Cornelius Pro Fast Gate IDC255 Manuale utente

FEATURES:

idc255 PRo FAST gATE™

Post-Mix ice drink disPenser

CG5018-1111 ICE & BEvEragE

• Improves service efﬁciency and speed by creating

a standard lid-dispense height with bottom

dispense design

• New lid dispenser and large capacity straw holder

feature no moving parts and an ergonomic design

that is easy to access, remove, and clean.

• Increases comfort and reduces workplace injuries

with an ergonomically-designed center-mounted

control panel, and larger, more durable buttons

• Improved ice portion control system with redesigned

pro fast gate, LED feedback, and easy entry/exit from

program mode

• Easy access to valves and other components

• 255 lb. ice capacity

• Increased serviceability:

– Requires only 1 electrical outlet

– Easy front access to carbonator tank

– Simple motor removal

• New and improved Total Flex2TM easily changes from

carbonated to non-carbonated

For more information or to place an order, contact your sales representative or authorized distributor.

OUTSIDE THE U.S.A.

Ph: 763.488.8200

Email: [email protected]

IN THE U.S.A.

Ph: 800.238.3600

Fax: 800.258.0255

101 Broadway Street West

Osseo, MN 55369

www.cornelius.com

9”

8.625”

39.75"

30"

20.756"

36.901"

NotE: PumP & motor assEmBly

must BE PosItIoNEd wIthIN

8 fEEt of thE dIsPENsEr

29.875"

TYPE OF VALVES. . . . . . . . . . . . . . Optiﬁll™ 2-4 oz/sec

post-mix

NUMBER OF VALVES . . . . . . . . . . 8

BEVERAGE MANIFOLDING . . . . . 3-1-1-3

CUP CLEARANCE . . . . . . . . . . . . . 8"

ICE STORAGE CAPACITY . . . . . . . 255 lb (115.7 kg)

CONNECTIONS . . . . . . . . . . . . . . . Water: 0.375" (9.5 mm)

Syrup: 0.375" (9.5 mm)

DRAIN SIZE . . . . . . . . . . . . . . . . . . 0.75" (19.1 mm) pvc (npt)

pipe or ﬂexible tubing

ELECTRICAL REQUIREMENTS . . 120 V / 60 Hz / 9.3 Amps

SHIPPING WEIGHT . . . . . . . . . . . . 350 lb (150 kg)

AGENCY LISTINGS . . . . . . . . . . . .

City of New York

City of Los Angeles

Part NumBEr dEsCrIPtIoN

621057404 IDC255 Pro Fast Gate beverage dispenser with 8 UFB-1™ 2-4 oz OptiFill™ valves

and side splash guards

TEcHNicAL SPEciFicATioNS:
