6SMARTHUB
1.6 Main Features
•SMARTHUB monitors up to 4 devices working simultaneously and can store
another 128 devices in stand-by mode.
•SMARTHUB continuously monitors real- time RPMs, battery level, RSSI, speed
alerts, device ID, working hours, and also displays tools installed and machine ID.
•Four colored LEDs indicate operating modes.
•SMARTHUB casing is compact, streamlined, robust, and IP67 sealed.
1.7 Basic Configuration — 5 PLC I/O SIGNALS:
•Low RSSI
•Low Battery
•High / Low Speed Limit Exceeded
•Spindle Speed ≠ 0
•Power ON
1.8 SMARTHUB Case Contents
•One SMARTHUB Unit
•UL Cable (one meter), male Amphenol connector at
the SMARTHUB end, stripped for wiring at the other
end. Longer cable or additional connectors are
available upon request
•User Manual and Installation Guide
1.9 Display Tablet
The Display Tablet is a sealed, IP68 rugged model, featuring a slim, light-weight casing
and convenient holding strap. It comes in a protective carry case, and includes, a
charger, USB cable and manufacturer's instructions booklet.
NOTE: The Display Tablet is ordered and packaged separately.
