL

Esc

DP/WBT

M /AV

Exits setup page/mode.

Enters CO calibration with .

Enters RH calibration with .

Freezes the current readings.

Cancels data hold function.

Activates or cancels the backlight.

Selects unit or increases value in setup.

Selects AIR, DP, WBT temps display.

Selects unit or decreases value in setup.

Activates MIN,MAX,STEL,TWA function.

Saves and finishes settings.

DP/WBT

KEYPAD

OPERATION

Press to turn the meter on and off.

At power up, it emits a short beep and

performs 30 seconds countdown(Fig.2)

for meter warm up, then enters normal

mode with current CO , temperatures,

and humidity readings

displayed (Fig.3).

SET

CO2

Fig. 2

Fig 3

Model 7752/77532 Model 7755/77535

DP/WBT

CO2

Fig.4 Fig.5

TAKING MEASUREMENT

CO2

Press to switch temperatures

display. The lower left display will cycle

from air temperature, dew point temp.

(Fig.4), and wet bulb temp.(Fig.5).

The meter starts measurement when

power on and update readings every

second. In the condition of operating

environment change (ex. from high to

low temp.), it takes 30 sec to respond

for CO sensor and 30 minutes for RH.

NOTE: Do not hold the meter close to

faces in case exhalation affects CO

levels.

POWER ON/OFF

AIR(all models),DP,WBT

DATA HOLD

Press to freeze the readings,

"HOLD” icon is displayed on the left

top of LCD(Fig.6). All current readings

are kept unchanged, except STEL and

TWA. Press again to cancel the

hold function.

HOLD

CO2

Fig.6

BACKLIGHT

Hold down for more than 1 second

to activate and cancel backlight function.

MIN,MAX,STEL,TWA

Under normal mode, press to see

the minimum, maximum, and weighted

average readings. Each press of ,

it displays MIN, MAX, STEL, TWA in

sequence and returns to normal mode.

In MIN and MAX modes, it shows the

minimum and maximum readings of

CO on main display and of AIRor Dpor

WB temperatures and humidity

on the lower displays. (Fig.7)

M /AV

CO2

Fig.7

In STEL and TWA modes, the main

display shows the

(STEL) and 8 hours(TWA).

weighted average of

CO readings for the past 15 minutes

The lower

displays are the current AIR, DP/WB

temperatures and humidity.

. (Fig.8)

M /AV

STEL

CO2

Fig.8

NOTE:

While all readings are held unchanged,

STEL and TWA will keep updating

every 5 minutes.

If the meter is turned on for shorter

than 15 minutes, the STEL value will

be the weighted average of readings

taken since power on. Same for TWA

values appear before 8 hours.

2.It takes at least 5 minutes to calculate

STEL and TWA. The display shows

“----” (Fig.9) during the first 5 minutes

from power on.

SET

STEL

CO2

Fig. 9

The meter turns off automatically after

20 minutes of inactivity. To override the

function, hold down and for 2

seconds to turn on the meter until “n”

appears. NOTE: Auto sleep function

will be disabled during calibration mode.

SET

AUTO POWER OFF

ALARM

The meter features audible alarm to

give warnings when CO concentration

exceeds the limit. (See P1.0 in setup

for setting alarm threshold). It emits

beeps(Abt.80dB)when CO level goes

over the set value and stops when any

key (but ) was pressed or readings

fall below the set value. It beeps again

when value goes over the limit. Restart

the meter if beeper can't be stopped.

SETUP

Hold down un

setup mode.

To exit setup, press in P1.0 or P3.0

and it returns to normal mode.

Note: P2.0 is not applicable in these

models but for future model with

CO and CO measurement.

P1.0 CO ALARM

When entering setup mode, P1.0 and

“AL” (Fig.10) are displayed on the LCD.

Press to go into P1.1 for setting

CO alarm threshold. The current set

value will be blinking on LCD

Press to increase the value or

to decrease. Each press tunes

and the alarm range is from

100 to 9900ppm. When the preferred

alarm value is set, press to save

the setting or without saving and

return to P1.0.

P3.0 TEMPERATURE SCALE

Press or in P1.0 to access P3.0

for setting up temperature scale(Fig.12).

Press and it goes into P3.1 with

o o

blinking C or F current set(Fig.13) on

the lower left display. To switch

press to

save the setting or without saving

and return to P3.0.

der normal mode for

more than 1 sec to enter

(Fig11).

100 ppm

o o

C or F,

press and . Then

SET

CAL

Esc

M /AV

DP/WBT

M /AV

CAL

Esc

CO2CO2

Fig. 10 Fig. 11

DP/WBT

M /AV

DP/WBT

M /AV

CAL

Esc

Fig. 12 Fig. 13

CO CALIBRATION

CAUTION:

Do not calibrate the meter in the air

with unknown CO concentration.

Otherwise, it will be calibrated as

400ppm by default and leads to

inaccurate measurements.

CAL

Esc

CO2

Fig. 14

NOTE:

Ensure the batteries are with full voltage

during the calibration to prevent from

interruption or failed calibration.

The manual calibration is suggested to

to be done in fresh outdoor air that is

well ventilated and in sunny weather.

Place the meter in the calibration site.

Turn on the meter and hold down

and simultaneously to enter CO

calibration mode (Fig.14). 400ppm and

“CAL” are blinking on the LCD while

performing calibration.

Wait about 5 minutes until the blinking

stops and the calibration is completed

automatically and back to normal mode.

To abort the calibration, turn off the

meter at any time.

The meter is calibrated at standard

400ppm CO concentration in factory.

It’s suggested to do manual calibration

regularly to maintain good accuracy.

Note:

When the accuracy becomes a concern

after a long time usage, return to dealers

for standard calibration.

33% calibration

Plug the sensor probe into 33% salt

bottle. Hold down and under

normal mode to enter 33% calibration

(Fig.15). “CAL” and calibrating value

(32.7% if at are blinking on the

LCD with current temperature at the left.

Meter is now calibrating, and will finish

in about 60 minutes when “CAL” and

humidity stop blinking. (Fig.16)

25 C)

The meter defaults to be calibrated the

humidity with 33% and 75% salt solution.

The ambient condition is recommended

to be at 25 C and stable humidity(better

to be close to the calibrating value). To

abort calibration, just turn off the meter.

(7755/77535)

RH CALIBRATION

CAL

Esc DP/WBT

Fig. 15

Fig. 16

Fig.17

75% calibration

After 33% calibration, plug the sensor

probe into 75% salt bottle, then press

to enter 75% calibration (Fig.17).

M /AV

CAUTION:

Do not calibrate the humidity without

the default calibration salt. Otherwise,

it will cause permanent damage.

Contact the dealer for calibration salt

or services.

Altri manuali Co2meter Strumento di misura

Co2meter

Co2meter SAN-20 Manuale utente

Co2meter

Co2meter SAN-10 Manuale utente

Co2meter

Co2meter XT-10 Manuale utente

Co2meter

Co2meter eSENSE Outdoor SE-0036 Manuale utente

Co2meter

Co2meter RAD-0002-ZR Manuale utente

Co2meter

Co2meter CM-1650 Manuale utente

Co2meter

Co2meter AZ-0004 Manuale utente

Co2meter

Co2meter 77597 Manuale utente

Co2meter

Co2meter SAN-10 Manuale utente

Co2meter

Co2meter AZ 77535 Manuale utente

Co2meter

Co2meter TecPen MAP TS-200 O2 Manuale utente

Co2meter

Co2meter Gastrack GAP-100 Manuale utente

Co2meter

Co2meter SAN-0001 Manuale utente

Co2meter

Co2meter CM-1650 Manuale utente

Co2meter

Co2meter 7755 Manuale utente

Co2meter

Co2meter CM-650 Manuale utente

Co2meter

Co2meter CM-1650 Manuale utente

Co2meter

Co2meter TIM-12 Manuale utente

Co2meter

Co2meter TON-0007 Manuale utente

Co2meter

Co2meter Aranet4 PRO Manuale utente

Co2meter

Co2meter RAD-0002 Manuale utente

Co2meter

Co2meter AQ500 Manuale utente

Manuali Strumento di misura popolari di altre marche

Suaoki

Suaoki D40 Manuale utente

Elster

Elster BK-G1.6 Manuale utente

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuale

Duratool

Duratool D03128 Manuale utente

Vega

Vega VEGAPULS 65 Manuale utente

Tonghui

Tonghui TH2618B Manuale utente

Tenmars

Tenmars TM-801 Manuale utente

MSR

MSR 145 Manuale utente

TPS

TPS WP-82 Manuale utente

ELMETRON

ELMETRON CP-511 Manuale utente

PCB Piezotronics

PCB Piezotronics 003C30 Manuale utente

Tenma

Tenma 72-10465 Manuale utente

Endress+Hauser

Endress+Hauser Proline Promag 50 Specifiche tecniche

Siemens

Siemens SITRANS F Coriolis FCT030 Manuale elenco delle parti

KLINGER

KLINGER CMF V Series Manuale utente

EXFO

EXFO FTB-2 Manuale operativo e di manutenzione

Keysight

Keysight M8290A Manuale utente

ADTEK

ADTEK MW-5 Manuale utente
