MS-C78

Micro ATX Motherboard

User’s Manual

Edition 1.0

2014/02/24

MS-C78 User’s Manual

-1-

reserved. The information in this document is subject to change without prior notice to

make improvements to the products.

This document contains proprietary information and protected by copyright. No part of

this document may be reproduced, copied, or translated in any form or any means

without prior written permission of the manufacturer.

All trademarks and/or registered trademarks contains in this document are property of

their respective owners. Disclaimer

The company shall not be liable for any incidental or consequential damages resulting

from the performance or use of this product.

The company does not issue a warranty of any kind, express or implied, including

without limitation implied warranties of merchantability or fitness for a particular purpose.

The company has the right to revise the manual or include changes in the specifications

of the product described within it at any time without notice and without obligation to

notify any person of such revision or changes.

Trademark

All trademarks are the property of their respective holders.

Any questions please visit our website at TUhttp://www.commell.com.twUT

MS-C78 User’s Manual

-2-

I/O Shield x 1

(OPLATE-MCDLA)

(1270055)

Packing List:

Please check the package content before you starting using the board.

Hardware:

MS-C78 Micro ATX motherboard x 1

Cable Kit:

SATA Cable x 2

(OALSATA3-L)

(1040529)

Printed Matters:

Driver CD (Including User’s Manual) x 1

VGA Cable x 1

(OALVGA-S-7)

(1040556)

DB25 & DB9 cable x 1

(OAL1S1P)

(1040041)

MS-C78 User’s Manual

-3-

Index

Chapter 1 <Introduction> ............................................................................5

1.1 <Product Overview>.....................................................................................5

1.2 <Product Specification>................................................................................6

1.3 <Mechanical Drawing>.................................................................................7

1.4 <Block Diagram>..........................................................................................8

Chapter 2 <Hardware Setup>......................................................................9

2.1 <Connector Location>..................................................................................9

2.2 <Jumper Location & Reference>................................................................10

2.3 <Connector Reference>............................................................................. 11

2.3.1 <Internal Connectors> ................................................................... 11

2.3.2 <External Connectors>.................................................................. 11

2.4 <CPU and Memory Setup> ........................................................................12

2.4.1 <CPU installation>.........................................................................12

2.4.2 <Memory Setup>...........................................................................13

2.5 <CMOS & ATX Setup>...............................................................................14

2.6 <Serial ATA Interface>................................................................................15

2.7 <Ethernet Interface>...................................................................................16

2.8 <Onboard Display Interface> .....................................................................17

2.8.1 <Analog Display>...........................................................................17

2.8.2 <Digital Display>............................................................................18

2.8.3 <VGA Interface> ............................................................................22

2.9 <Integrated Audio Interface>......................................................................23

2.10 <USB Interface>.......................................................................................24

2.11 <Serial Port>.............................................................................................26

2.12 <MSATA Interface>...................................................................................29

2.13 <GPIO and SMBUS Interface>.................................................................30

2.14 <Power Supply and Fan Interface >.........................................................31

2.14.1 <Power Input> .............................................................................31

2.14.2 <Fan connector>..........................................................................32

MS-C78 User’s Manual

-4-

2.15 <Switch and Indicator>.............................................................................33

Chapter 3 <System Setup>........................................................................34

3.1 <Audio Configuration>................................................................................34

3.2 <Display Properties Setting> ......................................................................35

3.3 <SATA configuration> .................................................................................37

3.4 <SATA RAID Configuration>.......................................................................38

Chapter 4 <BIOS Setup>............................................................................40

Appendix A <I/O Port Pin Assignment>....................................................42

A.1 <Serial ATA Port> .......................................................................................42

A.2 <IrDA Port>.................................................................................................42

A.3 <LAN Port>.................................................................................................42

A.4 <Parallel Port>............................................................................................43

Appendix B <Flash BIOS>.........................................................................44

B.1 <Flash Tool>...............................................................................................44

B.2 <Flash BIOS Procedure> ...........................................................................44

Appendix C <Programming GPIO’s>........................................................45

Appendix D <Programming Watchdog Timer >.......................................46

Contact Information...................................................................................47

MS-C78 User’s Manual

-5-

Chapter 1 <Introduction>

1.1 <Product Overview>

MS-C78 the 4th Generation Intel of the Micro ATX motherboard, supports 4th Generation

Intel® Core™ i7, Core™ i5, Core™ i3, Celeron, Pentium Desktop Processor and

features Intel Q87 chipset, integrated HD Graphics, DDR3 memory, REALTEK High

Definition Audio, Serial ATAIII with RAID function for a system and Intel Gigabit LAN.

Intel Haswell Processor

The 4th Generation Intel® Core™ processor family desktop is the next generation of

64-bit, the processors are based on Intel® microarchitecture formerly known as Haswell,

manufactured on 22nm process technology with 3-D tri-gate transistors.

Features for Intel Q87 chipset

The board integrates Intel Q87 chipset, supports integrated HD Graphics, built-in high

speed mass storage interface of Serial ATAIII interface with RAID function, High

Definition Audio with 2 channels surrounding sound.

Flexible Extension Interface

The board provides, MSATA socket, Mini-PCI socket, one PCIEx16 slot and one PCIEx4

slot, and two PCI slot.

MS-C78 User’s Manual

-6-

1.2 <Product Specification>

General Specification

Form Factor Micro ATX motherboard

CPU Supports 4th Generation Intel® Core™ i7/ i5/ i3/ Celeron/ Pentium Desktop

Processor.

Package type: FCLGA1150

Memory Four DDR3/DDR3L (support 1.5V) 1333/1600 DIMM up to 32GB

Support Non-ECC, unbuffered memory only

Chipset Intel Q87 Express chipset

Real Time Clock Chipset integrated RTC with onboard lithium battery

Watchdog Timer Generates a system reset with internal timer for 1min/s ~255min/s

Power Management Supports ACPI 4.0 compliant

Serial ATA Interface Intel® Q87 PCH built-in 4 x Serial ATAIII interface up to 600MB/s Support

RAID 0, 1, 5, 10 and Intel Rapid Storage Technology.

(not support SATA II device)

VGA Interface Intel® Clear Video integrated HD Graphics Technology

DVI Interface Onboard DVI connector

LVDS Interface Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply

Display port Interface Onboard Display port connector

Audio Interface Intel® integrated Q87 with Realtek ALC888 HD Audio.

LAN Interface 1 x Intel® I210 Gigabit LAN

1 x Intel® I217-LM Gigabit LAN

GPIO interface Onboard programmable 8-bit Digital I/O interface

Extended Interface One PCIE X 16 slot & one PCIE X 4 slot, One MSATA, One Mini PCI, Two

PCI slot.

(mSATA only Support SATAIII)

Internal I/O Port 4 x RS232, 1 x GPIO port, 1 x Front panel Audio, 1 x IrDA connector,

1 x CRT, 1 x SMBUS connector, 1 x LVDS, 1 x LPC, 1 x LPT, 6 x USB2.0 and

2 x USB3.0 ports, 4 x SATAIII

External I/O Port 1 x PS/2 Keyboard/Mouse Port, 1 x RS232, 1 x RS232/422/485, 1 x DVI port,

1 x Display port, 2 x RJ45 LAN ports, 4 x USB3.0 ports and

1 x 2 Channel Audio.

Power Requirement Standard ATX 24-pin (20-pin is compatible) power supply and P4 4-pin 12V

Dimension 244mm x 244mm

Temperature Operating within 0~60 centigrade

Storage within –20~85 centigrade

Ordering Code

MS-C78 Onboard DVI, Display Port, CRT, LVDS, 2 x Gigabit LAN, USB3.0 & 2.0,

Serial Port, SATAIII, IrDA, Realtek HD Audio, Mini PCI, PCIE x16 & x4, PCI,

SMBUS, GPIO, LPC, LPT, mSATA.

The specifications may be different as the actual production.

For further product information please visit the website at TUhttp://www.commell.com.twUT

MS-C78 User’s Manual

-7-

1.3 <Mechanical Drawing>

MS-C78 User’s Manual

-8-

1.4 <Block Diagram>

Q87

W25Q128 SPI

1 x Intel I210

1 x Intel I217-LM

1 x RS232/422/485

1 x RS232 & GPIO & IrDA

& LPC & LPT

1 x PS/2

4th Generation Intel® Core™ i7,

Core™ i5, Core™ i3, Celeron,

Pentium Processor

1 x PCI Express x16

4 x 240-pin DDR3

LO-DIMM

1333/1600 MHz

up to 32GB

W83627DHG-P

1 x LVDS

4 x Serial ATAIII

6 x USB 3.0

6 x USB 2.0

1 x mSATA

1 x DVI

1 x CRT

4 x RS232

ALC888 HD Audio

F81216

1 x Display port

TSI383

2 x PCI

1 x PCI Express x4

1xminiPCI

MS-C78 User’s Manual

-9-

Chapter 2 <Hardware Setup>

2.1 <Connector Location>

PS2 USB_RJ45_1/2 Audio

DVI

Display Port

COM1+COM2

MSATA

CN_DIO

CPUFAN

CN_12V

CN_INV

CN_LPC

CN_AUDIO

COM3

CN_CRT

CN_LVDS

CN_IR CN_SMBUS

CN_USB3-1 JFRNT

SYSFAN

DDRIII_A2

ATX

S_ATA3

CN_USB2-3/2/1

COM4

COM5

COM6

PCI 3

PCIE_16X PCIE_4X

PCI 1

CN_LPT

DDRIII_B1

DDRIII_B2

DDRIII_A1

S_ATA2

S_ATA1

S_ATA4

MINIPCI
