D-Link QuickMedia DFB-H7 Manuale utente

DFB-H7

USB 2.0/ FireWire

Combo Hub

Other D-Link products that

work with the DFB-H7:

DUB-A2

2-Port USB 2.0

PCI Adapter

DFB-A5

USB 2.0/ FireWire

Combo Adapter

DU-520

5-Port USB 2.0

PCI Adapter

Four Hi-Speed USB

2.0 Ports

The DFB-H7 expands your connectivity options

with four additional Hi-Speed USB 2.0

ports, allowing you to connect more digital

media peripherals to your computer and transfer

media-rich content at rates up to 480Mbps.1

Two IEEE 1394 FireWire Ports Connect digital video camcorders, external

hard drives, scanners, printers, or other

multimedia devices using the DFB-H7’s two

FireWire ports to deliver up to 400Mbps of

digital media to your computer.

Backward Compatible

with USB 1.0/1.1 Devices

The DFB-H7 is backward compatible with

all of your existing USB 1.0/1.1 products.

This means that you don’t have to replace the

USB 1.0/1.1 products you already have. Simply

connect your USB 2.0 and USB 1.0/1.1

products to the DFB-H7. Each device will

perform at its fastest speed automatically.

Plug & Play With Plug & Play installation, the DFB-H7 is

easy to install. There are no drivers to worry

about and no software to install. Simply

plug the DFB-H7 into an available USB and

FireWire port on your computer and you are

ready to go.

Compatible with Both

Microsoft Windows

and Macintosh OS X

The DFB-H7 is both PC and Mac compatible,

which makes it easy to integrate with your

existing home or ofﬁce environment.

1 Maximum transfer rate based on USB 2.0 speciﬁcation. Actual data throughput will vary.

D-Link Systems, Inc. 17595 Mt. Herrmann Fountain Valley CA92708-4160 www.dlink.com

Other trademarks or registered trademarks are the property of their respective manufacturers or owners.

Price and specifications are subject to changes without notice. See inside package for warranty details.

* 24/7 Tech Support is available only in USA.

USB 2.0 /FireWire

Per Port

LED Indicator

Two IEEE 1394

FireWire Ports

Four USB 2.0 Ports

Power LED

One FireWire Upstream Port

Connects to a Host

Computer or Hub One Type B

Port Connects to a

Host Computer or Hub

Power Receptor

DFB-H7

Product Information

Part No: DFB-H7

Description: USB 2.0/

FireWire Combo Hub

UPC: 790069-259969

D-Link Systems, Inc.

TEL: (800) 326-1688

www.dlink.com

Package Contents

DFB-H7

6ft USB 2.0 Cable

6ft FireWire Cable

(6-pin to 6-pin)

Power Adapter

Installation Guide

Warranty

The D-Link DFB-H7 connects you to

all of your digital media peripherals.

Combining USB 2.0 & FireWire into

one easy-to-use hub, the DFB-H7 is

an all-in-one, high speed, high per-

formance solution for digital media

peripherals.
