Delmhorst BDX-20 Manuale utente

BDX-20 & BDX-30

Quick Start Guide

Navigator Series

Delmhorst

EDGETM App*

Download the App

Support and FAQ

*BDX-30 only

510QSG-0001, Rev 12/2021

Upload readings from meter to app

Access to expanded material/species selections,

including foreign species sets

View all readings on a single screen

Add timestamp and geotags to readings

Exclude outlier readings from statistics

Generates plot of all readings

Customize LED range

Multi-language support for app and meter

Export readings to Excel®for additional

analysis and report generation

51 Indian Lane East

Towaco, NJ 07082

[email protected]

877-DELMHORST (335-6467)

Meter Features

Quick Start

Turn Meter On and Off

Remove tab from inside battery compartment

Press any key to wake meter

Long press center button to timeout

Press Read button from any screen to enter

live reading mode

Read button toggles between held

and live reading

Held readings will blink

Press center button to save reading

from live or held reading

Saved readings will export to EDGETM App

when app and meter are connected*

Take a Reading

Hold a Reading

Save and Export a Reading

Bluetooth®app for customizing device

and exporting data*

English, Spanish, French, German, Italian

and Russian*

Customizable*, color-coded LED’s

Built in material, temperature and

pin-type correction

Adjustable alarm

Built in calibration check

Compatible with all Delmhorst electrodes

2 year warranty

View, hold and save readings

Change material/species

Adjust alarm set point

Set material temperature

Set insulated vs. non-insulated pins

READ

Save up to 100 readings

Saved readings contain material type,

reading value, material temp, and pin type

View average, high and low values

View last 10 readings

STATS

Calibration Check: 12% MC

Temperature Units: °F/°C

Meter Timeout: 1/4/10 minutes

Bluetooth®: ON/OFF

Display Brightness: 1-10

Backlight: ON/OFF/AUTO

Display Contrast: 1-10

SET

YOUR BDX MeterComponents

1) Display

Large, easy to read under all conditions

2) Read Button

Press from any screen to enter live

reading mode

Press again to toggle between live

and held reading

3) Navigation Buttons

Move between and down into the

READ, SET and STATS menus

Center button to save readings

or changes to settings

4) Easy-grip Handle

Easily push pins into material

5) Colored LEDs

Red, yellow, and green LEDs show the

relative moisture status

Adjustable within the Delmhorst EDGETM App

6) Ambient Light Sensor

Turns backlight on and off in Auto

Backlight mode

7) Pins

Insert integral pins up to 5/16” into material

to take reading

8) Electrode Connector

Connect with any Delmhorst

electrode to extend functionality

Display

Read Button

Navigation

Buttons

Pins &

Pin Cap

Light

Sensor

LEDs

Electrode Connector

& Electrode Cap

Easy-grip

Handle

Bluetooth®Indicator *

• Solid

- On and connected

• Blinking

- On and seeking connection

• None

- Off

Read Adjustments

Up/down to move between

Read screen settings

Left/right buttons to

adjust value

Selection Arrows

Left/right to adjust

when blinking

Center/down to enter

current selection
