Dell PowerVault NX3000 Manuale utente

Dell™ PowerVault™

NX3000 Systems

Getting Started

With Your System

Začínáme se systémem

Guide de mise en route

Handbuch zum Einstieg

Τα πρώτα βήματα με το σύστημά σας

Rozpoczęcie pracy z komputerem

Начало работы с системой

Procedimientos iniciales con el sistema

Sistem Başlangıç Kılavuzu

www.dell.com | support.dell.com

Dell™ PowerVault™

NX3000 Systems

Getting Started

With Your System

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use

of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

____________________

Information in this document is subject to change without notice.

ReproductionofthesematerialsinanymannerwhatsoeverwithoutthewrittenpermissionofDellInc.

is strictly forbidden.

Dell, the DELL logo, and PowerVault are trademarks of Dell Inc.; Intel and Xeon are registered

trademarks of Intel Corporation in the U.S. and other countries; Microsoft and Windows are either

trademarks or registered trademarks of Microsoft Corporation in the United States and/or other

countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

Model E02S

Regulatory Type E02S001

April 2010 P/N F354N Rev. A01

Getting Started With Your System 3

Installation and Configuration

WARNING: Before performing the following procedure, review the safety

instructions that came with the system.

Unpacking the System

Unpack your system and identify each item.

Installing the Rails and System in a Rack

Assemble the rails and install the system in the rack following the safety

instructions and the rack installation instructions provided with your system.

4Getting Started With Your System

Optional – Connecting the Keyboard, Mouse, and Monitor

Connect the keyboard, mouse, and monitor (optional).

The connectors on the back of your system have icons indicating which cable

to plug into each connector. Be sure to tighten the screws (if any) on the

monitor's cable connector.

Connecting the Power Cable(s)

Connect the system’s power cable(s) to the system and, if a monitor is used,

connect the monitor’s power cable to the monitor.

Getting Started With Your System 5

Securing the Power Cable(s)

Bend the system power cable(s) into a loop as shown in the illustration and

secure the cable(s) to the bracket using the provided strap.

Plug the other end of the power cable(s) into a grounded electrical outlet or

a separate power source such as an uninterruptible power supply (UPS) or

a power distribution unit (PDU).

Turning On the System

Press the power button on the system and on the optional monitor, if used.

The power indicators should light.

6Getting Started With Your System

Installing the Optional Bezel

Install the bezel (optional).

Supported Operating System

Your system is preinstalled with Microsoft®Windows®Storage Server 2008

Standard x64 Edition.

NOTE: For the latest information on supported operating systems, see www.dell.com

Other Information You May Need

WARNING: See the safety and regulatory information that shipped with

your system. Warranty information may be included within this document or

as a separate document.

• The rack documentation included with your rack solution describes how to

install your system into a rack.

•The

Hardware Owner’s Manual

provides information about system features

and describes how to troubleshoot the system and install or replace system

components. This document is available online at

support.dell.com.

• Any media that ships with your system that provides documentation and

tools for configuring and managing your system, including those pertaining

to the operating system, system management software, system updates, and

system components that you purchased with your system.

NOTE: Always check for updates on support.dell.com and read the updates

first because they often supersede information in other documents.

Getting Started With Your System 7

Obtaining Technical Assistance

If you do not understand a procedure in this guide or if the system does not

perform as expected, see your Hardware Owner’s Manual. Dell™offers

comprehensive hardware training and certification. See www.dell.com/training

for more information. This service may not be offered in all locations.

NOM Information (Mexico Only)

The following information is provided on the device described in this

document in compliance with the requirements of the official Mexican

standards (NOM):

Importer:

Model number: E02S

Supply voltage: 100–240 VAC

Frequency: 50/60 Hz

Current consumption: 7.0–3.5A

8Getting Started With Your System

Technical Specifications

Processor

Processor type One or two quad-core Intel®Xeon®Processor 5500

series

Expansion Bus

Bus type PCI Express Generation 2

Expansion slots via riser card:

Riser 1 (Center Riser)

One full-height, 9.5-inch length, x4 link (slot 1)

NOTE: This slot can be upgraded to 12.2 inches.

One low-profile, 9.5-inch length, x4 link (slot 2)

Riser 2 (Left Riser)

Two full-height, 9.5-inch length, x8 link (slot 3 and 4)

One full-height, 9.5-inch length, x16 link (slot 3)

NOTE: Support for up to 25W is available only on the first

two cards installed in the system; any additional cards

installed in the system must be 15W or under.

Memory

Architecture 800, 1066, or 1333 MHz DDR3 registered or unbuffered

Error Correcting Code (ECC) DIMMs. Support for

Advanced ECC or Memory Optimized operation.

Memory module

sockets

Eighteen 240-pin

Memory module

capacities

1 GB or 2 GB UDIMMs and 2 GB, 4 GB,

or 8 GB RDIMMs

(single, dual, or quad-rank dependent on capacity)

Minimum RAM 1 GB with a single processor (1 DIMM per processor)

Maximum RAM 96 GB (with quad-rank 8 GB RDIMM), 144 GB

(with dual-rank 8 GB RDIMM), or 24 GB (with 2 GB

UDIMMs)
