Createbot MAX Manuale utente

MAX3D Printer

Tel:0086-574-88037579

Scanning for more online Support

Instruction

Mini Packing List

MAX3D Printerx1

The items listed below are all the accessories in the box.Please check the items

before using

PLA Filament1kgx1

Door Plate x4 Filameant Support x1 or 2

Glass Platform(282x270mm)x1 Bladex1

Door Handlex1

Power Supply x1

USB Cablex1

SD Cardx1

Card Readerx1

Wrenchx3

(1.5/2/2.5)

Plastic Partsx2

Thumb screw(M3X6)x8

Screw (M4x6)x10

Circular magnets(12*6*1)x1

Bucklex8

Tweezersx1

Appearance Introduction

SD Slot

Touch Screen Printing Platform

Extruder

Load the filament

First fixed filament holder in the machine on the right side of the holder hole with four hand

screw screws , put the filament on the holder,insert filament from feed port of nozzle through

the white feed tube,stop insert until feel the resistance

White Pipe

Scroll

Feed port

Fliament Support 3

Operartion Guide

Step1

Taking out the three door plate,fix the left and right door plate on the printer with M4x6

screw.Then assemble the plastic parts and door handle with the M4x6 screw on front of the

printer.

Step2

First press the TOOL button into the tool menu then PREHEAT button you can see on

the picture 3

Turn on the Printer

Insert the power cable into the 220V power connector on the back of the machine and insert

the power cable into the wall power connector. Press the front round metal button on the

machine and hear the “di” sound. The display shows the startup interface, indicating that the

3D printer is normal start up.

22V Power Input

Power Cable

Home Page Preheat Menu

Light Button

Tool Button

Click “TOOL”, then choose “FILAMENT” and click “DOWN” to extrude the filament. If it is

extruded normally and smoothly, click “Stop” to finish it and click “BACK” to return to home

page.

Extruding Test

Step3

。

Step4

Clip of the glass platform 5

Well assembled

Direction of insert

Take out the glass platform from the box of accessories. Then push it until it reaches to the end of heated

bed. Finally, fix it with the glass clip in front of heated bed. (Please note: after installing the glass platform,

click “TOOL” and choose “LEVEL” to level the platform. Adjust the distance between nozzle and platform

to the thickness of one A4 paper by rotating the corresponding screw under the platform.)

Tool Menu Load and unload the filament

Step5

In the print home page, click the print icon, enter the print interface, open (openSD) icon,

open the SD card file interface, choose the 001 testing model ,then the printer will start

printing.

Printing Test

Now,you can already use createbot 3d printer,there are many interesting models on the website

WWW.China3Dprinter.cn for your download,besides you can also print any 3d models design by

yourself,createbot slice software support OBJ, STL, AMF and other formats of three-dimensional

model,the steps of install slice software as follows:

Slicing Software Installation

Copy the slicing software file from the SD card into your comoputer and Open the installer

Slicing Software

The software will insatll the drive automatically,click next to finish the installation

Select the path where the slice software is installed, then click Next, click

Install, the softwarewill automatically instaledl until finished

After the software is installed automatically, you will see the interface below, click the

Finish button, end the slice software installation.

The parameter settings for first run the

slice software

Open the slice software,select language,choose the model of the printer you purchased(such

as the purchase MINI, please select MINI), then click Next to complete the configuration.

Recommended using the following parameters to printing your models,you also can adjust

the parameters for your needs.


Note:

When selecting a support type, it is possible to determine whether it is

necessary to add partial support or entire support or without support by

observing the model or slice interface. But in principle it is better to avoid

support or reduce support.Rotate model can be used to avoid or reduce the

purpose.

When selecting the type of platform attachment, the edge or grid can

be appropriately added according to the size of the land area and the height

of the model.

Single Extruder

Dual Extruder
