Nucleus® CP910 and

CP920 Sound Processor

Hybrid Hearing Supplement*

Patient Information

* FDA approved for use with the

Hybrid L24 (CI24REH) Implant

Microphones and

microphone protectors

Coil

Indicator light

Coil magnet

Upper button Coil cable

Lower button

CP920

Processing unit

Serial number

Acoustic component

* Acoustic component only approved for use with the Nucleus Hybrid Implant

Compact

rechargeable

battery module

CP920 Sound Processor with Acoustic Component*

with Compact Rechargeable Battery Module

Microphones and

microphone protectors

Coil

Indicator light

Coil magnet

Upper button Coil cable

Lower button CP910

Processing unit

Serial number Accessory

socket

Earhook

Standard

rechargeable

battery module

CP910 Sound Processor

with Standard Rechargeable Battery Module

3COCHLEAR NUCLEUS 6 • HYBRID HEARING SUPPLEMENT

Symbols

Note

Important information or advice.

Tip

Time saving hint.

Caution (no harm)

Special care to be taken to ensure safety and effectiveness.

Could cause damage to equipment.

This guide is for recipients of the Cochlear™

Nucleus®Hybrid L24 Cochlear Implant. It

providesinformation about using an acoustic

component with your sound procesor for

Hybrid Hearing. You can also choose a

Cochlear Nucleus CR210 Remote Control or

CR230 Remote Assistant to control

your processor. For more about remotes,

please consult your remote user guide.

People with certain types of hearing loss can wear the processor in

Hybrid mode by adding an acoustic component. The acoustic component

sends ampliﬁed acoustic sound into the ear canal.

A number of tools and accessories are supplied with your sound processor.

NOTE

Please refer to the booklet Important

Information: Warnings, Precautions and

Electromagnetic Compatibility for important

information that applies to cochlear

implant systems.

Wear

5COCHLEAR NUCLEUS 6 • HYBRID HEARING SUPPLEMENT

Your processor is protected against failure

from dust and temporary immersion in

water (IP57 rated) when you wear it with:

• a rechargeable battery module

• a coil and coil cable

• a closed accessory socket

• no acoustic component.

Your processor is protected against failure

from splashing water or access of foreign

objects 1.0 mm in diameter or larger

(IP44 rated) when you wear it with:

• a tamper resistant battery module

• a coil and coil cable

• a closed accessory socket

• an acoustic component worn in the ear.

Water, Sand and Dirt

The acoustic component

If your sound processor is programmed for use in Hybrid mode, you can

wear it with an acoustic component.

Wear your acoustic component

Hold the coil in one hand and place the

processor on your ear with the other.

Place the coil on your head.

Place your dome or earmould in your

ear as instructed by your clinician.

When removing your coil and processor,

remove your dome or earmould as

instructed by your clinician.

TIP

Always use the removal cord

(if present) when taking the

earmould out of your ear.

7COCHLEAR NUCLEUS 6 • HYBRID HEARING SUPPLEMENT

Remove your acoustic component

Wear your processor without the acoustic component by

replacing it with a standard earhook. Talk to your clinician

before replacing:

Locate the opening under the earhook.

Remove the battery module from the

processing unit by twisting the two

parts as shown.

Re-attach the battery module.

Press ﬁrmly on top of the Cochlear

EAC200 Series Earhook with your

thumb to click it off the sound

processor.

Insert a Cochlear EAC200 Series

Screwdriver into the hole. Carefully

push and twist the screwdriver until

the speaker unit cable disconnects.

CAUTION

Use only the EAC200 Series Screwdriver

– not the Cochlear™ Nucleus® Battery

Cover Locking Tool – to remove the acoustic

component.

9COCHLEAR NUCLEUS 6 • HYBRID HEARING SUPPLEMENT

Click the standard earhook into place.

Insert a new processing unit plug into

the speaker unit cable socket. Make

sure the plug goes all the way in.

Attach your acoustic component

Press ﬁrmly on the top of the standard

earhook with your thumb to click it off

the processor.

2Insert the Cochlear™ EAC200 Series

Screwdriver into the hole in the

processor unit plug.

3Use the screwdriver to carefully remove

the plug. Do not twist or try to lever the

plug out. Save the plug.
