CrimeStopper SP-500 Manuale utente

SP-500

2-WayLCD Paging Alarm& RemoteEngineStartingSystem

OPERATING INSTRUCTIONS

INTRODUCTION

CONGRATULATIONS onyourchoice of theSP-500 by Crimestopper Security Products Inc. Thisbooklet containsthe

informationnecessary for operatingyoursystem. If anyquestionsarise, contactyourinstallationdealer or

Crimestopper Security Products Inc.

*IMPORTANT INFORMATION: Primary and Optional Features

-PRIMARY: These features must beconnectedinorder forthesystem tooperateproperlyi.e. Power, Ground, LED,

etc.

-OPTIONAL: Optionalfeatures areconnected onlyifdesired or agreed uponby theinstallingdealer i.e. HornHonk,

Dome lightillumination,Door Locks, Trunk Pop, etc. These features mayrequire additionalparts andlabor charges.

Consult withyour installer about these features BEFORE installation!

CONTACTINFORMATION:

TECHNICAL SUPPORT(800)-998-6880

Monday- Friday8:00am- 4:30pmPacific

Website: www.crimestopper.com

CRIMESTOPPER

SECURITYPRODUCTS, INC.

1770 S. TAPO STREET

SIMI VALLEY, CA.93063 REV 12.2008

ThisdevicecomplieswithFCC Rulespart15.Operation issubject

tothe followingtwoconditions:1)Thisdevicemaynotcause

interference,and (2)thisdevicemustacceptanyinterferencethat

maybe received,including interferencethatmaycauseundesired

operation.The manufacturerisnotresponsibleforanyradioorTV

interferencecausedbyunauthorized modification tothis

equipment. Suchmodification couldvoidtheuser'sauthorityto

operatethe equipment.

TABLEOF CONTENTS

OperationCautions&Warnings……..…………..……………………………………………………………………2

TheRemoteControls……………….....…………..……………………………………………………………….…3-4

SettingtheClock………………...………………………….…………………………………………………..…...…..4

Quick ChartButtonFunctions...………………………….…………………………………………………..…...…..5

OperatingInstructions-Alarm……………………………………………………….………..……………..……..6-9

RemoteEngineControl………………………...……………………………………………….……………..….10-13

Anti-CarjackProtection...……………………………………….………….……..………………..………..………..14

LEDandRemoteStartDiagnostics………………..……………………………………………….………..….…15

Transceiver/ Remote Control Programming……………………………………………………..…………….…16

2VehicleOperation……...………………………….……………………………….………….…………….….……17

TURBOTimerMode…………….……………….…………………………………………………………..……..18-19

BatteryReplacement……………….……………………..………….….…………………………………………….20

OPERATIONCAUTIONS&WARNINGS

CRIMESTOPPERSECURITYPRODUCTS,INC. andits VENDORS shallnotbeliablefor anyaccident

resulting fromthe useofthisequipment. Thissystemisdesignedtobeprofessionallyinstalledintoacar or

vehicleingoodrunning order.Items,suchasparkingbrake,door switches,andallenginesafetyfeatures,

mustbeinperfectworkingcondition.

DAMAGEresulting frommisuseornegligenceisNOTcoveredunderwarranty and will be subjectto

repairand/ or replacementcharges.

ITISABSOLUTELYTHEOWNER’SSOLERESPONSIBILITYTO: A)Understandthe operationofthis

systemanditssafetyfeatures.B)Checkforproperoperationofthesesafetyfeaturespriortoaccepting

deliveryofthevehiclefromtheinstallation facility.C)Checkandmaintainthecondition ofthe vehicleandall

itemsrelativetotheproperoperationofthissystemanditssafetyfeatures.

DO NOTremotestartthevehicleinaclosedgarage. Makesurethat the vehicleisoutdoors, agarage door

isopen,orthereisadequateexhaustventilation.Failuretoobservethisrulecouldresultin injuryordeath

frompoisonousCarbon Monoxidefumes.Thisisespeciallyimportantwhen using theTimed Self-Startfeature

of theunit

THEREMOTECONTROLS

2-WAY-PAGER/ REMOTETRANSCEIVER:1-WAY-SIDEKICK REMOTE:

START/ AUX2

2ndFUNCTION

VEH1/ VEH2

CLOCK SET

TRUNK

ARM/

LOCK DISARM/

UNLOCK

12:00

START TRUNK

ARM /

LOCK

DISARM/

UNLOCK

2nd FUNCTION

VEH 1/VEH 2

THEREMOTECONTROLS

1-WAY-SIDEKICKREMOTE:

The 1-Waysidekickremoteaddsflexibilitytoyoursystem.Youcanhavetheconvenienceofoperatingyour

systemwithoutneedingtocarrythelarger pager remote.The Sidekickremotehasless range and offersall of

the sameoperation featuresexceptforpage-backconfirmation.The 1-WaySidekickRemoteusestwoCR-

2016Lithium3VoltBatteries.

2-WAY-PAGER/ REMOTETRANSCEIVER:

The 2-Wayhand-heldremotetransceiver isusedtosendandreceiveinformationfromthe vehicle.The

ControlModuletransmitsHighFrequencyFMsignalsfromthevehicletoyourpager overlong distances.Your

range will varydependingonlocation,terrain,andlocalRFnoise/interference.Thissystemisnotguaranteed

topageyouifyouarebehindconcretewalls,underground,inalargestructure,orinanareawithhigh levels

ofelectronicinterference.Handlethe pager/remotewithcare.The LCD displayand/orthe electronics maybe

damaged ifsubjectedtoabuse.TheAAA Cell 1.5Valkalinebatterycaneasilybe replaced bysliding openthe

batteryaccess dooronthebackofthe remote.Batterylifewill varydepending onusage.TheLCD screen

will displayalowbatteryiconwhenthebatteryislow.

SETTINGTHECLOCK (2-WAY- LCD REMOTE)

1.Press VEHButton on thesideoftheremotecontrol5times.

2.The remotewill beepandthe AMorPM displaywill beginflashing.

3.Press theTrunkButtontogotothenext item –AM-PM-Hour-Minutes.

4.Press theLockButtonto increase time.

5.Press theUnlockButtonto decrease time.

6.Press theStart Buttonto DisableorEnableBeep.

7.Press theVEHButtonto ExitSetup orwait 7seconds, the LCD light will turn off.

QUICK CHART BUTTONFUNCTIONS

Button Button

Functions Button Options Button Button

Functions Button Options

Lock Doors &Arm

System

Press andHold2

Seconds forPanic

Mode 2ndFunction

Press and Holdfor2

seconds

Unlock Doors&

DisarmSystem Press twicefor

seconddoorunlock

VEH

Selects between

Vehicle#1 and

Vehicle#2

Press and Holdfor2

seconds

Trunk Pop

Aux#1

PressandRelease

forTrunkPop Aux#1

Valet Service/ Park

Sensor ON/ Off

Valet Modewhen

Disarmed.Sensor

On/Off whenArmed

StartorStopengine Press forRemote

Start. Threeoptions

available

ActivatesCarJack

withIgnitionOn

Press and Hold2

SecondsforCarJack

Mode

Activates

Aux#2

SteadyMomentary

Output Activates

Aux#2

SteadyMomentary

Output

Activates

Aux#3

Momentary, Timed or

LatchedOutput Activates

Aux#3

Momentary, Timed

orLatchedOutput

NoFunction NoFunction Silent Arm/ Disarm NoArm/Disarm

ChripfromSirenor

Horn

Activates

Aux#4

Momentary, Timed or

LatchedOutput Activates

Aux#4

Momentary, Timed

orLatchedOutput

CLOCKSETUP:

Lock =Increase, Unlock= Decrease, Trunk= Next,Start= Beep withbuttonpress, VEH=Exit

Then

Plus

Then

Plus

Then

Plus

Then

Plus

OPERATINGINSTRUCTIONS-ALARM

Arming / Locking:

Press theLock Buttonontheremote control.TheSystem will arm emitonesirenchirp, onelightflash,andtheLED

willbeginto flash.Powerlocks willlock (ifequipped). Starter disablecircuitwillturnon. The2-Way LCD Pager will

beep once whiledisplayingaLockingsymbol.After ashort delay to allow thevehicleandelectronics to settle, the

system willbe completely armed.

Disarming:/ Unlocking

Press theUnlock Buttonontheremote control.TheSystem will disarm andconfirm withtwo sirenchirps, two light

flashes, andtheLED willturnoff. Powerlocks willunlock andInterior Dome lightwillturnon(ifinstalled withthese

optionalfeatures). The 2-Way LCD Pager willbeep twice while displaying anUnlock symbol.

Alarm Triggers:

If there isanintrusioninto thevehicle, ahard impact to thebody or theignitionisturned on,thealarm willsoundand

flashthelights for 1minute.After 1minute,thetrigger cyclewill automaticallystop andalarm willremainarmedto

continueprotectingthevehicle. If a door isleft openafter anintrusion thentheunitwill cycleamaximumof 2minutes

and continue to protect the other un-tampered or unopenedzones.

LCD Remote Paging/ ZoneViolations:

Whenthe system is triggered, the alarm sends a paging signalto the remote. If you are withinrange, youwillreceive

a paging signalthat willlightup the LCD Screen Red. The display willshow aniconof what caused the violation. The

paging remote willalso vibrate and beeptonotify you the vehicle has beentampered with.

Disarming WhileTripped(Triggered):

Disarmingthe Systemwhileitistriggering requiresTWOpressesofthe Unlock Button.The firstpress Resets

the alarmcycleonly(systemstill armed)whileasecondpress will disarm/unlockthe system.

Selective SilentArming / Disarming:

ToArmorDisarmthesystemwithoutsirenchirps,pressand releaseboththeUnlockandStartButtonatthe

sametime.TheSystemwill Armor Disarmwithoutsiren chirps.FlashinglightsandLEDwill be theonly

indicatorsofArm/Disarmstatus.The LCD will Displayamusicalnotewithan “Ø”when the systemisarmed or

disarmedwithoutachirp

OPERATINGINSTRUCTIONS-ALARM

PriorintrusionAlert

Thissystemwill notifyyouifthealarmwastriggeredwhileyouwereaway.Upon disarming,there will befour

additionalsiren chirpsafterthetwonormaldisarmchirps.Checkyour vehicleforanysignsofabreakinor

tampering. Also, seeLEDDiagnostics (page 15)todetermine thecauseof thetrigger.

RemotePanicProtection

Tosoundthealarminan emergencysituation ortodrawattention toyour vehicle,press and holdthe Lock

button for atleast3secondsuntil thesiren /horn sounds.Press the Unlockbuttontoresetpanicmode.The

LCD displaywill flashmost oftheiconsandemit10 beepswhenthe PanicMode istriggered.

Selective Shock SensorDisable

Toarmthe alarmandbypass shocksensor protection,presstheLockButton asnormalthenpress and

releasetheLock&UnlockButton togetherwithin2seconds.Youwill hear 3extrasirenchirpsindicating the

shocksensor bypass for thisarming cycleonly.Thisisfeature usefulwhenparking nearrailroadtracks,

airports,orareaswithexcessiveloudmachineryor noisetopreventthenuisanceofunnecessaryfalse

alarms.

OpenDoorAlert/ Bypass

Upon arming,thissystemwill warn you 60 secondslaterifadoor isleft open.The LCD pagerwill vibrateand

beep(5X’s)along withdisplayingthe openzoneonyour LCD screen.Thiszonewill bebypasseduntil the

doorisclosed;otherwise, thealarmwillcontinuetoprotectall otherzones.

Pre-WarningShock Protection

The Pre-Warning (Warn-A-Way)featurewill activatewhenalow-levelshockor vibration isdetected bythe

system’sshocksensor.The alarmwill chirp the siren 5timesandflashthelightsoncetohelpdeterany

furthertampering withthevehicle.Thepager/ remotewill beepand showaHammer Icon.

Passive ArmingMode:(Programmable)

Passive(automatic)Armingoccurs30 secondsafterthe ignition isturned off andthelastdoor isclosed.

Uponclosingthelastdoor,theunitwill flashthelightstwiceand LEDwillbeflashingrapidlytoconfirmpassive

countdown.Ifadoorisreopenedwithinthe30-secondperiod,thecountdownstopsandbeginsagainwhen

the door isclosed.Passivearmingprovidesfailsafeprotectionincaseyouforget toarmthesystem.

OPERATINGINSTRUCTIONS-ALARM

Passive Locking:(Programmable)

The systemcan beprogrammed topassivelylockthe doorswhen the systempassivelyarms.The default

settingisOFFbecausepassivelockingincreasestheriskoflocking the keysinthe vehiclewhenthesystem

arms/lockspassively,withoutyoupressing the remote.

Trunk/HatchPop(Optional, Remote AUX.Output1)

Thisfeatureisdesigned tointerfacewithexisting Factorypower trunkor power hatchreleasesystemsand

mayrequire additionalpartsand/orlaborcharges.Toeliminatethepossibilityofaccidentallyopeningthe

trunk,there are (3) optionsfor button press selection.Thisoptionwill allowyou tochange whether theRemote

starter andTrunkreleaseactivatebya:

1.Doublebutton ½secondpresses.

2.Single½second press.

3.Press andHold2seconds.

*Default=Single½secondpress*

RemoteAUX.Output2(Optional, Requires specialprogramming)

Thissystemcontainsa2

nd Auxiliaryoutputtoactivateotheraccessoriesor devices.Toactivatethe2

Auxiliaryoutput, press the Unlockand Trunkbuttonformorethan2seconds. Thismomentaryoutputwill stay

activeaslongastheremotebuttonishelddown. ThereisnoLCD / Pager confirmationforAux. 2output.

RemoteAUX.Output3(Optional, Requires specialprogramming)

Thissystemcontainsa3

rd Auxiliaryoutputtoactivateother accessoriesordevices.Thisoutputis

programmablefor amomentary,timedor Latchoutput. There are 2waystocontrolthisoutput. Toactivatethe

Third AuxiliaryOutput:

1.Press the2nd Functionbutton,thanpress theTrunkbutton onthetransmitter.

2.Press theLockand KeyButtonat the sametime.

RemoteAUX.Output4(Optional, Requires specialprogramming)

Thissystemcontainsa4

th Auxiliaryoutputtoactivateotheraccessoriesordevices.Thisoutputis

programmablefor amomentary,timedor Latchoutput. There are 2waystocontrolthisoutput. Toactivatethe

ForthAuxiliaryOutput:

1.Press the2nd Functionbutton,thanpress theLockbuttononthetransmitter.

2.Press theTrunkand Start Buttonatthe sametime.

OPERATINGINSTRUCTIONS-ALARM

DomeLightIllumination (Optional)

Thisfeaturewill turnonthe vehicle’sdomelightupondisarmingfor30secondsoruntil the keyisinsertedand

turnedon. Thiswill provide illuminated entrytoyour vehicleindimlylitareasforsafetyandsecurity.

EmergencyOverride(Disarm)

Ifyou havelostthetransmitter or itstopsworking for anyreason andtheAlarmisarmed,youwill haveto

disarmthe systemmanually.Open thedoorwiththekey[alarmwill sound], turn the ignitionon,and press the

override/programbutton for about5seconds.TheAlarmwill disarmand allowyoutousethe vehicleuntil you

can repair/replacethe remote. ValetmodealsopreventsPassiveArming.

ValetMode(Entermanuallyorusing theremote)

TodisableAlarmand RemoteEngineStarting for vehicleservicing the alarmsystemmustbedisarmed. To

ActivateValetMode: Turn theignitiononandpresstheoverride/programbutton [about5-6seconds]until

youhear (3)siren chirpsand theLEDturnsonsolid.Repeat theprocess toexit VALETmode.Toenter /exit

Valetviathe remote,press and holdboththe LockandUnlockButton togetherfor about3secondsuntil 3

chirpsareheard.Repeatthissteptoexitviatheremotetransmitter.Lock/Unlockand AUXfeatureswill still

operateinVALETModehowever,RemoteStartand Alarmfunctionsareinhibited.

ValetParkMode(Using theremotetransmitteronly)

ValetParkMode allowsyou toturnover the vehicletoaValetallowingaccesstodrive/lock/unlockyour

vehicle,butalarmwill triggerifthe trunkisopened. To ActivateValetPark: The alarmsystemmustbe

disarmed.Press andholdboththe Lockand Unlockbuttonstogetherfor about3seconds,3chirpswill be

heard firstwhen unitgoesintoregularValet. Release,press andholdbothbuttonsagain,youwill hear2more

chirps.The LEDwill alwaysflashslowlywhen inValetParkevenwhentheIgnition isturned on (or driving

vehicle).Repeat step abovetoexit Valet ParkMode.

Note:Valet Parkmode isonlyaccessiblewhen usingthe remotetransmitter

REMO REMOTEENGINECONTROLTEENGINECONTROL

RemoteStart&AuxiliaryOutput–ButtonPressSelection(Option#8):

Toeliminatethepossibilityofaccidentallyopening the trunkor startingthevehicle,thereare (3)optionsfor

button press selection.Thisoptionwillallowyoutochange whether the Remotestarter andTrunkrelease

activatebya:

4.Doublebutton ½secondpresses.

5.Single½second press.

6.Press andHold2seconds.

*Default=Single½secondpress*

REMOTEENGINESTARTING -SUCCESSFULSTART

1)Press remotestartbuttonontheremotetransmitter.Systemwill chirp 3timesfor audibleconfirmation.

(Chirpscan be programmed on or off-See installationmanual.)

2)Parking lightsflashonce,then turnonsolid,Ignition/Accessorycircuitsturnon.

3)After afewseconds,StarterMotor engages, Parking lightsandAccessorycircuitsturnoffwhilecranking.

4)EngineStartsandRuns. Parking LightsandAccessoryturnbackon, DoorsLock.

5)Enginewill remainrunningfor programmed run timeuntil resetwithBrakepedal.Ifneeded,theenginecan

be turnedoffwithremotetransmitter.

REMOTEENGINESTARTING –LCDPAGER-REMOTE:

When requestingaremotestart the LCDpagerremotewill confirmwithanIgnition Iconalongwith3beeps.

Oncethevehiclehassuccessfullystarted theremotewill confirmbackwith1vibration, amovingvehicleIcon,

and6beeps.

AFTER

IGN

STARTER

THEN

FLASH1X

SOLID

SEC.

PRESS START

Altri manuali per SP-500

Indice

Altri manuali CrimeStopper Avviamento remoto

CrimeStopper

CrimeStopper Ezee Start EZ-90 Manuale utente

CrimeStopper

CrimeStopper Cool Start RS-1300DP Manuale utente

CrimeStopper

CrimeStopper CS-865RKE II Series Manuale

CrimeStopper

CrimeStopper Ezee Start EZ-777 FM Manuale utente

CrimeStopper

CrimeStopper EZEE Start EZ-45DP Manuale utente

CrimeStopper

CrimeStopper CoolStart RS900ER Manuale utente

CrimeStopper

CrimeStopper RS800ER Manuale utente

CrimeStopper

CrimeStopper REVO-1 Series Manuale utente

CrimeStopper

CrimeStopper CS-865RKE II Series Manuale

CrimeStopper

CrimeStopper CS-845RKE Series II Manuale

CrimeStopper

CrimeStopper Cool Start RS-850 Manuale utente

CrimeStopper

CrimeStopper Infinity CS-2900DP-FM Manuale utente

CrimeStopper

CrimeStopper CS-9704 Manuale utente

CrimeStopper

CrimeStopper RS-999TW1/TW2 Manuale utente

CrimeStopper

CrimeStopper EZEE Start EZ-1 Manuale utente

CrimeStopper

CrimeStopper CS-870RKE Manuale utente

CrimeStopper

CrimeStopper EZ-45DP/55DP Manuale utente

CrimeStopper

CrimeStopper RS-800 Manuale utente

CrimeStopper

CrimeStopper cool start RS2-G3 Manuale utente

CrimeStopper

CrimeStopper EZEE Start EZ-3 Manuale utente

CrimeStopper

CrimeStopper Cool Start RS-1405DP Manuale utente

CrimeStopper

CrimeStopper CS-830RKE Manuale utente

CrimeStopper

CrimeStopper Cool Start RS-1405DP Manuale utente

CrimeStopper

CrimeStopper Cool Start RS-1300DP Manuale utente

Manuali Avviamento remoto popolari di altre marche

AstroStart

AstroStart 803U Manuale utente

Durite

Durite 0-649-20 Manuale

EINHELL

EINHELL BT-PS 1000 Manuale

Linear

Linear ACCESS AK-21 Specifiche tecniche

Soundstream

Soundstream TARANTULA RS.2 Manuale utente

Jaycar Electronics

Jaycar Electronics MB3752 Manuale utente

Ultra Start

Ultra Start 72 Series Manuale utente

ADS

ADS FLASHLOGIC FLRSVW1 Manuale utente

Selecta

Selecta JS012 Manuale utente

Black Widow Security

Black Widow Security BW RAS 400 Manuale utente

Vector

Vector Power City DK080706 Supplemento

Code Alarm

Code Alarm CA-535 Manuale utente

Ozito

Ozito OJS-800 Manuale utente

Profi-Partner

Profi-Partner 46387 Manuale utente

EZ STARTER

EZ STARTER EZ-45 Manuale utente

Viper

Viper 4204 Manuale utente

Essex Electronics

Essex Electronics KE-1701 Manuale utente

EINHELL

EINHELL EGS 3600 Manuale
