Assembly Instructions
Core Stand SKU: 111B/111W
IN THE BOX
©
Compulocks Brands Inc. All Rights Reserved.j
www.compulocks.com | online@maclocks.com | +1 800-948-0344 Sheet 1 of 1
0.26in
6.7mm
0.33in
8.3mm
0.26in
6.7mm
2.86in
72.5mm
1.40in
35.5mm
Fixed Stand Plastic cover M4x8MM Phillips Screws
PLEASE USE M6 SCREWS
WIRE INLET
LOCK SLOTS
LOCATE YOUR STAND
AND MOUNT IT
INSTALL STAND COVER
MOUNTING SCREWS
NOT PROVIDED
COUNTER MOUNTING PATTERN
INSTALL YOUR TABLET
ENCLOSURE AS SHOWN
USING M4 SCREWS
PROVIDED
4 5 6
321
Assembly Instructions
Swell
IN THE BOX
©
Compulocks Brands Inc. All Rights Reserved.j
www.compulocks.com | online@maclocks.com | +1 800-948-0344 Sheet 1 of 1
Mounting options Or
WALL
FOLLOW STAND
MOUNTING INSTRUCTIONS
(SUPPLIED WITH STANDS)
Torx Screwdriver M3x10mm tamper proof screws Swell enclosure
WALL MOUNTING
(SCREWS NOT PROVIDED)
Secure with
M3 screws (provided)
