QuickSpecs

Compaq S710 CRT Monitor

DA-10584 NorthAmerica — Version 11 — June 22, 2001

ODELS

S710 CRT Monitor (EMEA, CKK, APD and Brazil Model for Opal)(Worldwide model for Carbon color and Multi-media)

Opal Color SKUs

154499-011- Australia

154499-021 - EMEA

154499-031 - UK

154499-201- Equatorial

154499-291 - Japan

154499-A91 - Dubai Hub

154499-B23- South Africa

154499-B24 – AP

Carbon Color SKUs

154499-002 – NA

154499-012 – Australia

154499-02 - EMEA

154499-033 - UK

154499-B2 - Equatorial

154499-AA - China

154499-29 - Japan

154499-AD - Korea

154499-B2 - South Africa

Multi-Media Opal SKUs

154499-005 – NA

154499-B35 - Singapore

154499-025 - EMEA

154499-035 - UK

Note: AssetControl monitor. AssetControl features are accessible with Compaq desktops featuring Intelligent Manageability.

PECIFICATIONS

Type Color multiple scan with Invar Shadow Mask

Picture Tube (diagonal) 17-inch Flat Square

Viewable (diagonal) 16.0 inch (40.6 cm)

Horizontal Dot Pitch 0.24 mm

Trio Dot Pitch 0.28 mm

Max Refresh/Preset Graphic Modes 1600 x 1200 1280 x 1024 1024 x 768

N/A N/A/N/A 85 Hz/75 and 85 HzNote: All modes are non-interlaced unless

specified otherwise. 800 x 600 640 x 480 640 x 350

110 Hz/75, 85 Hz 125 Hz/60, 75

and 85 Hz 125 Hz/N/A

Text Mode 720 x 400

70 Hz

Mac Compatible Modes 832 x 624 1152 x 870

Note: Adapter required. 75 Hz N/A

Preset Graphic/Modes User-

Programmable 10/8

Anti-Glare/Anti-Static Yes/Yes

Plug and Play Yes

Tilt Base (up/down) 13°/5°

Swivel ±45°either side of center

QuickSpecs

Compaq S710 CRT Monitor

DA-10584 NorthAmerica — Version 11 — June 22, 2001

PECIFICATIONS

(continued)

User Controls Brightness, Contrast Yes

Size and Positioning Yes

Pincushion (barrel) Yes

Trapezoid Yes

Tilt (rotation) Yes

Color temperature (9300 K & 6500 K) Yes

Parallelogram Yes

Pincushion Balance Yes

Pinbalance Yes

Individual color control No

Moiré Cancellation Yes

Convergence No

Overscan Zoom

Serial Number Display No

Degauss Yes

Factory Reset Yes

Power Saver on/off No

AssetControl Yes

Note: When used with Compaq Intelligent Manageability CPUs and appropriate network software.

Approvals/Certifications UL Approval Yes

ISO9241-3, ISO9241-7, ISO9241-8 VDT Guidelines Approval Yes

MPR-II Compliant Yes

FCC Approval Yes

Energy Star Compliant Yes

TCO 99 Compliant Yes (Opal Color Versions)

TCO’95 Compliant Yes (Carbon Color Versions)

On-Screen Controls Yes

Language Selection German Yes

English Yes

Spanish Yes

Italian Yes

Swedish Yes

Portuguese Yes

French Yes

Russian Yes

Korean Yes

QuickSpecs

Compaq S710 CRT Monitor

DA-10584 NorthAmerica — Version 11 — June 22, 2001

PECIFICATIONS

(continued)

USB Capabilities With optional adapter (138638-xxx)

Pixel Clock Speed 110 MHz

Input Impedance 75 ohms

Horizontal Frequency 30 to 70 kHz

Vertical Frequency 50 to 125 Hz

Power Supply ALS 90 to 127 & 195 to 265 VAC, 47.5 to 63 Hz Universal Auto-Sensing

Maximum Power Rating 90 W

Power Consumption (Suspend/Sleep) < 15W/< 3W

Synchronized Input TTL separate synchronized

Signal Cable 15-pin miniature D-sub

Dimensions (HxWxD) 16.3 x 16.2 x 16. 5 in/41.5 x 41.2 x 42.0 cm

Weight 33 lbs/15.0 kg

Operating Humidity (non-condensing) 20% to 80%

Operating Temperature 10°to 40°C

48 Hour Direct Replacement If for any reason this monitor fails during the parts warranty, Compaq guarantees that a new or like-new monitor

replacement will be in the hands of the user within 48 hours.

Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Service Support Center for details.

Warranty Three-year; First year, parts, labor, and on-site repair, Second and Third years, parts only

Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Service Support Center for details.

QuickSpecs

Compaq S710 CRT Monitor

DA-10584 NorthAmerica — Version 11 — June 22, 2001

OMPAQ

M710 S

PEAKER

PECIFICATIONS

Sound Output 3.0 Watts per channel 4.3 Watts maximum @10% THD

Signal to Noise Ratio 50 dB

Speaker Impedance 4 ohm

Frequency Response f0Hz to15Hz

Power DC 12V Cord

OMPATIBILITY

Portables Compaq Armada™ 7800

Compaq Armada 7400

Compaq Armada 6500

Compaq Armada 3500

Compaq Armada 1750

Compaq Armada 1700

Compaq Armada 1500c

Desktops Compaq Deskpro™ EN Series Desktop

Compaq Deskpro EN Series Minitower

Compaq Deskpro EN Series Small Form Factor

Compaq Deskpro EP Series

Workstations Compaq Professional Workstation XP1000

Compaq Professional Workstation AP500

Servers Compaq ProLiant™ 7000 Xeon™

Compaq ProLiant 6500 Xeon

Compaq ProLiant 6000 Xeon

Compaq ProLiant 5500 Xeon

Compaq ProLiant 3000 Pentium

III

Compaq ProLiant 3000 6/450

Compaq ProLiant 1600 6/500

Compaq ProLiant 1600 (100-MHz)

Compaq ProLiant 800 (500-MHz)

SMB Compaq Prosignia™ Notebook Family of Personal Computers

Compaq Prosignia Desktop Family of Personal Computers

Compaq Prosignia 740

Compaq Prosignia 720

Compaq, registered United States Patent and Trademark Office.

Other product names mentioned herein may be trademarks and/or registered trademarks of their

respective companies.
