Dell PowerConnect W-Airwave Manuale utente

Dell PowerConnect W-AirWave 7.4

Quick Start Guide

0511039-01 | December 2011 1

Overview

This guide is designed as a reference for installing Dell PowerConnect W-AirWave using the CentOS software

bundled with the .iso disc image.

If you are installing Dell PowerConnect W-AirWave on a VMware server, please consult Appendix B of the Dell

PowerConnect W-AirWave 7.4 User Guide on support.dell.com/manuals for important installation instructions.

If you are installing Dell PowerConnect W-AirWave on a Red Hat Enterprise Linux server, contact Dell support

at support.dell.com.

This document includes the following topics

“Pre-Installation Checklist” on page1

“Creating AirWave Installation CD from .iso Disc Image” on page2

Pre-Installation Checklist

Use this check list to ensure installation goes smoothly

Note: Dell PowerConnect W-Series AirWave Wireless Management Suite (AWMS), AirWave, and AirWave Management Platform

(AMP) refer to the same product set and are used interchangeably..

Table 1 Pre-Installation Checklist

Checklist Check

Have available the Dell PowerConnect W-AirWave license key sent to you in an email

from Dell.

Obtain dedicated server meeting Dell sizing specifications

Static IP address for each AirWave server

Firewall provisioning enabling proper ports/protocols

WLAN infrastructure properties (type, quantity, and location)

WLAN infrastructure access credentials (SNMP, telnet, SSH, etc)

WLAN security policy specifications

Router and switches to monitoring (optional)

Upstream NMS applications (optional)

Wireless client authentication servers (optional)

AirWave administrative authentication servers like TACACS+ or RADIUS (optional)

2Dell PowerConnect W-AirWave 7.4 | Quick Start Guide

Creating AirWave Installation CD from .iso Disc Image

There is a variety of software tools that can be used to create an installation CD from the Dell PowerConnect

W-AirWave Installation CD .iso disc image. You can use a free tool called burnatonce.

1. Download and save the Dell PowerConnect W-AirWave 7.4 Installation CD .iso disc image.

2. Download and install burnatonce from http://www.burnatonce.net/downloads/. Windows 95/ME users will

need to download and install an additional ASPI layer.)

3. Insert a blank CD-R into the CD-R drive.

4. Right-click on the AirWaveInstallation CD .iso disc image file and select “burnatonce”.

5. When the burnatonce program opens, click the Write button. If burnatonce has not automatically associated

to the .iso disc image, run burnatonce manually and select the AirWave install image from the Load menu.

For help with CD burning software other than burnatonce, please refer to the user guide for that product and

reference the option to create a CD from .iso disc image. With Nero, for instance, this option may be found

under File -> Burn Image or Recorder -> Burn Image.

Server Requirements

Dell PowerConnect W-AirWave runs on a dedicated system and is compatible with most standard PC or rack-

mount server hardware. The Dell PowerConnect W-AirWave 7.4 Installation CD will format the hard disk,

install the CentOS operating system, and install the Dell PowerConnect W-AirWave software.

For minimum hardware requirements, refer to the Dell PowerConnect W-AirWave 7.4 Sizing Guide on

support.dell.com/manuals or contact Dell support on support.dell.com.

The hardware must support Red Hat Enterprise 5.0.

Installing AirWave

Phase 1: Installation of Cent OS

Insert the Dell PowerConnect W-AirWave Installation CD into the CD-ROM drive and boot the server from this

CD. When prompted at the Dell PowerConnect W-AirWave splash screen, type “install” to begin installation of

the Cent OS operating system. This process will later prompt for the selection of appropriate keyboard layout

and time zone for your location. When the Cent OS installation is complete, the system will reboot and the

installation CD will be ejected. Remove the CD from the CD-ROM drive.

Phase 2: Installation and configuration of AirWave software

The system will proceed through the Cent OS Linux boot process and a login prompt will be displayed. Use the

following credentials to log in to the system that will display the message included below.

•username: root

•password: admin

NOTE: The CD burning software included with Windows XP does not currently support the ability to create a CD from an .iso disc

image.

NOTE: This will format system hard disk drive(s) and destroy existing data.

Dell PowerConnect W-AirWave 7.4 | Quick Start Guide 3

#################################################################

Welcome to Dell PowerConnect W-AirWave.

Please run "./amp-install" to complete the installation.

#################################################################

To continue with the installation of Dell PowerConnect W-AirWave software, enter this command at the

prompt:

./amp-install

The installation of AirWave software will proceed through seven steps. Steps 2-4 require no user input.

Step 1: Configuring date and time

Step 5: Enter static IP configuration for the primary network interface

Step 6: Enter a display name for the Dell PowerConnect W-AirWave system

Step 7: If a DNS entry exists for the IP address assigned to the AirWave server, enter ‘y’ then the DNS

hostname; otherwise enter ‘n’

Step 8: Enter a new root user password. This password should be and recorded in a safe place.

Accessing the AirWave Web Interface

Enter the IP address assigned to the AirWave server into the URL box of your web browser. Use these default

credentials to log in to the system:

username: admin

password: admin

The first page to appear after you log in is the Home > License page. Paste the Dell PowerConnect W-AirWave

license key you received into the license field on this page, then click Save to display the Dell PowerConnect W-

AirWave licensing agreement.

Click I Accept to agree to the terms of the license agreement and apply the license key.

Changing Login Credentials

Dell strongly recommends that you change the system default credentials

The password for the default web interface user may be changed using the web interface itself, from the AMP

Setup > Users page. Click on the pencil icon to edit the admin user.

The password for the root user may be changed by entering the command passwd on the server command line

prompt.

4Dell PowerConnect W-AirWave 7.4 | Quick Start Guide

Wireless Networks®, the registered Aruba the Mobile Edge Company logo, and Aruba Mobility Management

System®. Dell™, the DELL™ logo, and PowerConnect™ are trademarks of Dell Inc.

Originated in the USA. All other trademarks are the property of their respective owners.

Open Source Code

Certain Aruba products include Open Source software code developed by third parties, including software code

subject to the GNU General Public License (GPL), GNU Lesser General Public License (LGPL), or other Open

Source Licenses. Includes software from Litech Systems Design. This product includes software developed by Lars

Fenneberg, et al. The Open Source code used can be found at this site:

http://www.arubanetworks.com/open_source

Legal Notice

The use of Aruba Networks, Inc. switching platforms and software, by all individuals or corporations, to terminate

other vendors’ VPN client devices constitutes complete acceptance of liability by that individual or corporation for

this action and indemnifies, in full, Aruba Networks, Inc. from any and all legal actions that might be taken against

it with respect to infringement of copyright on behalf of those vendors.

Altri manuali per PowerConnect W-Airwave

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Dell Software

Dell

Dell DX6000 Manuale utente

Dell

Dell PowerConnect W-Airwave Manuale utente

Dell

Dell PowerConnect W-Airwave Guida rapida alla configurazione

Dell

Dell IDRAC6 Manuale utente

Dell

Dell PowerConnect W-Airwave Manuale utente

Dell

Dell PowerConnect W-Airwave Manuale utente

Dell

Dell PowerVault MD3060e Series Manuale utente

Dell

Dell OptiPlex VDI Blaster Edition Manuale di istruzioni

Dell

Dell PowerConnect W-Airwave Manuale utente

Dell

Dell OpenManage Network Manager Manuale di istruzioni

Dell

Dell PowerConnect W-Airwave Manuale utente

Dell

Dell PowerEdge UPS 500T Manuale utente

Dell

Dell P1913 Manuale utente

Dell

Dell DX6000G Manuale utente

Dell

Dell E1913 Manuale utente

Dell

Dell DX6000 Manuale utente

Dell

Dell OpenManage Network Manager Manuale utente

Dell

Dell Server Manuale utente
