IMPORTANT

•After removing the packaging, make sure the appliance

is complete and undamaged. If in doubt, do not use the

appliance and contact qualified personnel only.

•Dispose of the plastic bag with care as it represents a

hazard for children.

•If the socket and power cable plug are incompatible, the

socket should be changed for a suitable type by quali-

fied personnel only who should ensure that the cross-

section of the wires leading to the socket is suitable for

the power absorbed by the appliance.

•Bear the following fundamental safety rules in mind:

- Never touch the appliance with damp hands.

- Never use the appliance with bare or wet feet.

- Never unplug the appliance by pulling the power

cable or the appliance itself.

- The appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety. Children should

be supervised to ensure that they do not play with

the appliance.

- Never leave the appliance plugged in as it could be

a safety hazard.

- Never place the iron under the tap to top up with

water. Always use the measure provided.

- If the power cable is damaged, have it replaced

immediately by a qualified electrician.

- The safety of this appliance is guaranteed only if

correctly connected to a proper and effective earth

connection as specified by current electrical safety

standards and regulations. This fundamental safety

requisite should be verified. If in doubt, ask a quali-

fied electrician to check the mains system tho-

roughly. Failure to earth the appliance absolves the

manufacturer of all liability for damage.

•When the appliance is to be discarded, after unplug-

ging from the mains, the lead should be cut as close as

possible to the iron to make the appliance unusable.

•Before cleaning or servicing, disconnect the appliance

by removing the plug from the socket.

•In the event of malfunction and/or faulty operation,

switch off the appliance and take it to a service centre.

•This appliance must be used exclusively for the purpose

for which it was expressly conceived. Any other use is

considered improper and thus dangerous.

•The manufacturer is not liable for damage caused by

inappropriate, incorrect or irresponsible use or for

damage resulting from repairs carried out by unquali-

fied personnel.

•In the event of malfunction, take the iron to an authori-

sed service centre.

•Never overfill the tank and never add stain removers or

similar products.

•Save these instructions for future reference.

•The iron must be used and rested on a stable surface

•If the appliance is dropped causing visible damage, do

not use. Take to a professional service centre.

•When placing the iron on the iron rest, make sure the

iron rest is located on a stable surface. The iron should

be placed on a flat surface extremely resistant to high

temperatures.

This appliance complies with directive 89/336/EEC on

radio interference suppression.

MAIN COMPONENTS

APlate

BSpray

COpening for filling tank with cover

DIndicator light

ESteam regulator

FSpray button

GSuper steam button

HThermostat knob

ISELF CLEAN button

Read this manual thoroughly before using the appliance.

This will ensure optimum results and maximum safety.

Important: Before plugging the appliance in, check that the

mains voltage corresponds to the voltage (V) indicated on

the rating plate of the iron. The socket must be efficiently

earthed.

STEAM IRONING

This iron works with normal tap water.

a) Before filling the tank, make sure the steam regulator E

is in the position ("dry" position) (fig. 1). Make sure

the power cable is unplugged from the mains socket.

b) Open the cover of the opening D and pour the water

into the iron (fig. 2). It is important that the iron is

always unplugged from the mains every time you fill or

top up the water in the tank.

c) Plug the iron into the mains socket.

d) A special segment on the thermostat knob H iden-

tifies the steam range. The steam will be wet if the ther-

mostat pointer His at the beginning of the segment and

dryer if it is towards the end. Make sure the fabric to be

ironed is suitable for steam ironing. When using the iron

for the first time, you are recommended to pass it seve-

ral times over a piece of cloth first.

e) After these checks, select the required temperature by

rotating the thermostat knob H.

f) The indicator light Dwill come on to show the iron is on.

After about a minute in the case of maximum tempera-

ture, the indicator light will go off showing that the iron

is ready for use.

g) Continuous steam delivery is obtained by positioning

the steam regulator Ein the 1, 2 or 3 position (3=

+steam; 1= -steam). Steam delivery ceases whenever

the iron is placed in a vertical position on the rear rest

(position recommended during pauses in ironing) or

with the iron horizontal when the steam regulator Eis in

the dry position .

Note: On the back of the iron there is a useful guide giving

information on the temperature to set according to

the garment being ironed:

Ricordatevi che la funzione vapore può essere impiegata

solo con termostato posizionato sul settore

DRY IRONING

•Plug in the iron and select the temperature, if there is

water in the tank, position the steam regulator Eon the

dry position (fig. 1).

•Wait until the indicator light Cgoes off showing that the

required temperature has been reached.

•If the fabric to be ironed is slightly damp or you iron

fast, you can use a higher temperature. If, on the other

hand, the garments are dry or you iron slowly, use a

higher temperature.

TURBO (SUPER STEAM) (FIG. 3)

•Place the thermostat knob Bon maximum.

•When the indicator light Cgoes off, press the super

steam button I.

For correct operation of the super steam function, you

must wait a few seconds between one burst of steam

and the next.

VERTICAL IRONING

Enables delicate garments to be steamed without resting

them on the ironing board: pay attention to the temperatu-

re used to steam hanging fabrics.

Position the steam regulator Eon the dry position .

Rotate the thermostat knob Hclockwise as far as it will go

(maximum steam position). When the indicator light Dgoes

off, place the iron in a vertical position and move it near the

garment. Press the super steam button Guntil the indi-

cator light Dcomes on again. Wait until the light goes off

before continuing vertical ironing.

Never direct the "vertical" steam jet at a garment hanging

in a wardrobe or worn by a person. Vertical ironing

should always be carried out with the garment hanging

on a clothes stand and always away from other garments,

elements, people and animals.

SPRAY (FIG. 4)

If during ironing, you note particularly resistant creases or

if your garment requires a higher level of dampness, you

can use the spray. Make sure the tank contains water. Press

the spray button (F) repeatedly, directing the spray jet

towards the parts of the garment to be dampened.

Never use the spray when ironing silk as the drops of

water could mark the fabric.

AFTER IRONING

To extend the working life of the iron, whenever you finish

ironing, you are recommended to empty the tank as follows:

•Unplug from the mains socket.

•Open the cover and empty the iron, holding it point

downwards and shaking it gently over a basin or sink.

•To dry the remaining moisture, turn the iron on again

with the thermostat in the maximum position for about

two minutes with the steam regulator in the MAX posi-

tion.

•Unplug from the mains socket and allow to cool.

•Clean the plate with a dry cloth as traces of moisture

could mark it.

•Wind the power cable around the cable winder.

•Store the iron in a vertical position.

MAINTENANCE AND CLEANING

After use, always wait until the iron is cold before putting

away. Allow to cool in a vertical position. Keep the surfa-

ce of the plate clean. Do not rest or use the iron on zips,

hooks, rings etc to avoid scratching the plate. Clean the

plate with a damp cloth only, never use abrasives or sol-

vents.

If the amount of stream drops during use, this could be cau-

sed by excessive build-up of limescale.

To remove, proceed as follows:

•fill the tank to the "MAX" level;

•plug the appliance into the mains and place the ther-

mostat in the MAX position. When the iron has reached

the required temperature (light off), unplug the applian-

ce and leave in a horizontal position;

•place over a sink;

•press the SELF CLEAN button;

•turn the steam regulator clockwise as far as it will go.

The limescale rod is released and the regulator lifts up;

•release the SELF CLEAN button;

•plug the appliance into the mains and leave in opera-

tion for at least two minutes to dry the plate.

•at the end, unplug the appliance from the mains. Leave

the iron to cool and clean the outside with a soft cloth.

SCALE PREVENTION SYSTEM (ANTICALC)

The appliance is fitted with a permanent resin scale filter in

the tank. This filters the impurities and eliminates all scale

residue, thus enabling you to use normal tap water The

resins reduce water hardness, doubling the working life of

the iron.

AUTO SHUT-OFF (CERTAIN MODELS ONLY)

If the iron is not used and left horizontally for 30 seconds, it

turns off automatically. If the iron is not used and left verti-

cally or on its side, the automatic shut-off devices trips after

eight minutes.

Indicator light flashes to indicate activation of automatic

shut-off.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must not be disposed of as

urban waste.

It must be taken to a special local authority differentiated waste col-

lection centre or to a dealer providing this service.

Disposing of a household appliance separately avoids possible negative con-

sequences for the environment and health deriving from inappropriate dis-

posal and enables the constituent materials to be recovered to obtain signifi-

cant savings in energy and resources.As a reminder of the need to dispose

of household appliances separately, the product is marked with a crossed-out

wheeled dustbin.

A) If your appliance comes fitted with a

plug, it will incorporate a 13 Amp fuse.

If it does not fit your socket, the plug

should be cut off from the mains lead,

and an appropriate plug fitted, as

below.

WARNING: Very carefully dispose

of the cut off plug after removing the

fuse: do not insert in a 13 Amp soc-

ket elsewhere in the house as this

could cause a shock hazard.

With alternative plugs not incorpora-

ting a fuse, the circuit must be pro-

tected by a 15 Amp fuse.

If the plug is a moulded-on type, the

fuse cover must be re-fitted when

changing the fuse using a 13 Amp

Asta approved fuse to BS 1362. In

the event of losing the fuse cover, the

plug must NOT be used until a repla-

cement fuse cover can be obtained

from your nearest electrical dealer.

The colour of the correct replacement

fuse cover is that as marked on the

base of the plug.

B) If your appliance is not fitted with a

plug, please follow the instructions

provided below:

WARNING - THIS APPLIANCE MUST BE

EARTHED

IMPORTANT

The wires in the mains lead are coloured

in accordance with the following code:

Green and yellow: Earth

Blue: Neutral

Brown: Live

As the colours of the wires in the mains

lead may not correspond with the colou-

red markings identifying the terminals in

your plug, proceed as follows:

The green and yellow wire must be con-

nected to the terminal in the plug marked

with the letter E or the earth symbol

or coloured green or green and

yellow.

The blue wire must be connected to the

terminal marked with the letter N or

coloured black.

The brown wire must be connected to the

terminal marked with the letter L or

coloured red.

ELECTRICAL CONNECTION (UK ONLY)

Indice

Altri manuali DeLonghi Ferro

DeLonghi

DeLonghi FXK20 Manuale utente

DeLonghi

DeLonghi VVX 2200 Manuale utente

DeLonghi

DeLonghi FXG 24A T Manuale utente

DeLonghi

DeLonghi VVX2000 Manuale utente

DeLonghi

DeLonghi FHX3 Manuale utente

DeLonghi

DeLonghi IC700 series Manuale utente

DeLonghi

DeLonghi VVX 100 Manuale utente

DeLonghi

DeLonghi FXG 175AT Manuale di istruzioni per l'installazione

DeLonghi

DeLonghi VVX800 Manuale utente

DeLonghi

DeLonghi EASYTURBO-S FXK23T Manuale utente

DeLonghi

DeLonghi FXN18AG Manuale utente

DeLonghi

DeLonghi PRO 1860X Manuale utente

DeLonghi

DeLonghi Stirella M70q Manuale utente

DeLonghi

DeLonghi PRO 500 Manuale utente

DeLonghi

DeLonghi FXG 175 AT Manuale utente

DeLonghi

DeLonghi STIRELLA VVX2370 Manuale utente

DeLonghi

DeLonghi VVX1000 Manuale utente

DeLonghi

DeLonghi Easy Turbo FXK23AT Manuale utente

DeLonghi

DeLonghi FXH 3 Manuale utente

DeLonghi

DeLonghi VVX 1860G Manuale utente

DeLonghi

DeLonghi PRO300 Manuale di istruzioni per l'installazione

DeLonghi

DeLonghi FXC 22 Manuale utente

DeLonghi

DeLonghi Stirella VVX1885 DualVap Manuale utente

DeLonghi

DeLonghi pro1847x Manuale utente

Manuali Ferro popolari di altre marche

Clatronic

Clatronic DB 3703 Manuale utente

TEFAL

TEFAL FV4093Z0 Manuale utente

Gorenje

Gorenje SIH 2200 BS Manuale utente

Philips

Philips GC6012 Manuale utente

Bosch

Bosch 2 Series Manuale utente

Riffel

Riffel Catena KB-819 Manuale utente

Texi

Texi Hestia Manuale utente

Maxwell

Maxwell MW-3010 Manuale utente

TREVIDEA

TREVIDEA Girmi ST60 Manuale utente

Philips

Philips HI5914/30 Manuale utente

Primula

Primula Vapormat Manuale utente

Magio

Magio MG-541 Manuale utente

Scarlett

Scarlett SC-1334S Manuale utente

Bosch

Bosch Sensixx B22L Manuale utente

Philips

Philips GC651 Manuale utente

Vitek

Vitek VT-1247 VT Manuale utente

Cleanmaxx

Cleanmaxx 3397 Manuale utente

Philips

Philips GC800 Manuale utente
