Installation, Operation, and

Maintenance Manual

www.ayrdyne.com

3.1.2 Navigation Bar

3.1.3 Home

3.2 Filters

3.2.1 Primary Filter

3.2.2 Hand Clean

3.2.3 Secondary Filter

 3.3Airow

3.3.1 Airow Settings

3.3.2 VFD Settings

3.4 Discharge

3.4.1 Rotary Valves

3.4.2 Double Dump

3.5 Safety

3.5.1 Safety Relay

3.5.2 Isolation Valve

3.6 System

3.6.1 Alarms

3.6.2 Settings

3.6.3 I/O

3.6.4 Metrics

3.6.5 Service Reminders

4 - Troubleshooting

4.1 Alarms

Glossary

. . . . . . . . . . . . . .17

. . . . . . . . . . . . . . . . . . . . . . . 18

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

. . . . . . . . . . . . . . 20

. . . . . . . . . . . . . . . . 22

. . . . . . . . . . . 23

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

. . . . . . . . . . . 24

. . . . . . . . . . . . . . .26

. . . . . . . . . . . . . . . . . . . . . . . . . . 28

. . . . . . . . . . . . . . 28

. . . . . . . . . . . . . . 30

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

. . . . . . . . . . . . . . . . 32

. . . . . . . . . . . . . .32

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

. . . . . . . . . . . . . . . . . . . . . .33

. . . . . . . . . . . . . . . . . . . . .34

. . . . . . . . . . . . . . . . . . . . . . . . . .35

. . . . . . . . . . . . . . . . . . . . . 36

. . . . . . . . . .38

. . . . . . . . . . . . . . . . . . . . . . . . . . . .40

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Introduction

1-Overview

1.1 Safety

2 - Installation and Removal

2.1 Removal of HMI

2.2 Installation of HMI

2.3 Removal of PLC

2.3.1 Installing and Removing

the CPU from DIN rail

2.3.2 Installing and Removing

an SB, CB, or BB

2.3.3 Installing or Replacing

the battery in the BB 1297

battery board

2.3.4 Installing and Removing

an SM

2.3.5 Installing and Removing

a CM or CP

2.3.6 Removing and Reinstalling

the S7-1200 terminal

block connector

3 - Operation

 3.1ScreenOverview

3.1.1 Status Bar

TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

. . . . . . . . . . . . . . . . . . . . 6

. . . . . . . . . . . . . . . . . . . . . .7

. . . . . . . . . . . . . . . . . . . 9

. . . . . . . . . . . . . . . . . . . . .10

. . . . . .10

. . . . . . . . . . . .11

. . . . . . . . . . . . . .12

. . . . . . . . . . . . . . . . . . . . . . .12

. . . . . . . . . . . . . . . . . 14

. . . . . . . . . . . .15

3 - Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

. . . . . . . . . . . . . . . . . . . 16

. . . . . . . . . . . . . . . . . . .17

www.ayrdyne.com

INTRODUCTION

OVERVIEW

The purpose of this document is to outline proper

installation, maintenance, operation, and care

of the AyrDyne® Monitoring System Human

Machine Interface (HMI). This document is in

no way intended to be used to determine the

reliability of this product outside of its originally

intended application. It is the duty of the end user

or integrator to perform the appropriate risk

analysis in order to determine the relevance of its

use within any specic application.

All pertinent state, regional, and local safety

regulations must be observed when installing and

using this product. For reasons of safety and to

help ensure compliance with documented system

data, only the manufacturer should perform

repairs to components.

Failure to follow the guidelines outlined in this

manual may result in injury, harm, or improper

operating results. Failure to observe this

information may also result in equipment damage,

premature wear, or failure.

www.ayrdyne.com

SAFETY

OVERVIEW

The installation, maintenance, operation, and care of the

AyrDyne® Monitoring System Human Machine Interface

(HMI) should only be performed by individuals who are

qualied and trained to do so. A “qualied” person in this

context is a person who has skills and knowledge related

to the construction and operation of electrical equipment

and its installation through both work experience and

training. Additionally, a qualied person is one who

has received and undergone safety training specic to

electrical maintenance. Anyone who has not undergone

safety training specic to this system should not operate or

perform maintenance on the system.

In terms of maintenance of this system, “lock out tag

out” safety protocol applies. This means that any time

maintenance on this system is performed, the machine

must be shut down, unplugged and tagged or labeled,

explaining that maintenance is taking place.

DenTech is not liable for any consequences

arising from misuse of this system. If you are

unsure of whether you are qualied to use or maintain this

system, please contact an electrician or other qualied

professional for assistance. Failure to follow safety

protocol for this and any other system could result in

serious bodily harm or other injury. No responsibility is

assumed by DenTech for any consequences arising out of

the use of this material.

This symbol indicates that an electrical

hazardexistswhichcouldresultinpersonal

injuryiftheinstructionsarenotfollowed.

This safety alert symbol is used to alert you

to potential personal injury hazards. Obey all

safetymessagesthatfollowthissymbolto

avoid possible injury or death.

1.1

www.ayrdyne.com

REMOVAL OF HMI

INSTALLATION & REMOVAL

Figure 2.3.1a

Figure 2.3.1b

Front view of HMI.

Rear view of HMI.

2.1

MECHANICALLY UNSTABLE TERMINAL

AlwayskeepHMIstableinpanelcut-outwhileyouare

installing or removing installation fasteners.

FAILURE TO FOLLOW THESE INSTRUCTIONS MAY

RESULT IN INJURY, OR EQUIPMENT DAMAGE.

CAUTION!

ELECTRICAL SHOCK HAZARD EXISTS

-Ensurethatthecontrolenclosurewithinwhichyou

areworkingispowereddownandlockedout.

-Verifythatallpowersourcesareinazeroenergy

state.

FAILURE TO FOLLOW THESE INSTRUCTIONS MAY

RESULT IN INJURY, DEATH, OR EQUIPMENT DAMAGE.

WARNING!

www.ayrdyne.com

REMOVAL OF HMI

INSTALLATION & REMOVAL

Figure 2.3.1c

Figure 2.3.2

Power connection removed from HMI.

Ground wire with T-20 Torx screw.

2.1 REMOVAL OF HMI

Pull green connector downward to remove

power connection from HMI.

Use a T-20 Torx screwdriver to remove the

ground wire.

2.1

www.ayrdyne.com

REMOVAL

INSTALLATION & REMOVAL

Figure 2.3.3

Figure 2.3.4

Loosening HMI fasteners.

Installation fasteners removed.

With the HMI free from all electrical wiring,

begin to loosen the 10 installation fasteners that

secure the HMI to the control enclosure door

using a small at head screwdriver. Make sure to

support the HMI with the other hand.

Continue to loosen fasteners until they can be

removed from the HMI.

2.1

www.ayrdyne.com

REMOVAL & INSTALLATION

INSTALLATION & REMOVAL

Figure 2.3.5a

Figure 2.3.5b

Removal of the HMI from the front of the

enclosure.

HMI completely removed.

Once the installation fasteners have been

removed, gently remove the AyrDyne HMI from

the front of the enclosure door, taking care not

to damage or displace the installation gasket.

2.1

2.2 INSTALLATION OF HMI

To install the HMI, follow the steps on pages

six through nine in reverse order.

www.ayrdyne.com

INSTALLING & REMOVING PLC

INSTALLATION & REMOVAL

For the removal of the PLC portion of the AyrDyne

Monitoring System, please visit the AyrDyne website

for a link to the Siemens installation manual.

Siemens S7-1200 Manual System Manual, 04/2012,

A5E02486680-06

Pages 50-55

2.3

2.3.1 INSTALLING & REMOVING THE CPU ON A DIN RAIL

TASK PROCEDURE

1. Ensure that the CPU and all S7-1200 equipment are

disconnected from electrical power.

2. Disconnect the I/O connectors, wiring, and cables from the

CPU (Page 55).

3. Remove the CPU and any attached communication modules as

a unit. All signal modules should remain installed.

4. If an SM is connected to the CPU, retract the bus connector:

– Place a screwdriver beside the tab on the top of the signal

module.

– Press down to disengage the connector from the CPU.

– Slide the tab fully to the right.

5. Remove the CPU:

– Pull out the DIN rail clip to release the CPU from the rail.

– Rotate the CPU up and off the rail, and remove the CPU

from the system.

TASK PROCEDURE

1. Install the DIN rail. Secure the rail to the mounting panel every 75 mm.

2. Ensure that the CPU and all S7-1200 equipment are disconnected from electrical

power.

3. Hook the CPU over the top of the DIN rail.

4. Pull out the DIN rail clip on the bottom of the CPU to allow the CPU to t over

the rail.

5. Rotate the CPU down into position on the rail.

6. Push in the clips to latch the CPU to the rail.

// b) REMOVING THE CPU FROM A DIN RAIL

// a) INSTALLING THE CPU ON A DIN RAIL
