Dell Wyse 5040 AIO Manuale utente

Dell Wyse Cloud Client

Wyse 5040 AIO

Quick Start Guide

快速啟動指南

Panduan Memulai Cepat

1 Set up the stand

設立站立架

Pasang dudukan



2Connect the network cable

連接網路線

Hubungkan kabel jaringan



NOTE: If you have a Fiber SFP module, unlock it, plug it into its slot, and rotate the latch

to lock the module in place

註：如果您有光纖 SFP 模組，請先解鎖，將其插入插槽，旋轉拴鎖以固定鎖住模組

CATATAN : Jika Anda memiliki modul Fiber SFP, buka, colokkan ke dalam slot-nya, dan

putar pengancing untuk mengunci modul pada tempatnya

USB Connector

USB 連接器

Konektor USB

USB 

Connect the Keyboard and Mouse

連接鍵盤與滑鼠

Hubungkan Keyboard dan Mouse



4 Connect the power adapter

連接變壓器

Hubungkan adaptor daya





NOTE: Your client device is ready to use when the client device activity light goes off.

註：當客戶端裝置之活動指示燈熄滅時，即代表您的客戶端裝置已備妥可供使用。

CATATAN : Perangkat klien Anda siap digunakan saat lampu aktivitas perangkat klien padam.

5 Turn on your client device

打開客戶端裝置

Nyalakan perangkat klien Anda



On Screen Display (OSD) Buttons

在螢幕顯示器 (OSD) 按鈕 | Tombol On Screen Display (OSD)

Brightness/Contrast

亮度/對比度 | Kecerahan/Kontras

Auto Adjust

自動調整 | Penyetelan Otomatis

Input Source

輸入來源 | Sumber Input

Color Settings

顏色設定 | Pengaturan Warna

Display Settings

顯示器設定 | Pengaturan Tampilan

Energy Settings

能源設定 | Pengaturan Energi

Menu Settings

選單設定 | Pengaturan Menu

Other Settings

其它設定 | Pengaturan Lain

Fiber SFP:ةظحم

 

:ةظحم 

)OSD(

















1. 照相機狀態指示燈

2. 照相機

3. 麥克風

4. USB 2.0 連接埠

5. 音效連接埠

6. 站立架

7. 立體聲喇叭

8. 防盜鎖孔

9. 螢幕顯示 )OSD( 按鈕

10. 電源開啟/關閉按鈕

11. +19V 變壓器輸入口

12. VGA 輸入

13. USB 2.0 連接埠

14. 網路連接埠，10/100/1000 Base-T

或SFP/Mini-GBIC 插槽

15. 外接式螢幕的顯示幕埠連接器

1. Lampu status kamera

2. Kamera

3. Microphone

4. Port USB 2.0

5. Port audio

6. Dudukan

7. Speaker stereo

8. Slot pengunci keamanan

9. Tombol On Screen Display (OSD)

10. Tombol on/off daya

11. Input adaptor daya +19V

12. Input VGA

13. Port USB 2.0

14. Port jaringan, 10/100/1000 Base-T,

atau SFP/Mini-GBIC slot

15. Konektor Port Tampilan untuk

monitor eksternal

1. Camera status light

2. Camera

3. Microphone

4. USB 2.0 port

5. Audio port

6. Stand

7. Stereo speakers

8. Security lock slot

9. On Screen Display (OSD) buttons

10. Power on/off button

11. +19V Power adapter input

12. VGA input

13. USB 2.0 port

14. Network port, 10/100/1000 Base-T,

or SFP/Mini-GBIC slot

15. Display Port connector for external

monitor

Features

特色 | Fitur |

NOTE: Components may vary based on model and location.

註：元件可能隨機型與地點而有所不同。

CATATAN : Komponen mungkin berbeda-beda tergantung model dan lokasi.

Product support and manuals

產品支援與手冊

Dukungan dan petunjuk produk



dell.com/support

dell.com/support/manuals

Contact Dell

聯絡 Dell | Hubungi Dell dell.com/contactdell

Regulatory and safety

管制與安全 | Peraturan dan keamanan dell.com/regulatory_compliance

Regulatory model

監管型號 | Model peraturan W11B

Client device model

客戶端裝置型號 | Model perangkat klien Dell Wyse Thin Client Series

Wyse 5040 AIO

Printed in Malaysia.

2015-04

0VYJ58A00
