100BASE-FX to

100BASE-FX

Media Converter

User’s Guide

Rev. 01 (JUN. 2002)

1907M120SC26000

wan

RECYCLABLE

TABLE OF CONTENTS

TABLE OF CONTENTS......2

INTRODUCTION.................3

ABOUT MEDIA CONVERTER ......................... 3

PRODUCT FEATURES ................................... 3

INSTALLATION ..................3

SELECTING A SITE FOR THE EQUIPMENT ....... 3

CONNECTING TO POWER ............................. 4

INSTALLING IN A CHASSIS ............................ 4

LED INDICATOR ........................................... 5

SPECIFICATIONS .................6

RECYCLABLE

Rev. 01 (Jan. 2002)

6012-9600133

1907M120SC16001

Printed In Taiwan

INTRODUCTION

Thank you for choosing the 100Base Fast Ethernet

Media Converter, The Converter introduced here

provides one channel media conversion between

100BASE-FX and 100BASE-FX.

About Media Converter

Media Converter is a network technology specified by

IEEE 802.3u 100BASE-FX standards.

Product Features

yOne-channel media conversion between

100BASE-FX and 100BASE-FX

yFiber media allows: multi-mode fiber and

single-mode fiber using SC connector

yFull wire-speed forwarding rate

yFront panel status LEDs

yUsed as a stand-alone device or with a chassis

yHot-swappable when used with a chassis

INSTALLATION

This chapter gives step-by-step installation instructions

for the Converter.

Selecting a Site for the Equipment

As with any electric device, you should place the

equipment where it will not be subjected to extreme

temperatures, humidity, or electromagnetic interference.

Specifically, the site you select should meet the

following requirements:

1. The ambient temperature should be between 32

and 104 degrees Fahrenheit (0 to 40 degrees

Celsius).

2. The relative humidity should be less than 90

percent, non-condensing.

3. Surrounding electrical devices should not exceed

the electromagnetic field (RFC) standards for

IEC 801-3, Level 2 (3V/M) field strength.

4. Make sure that the equipment receives adequate

ventilation. Do not block the ventilation holes on

each side of the switch or the fan exhaust port on

the side or rear of the equipment.

5. The power outlet should be within 1.8 meters of

the switch.

Connecting to Power

1. This Converter is a plug-and-play device.

2. Connect the supplied AC to DC power adaptor

with a power voltage of 7.5Vdc/1.5Amp to the

DC-Jack on the converter, and then attach the

plug into a standard AC outlet.

Installing in a Chassis

The Converter can be fit into any of the expansion slots

on a special designed chassis.

yFirst, install the converter onto a carrier supplied with

the chassis:

Step 1- Unscrew and pull out the media converter

board.

Step 2- Plug in the media board to any of the vacant

slot.

Step 3- Fit the converter onto the carrier and use the

screw to secure it.

LED Indicator

The LED indicators give you instant feedback on status

of the converter:

SPECIFICATIONS

Standards: IEEE802.3u 100BASE-FX

Data Transfer Rate: 148800pps for 100Mbps

Duplex Mode: Full Duplex Mode

LED indicators: PWR, LINK-1, LINK-2

Media Interface: SC

EMI Compatiblity: FCC Class B

CE Certification, Class B

VCCI Class B

Temperture: Storage: -10°C ~ 70°C

Operating: 0°C ~ 40°C

Humidity: 10% ~90% non-condensing

Power Consumption: 0.6 Watts (maximum)

LEDs State Indication

Steady Power onPower

(PWR) Lights off Power off

Lights on Linking on port

FX-1

LINK-1

Lights off Not Linking

Lights on Linking on port

FX-2

LINK-2

Lights off Not Linking
