CL5500 - Programming and
Operating Instructions
About CL5500
Thisrange of lockscan be operated and managed directlyvia the keypador via a
compatible smartphone by downloading the K3 Connect App.
This Programming and Operating Instructions provides the basics to get you started plus
the full details on how to program and operate the CL5500 range of locks.
The Basics
Master Code
The factory set Master Code is #12345678. This should be changed immediately after installation (Program
01). The Master Code (and Sub-Master Code if set) always start with the # button. This puts the lock in
Programming Mode.
Access Methods
The lock supports a maximumof 350 Clients (users):User Codes (100), User Cards (150)and User
Compatible Phones (100).
Keypad
The lock has a 12 button, back-lit keypad which includes * and # buttons. The # button is only used for
programming. The * button is used in some Programs and with NetCodes.
Code Free
Code Free can be configured via Program04orvia Key-in-Lever by changing the cylinder tailpiece (refer to
Installation Instructions).
Locked/Unlocked Status
By default, when the lock is locked, there is no visual indication. Program08can be used to enable locked
indication.
Views: 866
Print
24/9/2561 KA-01040 · Customer Self-Service
https://support.codelocks.com/knowledgebase/article/KA-01040/en-us 2/13
Remote Release
The lock has two sets of terminals within the front housingfor remote release, labelled REM1 and REM2.
REM1 is intended for push-button release where the lock will open for the normal set time. REM2 is
intended for use where the lock needs to be released for a longer period. When a switch or relay
connected to REM2 is closed, the lock will open for a period of 30 minutes after which the lock will revert
to normal operation. Refer to Installation Instructions for further information.
The App
Manage with the K3 Connect App
The lock can be managed with the K3 Connect App by any Bluetooth compatible smartphone.
The Appis available on:
Apple App Store for Apple devices or Google Play™ for Android™ devices by searching forK3 Connect.
1. Install the K3 Connect App on your device.
2. Once installed, open K3 Connect and selectCreate Account.
3. The account creation process includes email confirmation. Once the account has been created, sign-
in to the App.
4. To add a new lock, touch the+iconon theLocksscreen.
5. Enter the lock DIN and choose a lock name.
For this lock range it is CL5510 - DIN: CL5510
Note:The lock DIN is case-sensitive. DIN to be used for all CL5500 variants i.e. CL5510, CL5520,
CL5500PK etc.
6. In the App, touch the tickand then immediately, on the lock, enter the following Program:
#Master Code•00•1••
Example:#12345678•00•1••
Note:If you have changed your Master Code, substitute the code used in the example with your own
code.
7. The lock will now pair with your phone.
Factory Reset
The lock can be reset to its original factory settings. You may need to do this if the Master Code is no
longer known or you no longer have management access via a smartphone. To reset the lock, you must
have access to the battery compartment in the rear of the lock.
1. Remove a battery.
2. Press and hold the0button.
24/9/2561 KA-01040 · Customer Self-Service
https://support.codelocks.com/knowledgebase/article/KA-01040/en-us 3/13
3. Replace the battery whilst continuing to hold the0button.
4. After the double beep, release the0button.
5. Press the0button three times.
6. If successful the Blue LED's will burn for 7 seconds.
Regulatory Compliance
The device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and(2)This device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Apple, the Apple logo, and iPhone are trademarks of Apple Inc., registered in the U.S. and other
countries.App Store is a service mark of Apple Inc.
Android, Google Play and the Google Play logo are trademarks of Google Inc.
Programs
01 Change the Master Code
Note:The Master Code is 8 digits in length.
#Master Code•01•New Master Code•New Master Code••
Example:#12345678•01•87654321•87654321••
Result:The Master Code has been updated to 87654321
24/9/2561 KA-01040 · Customer Self-Service
https://support.codelocks.com/knowledgebase/article/KA-01040/en-us 4/13
02 Change the Sub-Master Code
Note:The Sub-Master Code is 8 digits in length.
#Master Code•02•New Sub-Master Code•New Sub-Master Code••
Example:#12345678•02•44556677•44556677••
Result:The Sub-Master Code has been changed to 44556677
03 Delete the Sub-Master Code
#Master Code•03••
Example:#12345678•03••
Result:The Sub-Master Code has been deleted
06 Change the Re-lock Delay
Change the time (in seconds) for the lock to remain unlocked after successful unlocking (i.e. correct code,
card or phone).
The default re-lock delay is 5 seconds.
Note:The delay range is from 2 seconds to 30 seconds.
#Master Code•06•Time <02-30>••
Example:#12345678•06•10••
Result:The lock will remain open for 10 seconds after successful unlocking
08.1 Change the Locked/Unlock Status
By changing the locked/unlocked status, you can enable a visual locked status indicator.
Disable locked status indicator (default)
Note: This Program is available to both the Master and Sub-Master codes.
#Master Code•08•01••
Example:#12345678•08•01••
Result:No locked status indicator
08.2 Enable locked status indicator
Note: This Program is available to both the Master and Sub-Master codes.
#Master Code•08•02••
Example:#12345678•08•02••
Result:The red LED will flash every 5 seconds
Note:Battery life will be reduced by enabling the locked status indicator.
07 Emergency Open Cancellation
By closing the normally open REM 2 contact, the lock will open for 30 minutes. The Emergency Open
Cancellation reverts the lock to normal operation after the REM 2 input has been triggered.
Note:This Program is available to both the Master and Sub-Master Codes.
#Master Code•07••
24/9/2561 KA-01040 · Customer Self-Service
https://support.codelocks.com/knowledgebase/article/KA-01040/en-us 5/13
Example:#12345678•07••
Result:The lock reverts to normal operation
Note:See Installation Instruction for REM connection.
13 Feature Restriction
The lock supports entry methods including code, card, phone and NetCode. By default, all methods are
supported but can be disabled using the program below.
Note:Access via a smartphone with the K3 Connect App is not supported in standalone applications.
#Master Code•13•User Code <0-1>•Smart Card <0-1>•NetCode <0-1>••
Example:#12345678•13•1•1•1••
Result:Code, Card and NetCode methods are all enabled.
Help:To enable a method, specify 1. To disabled a method, specify 0
14.0 Disable Keypad Illumination
Note:Keypad illumination is disabled by default.
#Master Code•14•0••
Example:#12345678•14•0••
Result:Keypad illumination is disabled.
14.1 Enable Keypad Illumination by Proximity
Keypad will illuminate when something comes in very close proximity to the keypad.
#Master Code•14•1•Start Hour <08>•End Hour <17>••
Example:#12345678•14•1•08•17••
Result:Keypad illumination by proximity is enabled from 8am - 5pm.
Note:Battery life will be reduced by enabling keypad illumination.
14.2 Enable Keypad Illumination by Button Press
Keypad will illuminate when any button is pressed.
#Master Code•14•2•Start Hour <08>•End Hour <17>••
Example:#12345678•14•2•08•17••
Result:Keypad illumination by button press is enabled from 8am - 5pm.
Note:Battery life will be reduced by enabling keypad illumination.
15.1Lock-Down
Prevent the lock from being unlocked by any method except via Master Code and Sub-Master Code:
Note: This Program is available to both the Master and Sub-Master codes.
#Master Code•15•1••
Example:#12345678•15•1••
Result:Lock-Down is enabled. Only the Master and Sub-Master Codes can be used to open the lock.
24/9/2561 KA-01040 · Customer Self-Service
https://support.codelocks.com/knowledgebase/article/KA-01040/en-us 6/13
15.2 Cancel Lock-Down
Note:This Program is available to both the Master and Sub-Master codes.
#Master Code•15•2••
Example:#12345678•15•2••
Result:Lock-Down is cancelled.
Code Free
Configures the lock to allow code free passage where no code, card or phone is needed to open the lock.
Up to 10 Code Free times can be added. Each period can be set to work on one or more specific days.
04 Setting Code Free Mode
Note:Code Free takes priority over any other setting except lock-down.
Note:This Program is available to both the Master and Sub-Master Codes.
#Master Code•04•Code Free period <0-9>•Time Start <HHmm>•Time End <HHmm>•Week
Pattern••
Example:#Master Code•04•0•0900•1630•1111100••
Result:The lock will be in Code Free from 09:00 to 16:30 on Monday to Friday
Help:The week pattern uses a sequence of 7 numbers (MTWTFSS) that enable (1) or disable (0) Code Free
on a particular day.
Suspend or Restore Code Free
Suspends or restores Code Free Mode for specific or all Code Free Mode periods.
05.1 Suspend specific Code Free period
Note: This Program is available to both the Master and Sub-Master Codes.
#Master Code•05•1•Code-Free period <0-9>••
Example:#12345678•05•1•0••
Result:Suspends Code Free period 0
05.2 Restore specific Code Free period
Note: This Program is available to both the Master and Sub-Master Codes.
#Master Code•05•2•Code Free period <0-9>••
Example:#12345678•05•2•0••
Result:Code Free period 0 restored
05.3 Suspend all Code Free periods
Note: This Program is available to both the Master and Sub-Master Codes.
#Master Code•05•3••
24/9/2561 KA-01040 · Customer Self-Service
https://support.codelocks.com/knowledgebase/article/KA-01040/en-us 7/13
Example:#12345678•05•3••
Result:Suspends all Code Free periods
05.4 Restore all Code Free periods
Note: This Program is available to both the Master and Sub-Master Codes.
#Master Code•05•4••
Example:#12345678•05•4••
Result:Restores all Code Free periods
Date & Time
10 Update the Date/Time
Update the date and time on the lock. Particularly important when Code Free and Active-Period options are
in use.
#Master Code•10•YYMMDD•HHmm••
Example:#12345678•10•160122•1422••
Result:The date has been updated to January 22nd, 2016 and the time to 14:22.
Set Daylight Savings Time
11 Update the Daylight Savings Time (DST)
#Master Code•11•Date Starts <YYMMDD>•Date Ends <YYMMDD>••
Example:#12345678•11•160327•161030••
Result:DST is set to start on March 27th, 2016 and end on October 30th, 2016.
In the majority of countries where DST operates, DST is applied at 01:00. This is the default DST time
on the lock but can be changed by using the program below.
12Set newDaylight Saving Time
#Master Code•12•Time <HH>••
Example:#12345678•12•02••
Result:DST will now be applied at 02:00
Clients (Users)
Add a New Client
24/9/2561 KA-01040 · Customer Self-Service
https://support.codelocks.com/knowledgebase/article/KA-01040/en-us 8/13
Four different types of client can be created when the lock is in standalone operation: standard code client,
one-time code client (where the code will be blocked after a single use), card user (MIFARE based
smartcards) and technician clients (only applicable when GuestCode is being used).
20.1 Add Code Client
Note:This Program is available to both the Master and Sub-Master Codes.
#Master Code•20•1•Code••
Example:#12345678•20•1•3366••
Result:The code 3366 can now be used to unlock the lock.
20.2 Add One-Time Code Client
#Master Code•20•2•Code••
Example:#12345678•20•2•7788••
Result:The code 7788 can be used to unlock the lock once only after which time it will be blocked.
20.3 Add Smart Card Client
Note:After entering the program below, the lock will wait for a MIFARE based smartcard to be placed over
the keypad.
Note: This Program is available to both the Master and Sub-Master codes.
#Master Code•20•3••
Example:#12345678•20•3••
Result:The smart card will be able to unlock the lock.
Note:This can be repeated for up to 150 cards.
20.4 Add Technician Code Client
Note:Only applicable when the GuestLock feature is enabled.
#Master Code•20•4•Technician Code••
Example:#12345678•20•4•4499••
Result:The Technician Code 4499 is now enabled
Selected Day Lock-Out
This program will lock out all Clients on the specified days. Please note that if a Client has a specific Active
Period, that will take priority over the selected day lock-out program. See Active Periods page 5.
29.1 Enable Selected Day Lock-Out
Note:This program does not affect Master Codes, Sub-Master Codes or NetCodes. This program will affect
Code Clients, smart card Clients and GuestCode Clients.
Note: This Program is available to both the Master and Sub-Master codes.
#Master Code•29•Week Pattern••
Example:#12345678•29•1111100••
Result:Entry only permitted on Mondays to Fridays.
24/9/2561 KA-01040 · Customer Self-Service
https://support.codelocks.com/knowledgebase/article/KA-01040/en-us 9/13
Help:The week pattern uses a sequence of 7 numbers (MTWTFSS) that enable (1) or disable (0) Code-Free
on a particular day.
29.2 Disable Selected Day Lock-Out
Note: This Program is available to both the Master and Sub-Master codes.
#Master Code•29•0000000••
Example:#12345678•29•0000000••
Result:Selected Day Lock-Out is disabled
Suspend and Restore Clients
Any Code Client can be suspended and restored. Smart Card Clients cannot be suspended when the lock is
in standalone operation.
21 Suspend a Code Client
Note:This Program is available to both the Master and Sub-Master Codes.
#Master Code•21•Code••
Example:#12345678•21•1199••
Result:The Code 1199 has been suspended.
22 Restore a Code Client
Note:This Program is available to both the Master and Sub-Master Codes.
#Master Code•22•Code••
Example:#12345678•22•1199••
Result:The Code 1199 has been restored.
Help:All clients can be suspended and restored by using the lock-down programs
Deleting Clients
Any Code Client can be deleted. When the lock is being used in standalone operation, smart card clients
can only be deleted by deleting all clients.
25 Delete a Single Code Client
Note:This Program is available to both the Master and Sub-Master Codes.
#Master Code•25•Code•Code••
Example:#12345678•25•1199•1199••
Result:The Code 1199 has been deleted.
24/9/2561 KA-01040 · Customer Self-Service
https://support.codelocks.com/knowledgebase/article/KA-01040/en-us 10/13
26 Delete All Clients
#Master Code•26••
Example:#12345678•26••
Result:All Clients have been deleted
Active Periods
In standalone operation, specific Active Periods can only be set for Code Clients. To use Active Periods for
all Client types, you will need to use the K3 Connect App. Up to 10 Active Periods can be set for each Client.
27.1 Set an Active Period for ALL Clients
Note: This Program is available to both the Master and Sub-Master codes.
#Master Code•27•****•Active Period <0-9>•Start Time <HHmm>•End Time <HHmm>•Week
Pattern••
Example:#12345678•27•****•0•1330•1830•0101000••
Result:All Clients will have access between 13:30 and 18:30 on Tuesdays and Thursdays only.
27.2 Set an Active Period for a Specific Code Client
Note:This Program is available to both the Master and Sub-Master Codes.
#Master Code•27•Code•Active Period <0-9>•Start Time <HHmm>•End Time <HHmm>•Week
Pattern••
Example:#12345678•27•1199•0•0900•1700•1111100••
Result:Client with Code 1199 has access between 09:00 and 17:00, Monday to Friday.
28.1 Suspend (Disable) Specific Active Period
Note: This Program is available to both the Master and Sub-Master codes.
#Master Code•28•1•Code•Active Period <0-9>••
Example:#12345678•28•1•1199•0••
Result:Suspends the first Active Period for Client with Code 1199.
28.2 Restore Specific Active Period
Note: This Program is available to both the Master and Sub-Master codes.
#Master Code•28•2•Code•Active Period <0-9>••
Example:#12345678•28•2•1199•0••
Result:Restores the first Active Period for Client with Code 1199.
28.3 Suspend All Active Periods for Specific Code Client
Note: This Program is available to both the Master and Sub-Master codes.
#Master Code•28•3•Code••
Example:#12345678•28•3•1199••
Result:Suspends all the Active Periods for Client with Code 1199.
Altri manuali per CL5500 SERIES
3
Questo manuale è adatto per i seguenti modelli
3
Indice
Altri manuali CODELOCKS Serratura
CODELOCKS
CODELOCKS CL5500 SERIES Manuale utente
CODELOCKS
CODELOCKS Kit-Lock KL1100 Manuale utente
CODELOCKS
CODELOCKS CL1000 Manuale utente
CODELOCKS
CODELOCKS CL210 Manuale utente
CODELOCKS
CODELOCKS KL1050 Manuale utente
CODELOCKS
CODELOCKS CL300 Manuale utente
CODELOCKS
CODELOCKS CL100 Manuale utente
CODELOCKS
CODELOCKS CL255 Guida per l'amministratore
CODELOCKS
CODELOCKS KitLock Slam Latch Manuale utente
CODELOCKS
CODELOCKS CL2000 Manuale utente
CODELOCKS
CODELOCKS Pushbutton 500 Series Guida rapida
CODELOCKS
CODELOCKS CL4510 Manuale utente
CODELOCKS
CODELOCKS KL1000 G3 NetCode Manuale utente
CODELOCKS
CODELOCKS CL500 Manuale utente
CODELOCKS
CODELOCKS CL4510 Manuale utente
CODELOCKS
CODELOCKS CL250 Guida per l'amministratore
CODELOCKS
CODELOCKS Kit-Lock KL1100 Manuale utente
CODELOCKS
CODELOCKS CL4510 Manuale utente
CODELOCKS
CODELOCKS CL50 Manuale utente
CODELOCKS
CODELOCKS CL5000 Manuale utente
