DFI 915G-TMGF Manuale utente

83800441

915G-TMGF

915GV-TML

System Board

User’s Manual

This publication contains information that is protected by copyright.

No part of it may be reproduced in any form or by any means or

used to make any transformation/adaptation without the prior

written permission from the copyright holders.

This publication is provided for informational purposes only. The

manufacturer makes no representations or warranties with respect to

the contents or use of this manual and specifically disclaims any

express or implied warranties of merchantability or fitness for any

particular purpose.The user will assume the entire risk of the use or

the results of the use of this document. Further, the manufacturer

reserves the right to revise this publication and make changes to its

contents at any time, without obligation to notify any person or

entity of such revisions or changes.

Trademarks

Windows®2000, Windows NT®4.0 and Windows®XP are

registered trademarks of Microsoft Corporation. Intel®and Pentium®

4 are registered trademarks of Intel Corporation. Award is a

registered trademark of Award Software, Inc. Other trademarks and

registered trademarks of products appearing in this manual are the

properties of their respective holders.

Caution

To avoid damage to the system:

• Use the correct AC input voltage range.....

To reduce the risk of electric shock:

• Unplug the power cord before removing the system chassis

cover for installation or servicing. After installation or servicing,

cover the system chassis before plugging the power cord.

Battery:

• Danger of explosion if battery incorrectly replaced.

• Replace only with the same or equivalent type recommend

the manufacturer.

• Dispose of used batteries according to the battery

manufacturer’s

instructions.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a residential

installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio TV technician for

help.

Notice:

1. The changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority

to operate the equipment.

2. Shielded interface cables must be used in order to comply with

the emission limits.

About this Manual

This user’s manual contains detailed information about the system

board. If, in some cases, some information doesn’t match those

shown in the multilingual manual, the multilingual manual should al-

ways be regarded as the most updated version. The multilingual

manual is included in the system board package.

To view the user’s manual, insert the CD into a CD-ROM drive.The

autorun screen (Mainboard Utility CD) will appear. Click the

“TOOLS” icon then click “Manual” on the main menu.

About the Package

The system board and accessories in the package may not come

similar to the information stated in this manual. This may differ in

accordance to the sales region or models in which it was sold. For

more information about the standard package in your region, please

contact your dealer or sales representative.

Warranty

1. Warranty does not cover damages or failures that arised from

misuse of the product, inability to use the product, unauthorized

replacement or alteration of components and product

specifications.

2. The warranty is void if the product has been subjected to

physical abuse, improper installation, modification, accidents or

unauthorized repair of the product.

3. Unless otherwise instructed in this user’s manual, the user may

not, under any circumstances, attempt to perform service,

adjustments or repairs on the product, whether in or out of

warranty. It must be returned to the purchase point, factory or

authorized service agency for all such work.

4. We will not be liable for any indirect, special, incidental or

consequencial damages to the product that has been modified

or altered.

Table of Contents

Chapter 1 - Introduction

1.1 Specifications......................................................................................................................

1.2 Special Features of the System Board.....................................................

1.3 Package Checklist.........................................................................................................

Chapter 2 - Hardware Installation

2.1 System Board Layout ...........................................................................................

2.2 System Memory...........................................................................................................

2.3 CPU........................................................................................................................................

2.4 Jumper Settings.............................................................................................................

2.5 Rear Panel I/O Ports..............................................................................................

2.6 I/O Connectors...........................................................................................................

Chapter 3 - BIOS Setup

3.1 Award BIOS Setup Utility....................................................................................

3.2 Updating the BIOS.....................................................................................................

Chapter 4 - Supported Softwares

4.1 Drivers, Utilities and Software Applications.....................................

4.2 Installation Notes......................................................................................................

101

108

Introduction

Appendix A - Enabling the Hyper-Threading

Technology

A.1 Enabling the Hyper-Threading Technology...........................................

Appendix B - System Error Messages

B.1 POST Beep....................................................................................................................

B.2 Error Messages...........................................................................................................

Appendix C - Troubleshooting

C.1 Troubleshooting Checklist.................................................................................

109

112

114

Introduction

Chapter 1 - Introduction

1.1 Specifications

Processor

• Intel®Pentium®4 Prescott processor

- Hyper-Threading Technology

- 533MT/s and 800MT/s (200MHz) system bus interface

• Socket LGA 775 (LAN Grid Array)

Chipset

• 915G-TMGF

- North bridge: Intel®915G Express chipset

- South bridge: Intel®82801FB I/O Controller Hub (ICH6)

• 915GV-TML

- North bridge: Intel®915GV Express chipset

- South bridge: Intel®82801FB I/O Controller Hub (ICH6)

System Memory

• Four 184-pin DDR DIMM sockets that support PC2700

(DDR333) and PC3200 (DDR400) DIMMs

• Supports dual channel (128-bit wide) memory interface

• Supports up to 4GB system memory

• Supports non-ECC x8 and x16 DIMMs

• Supports up to 512Mb DRAM densities

• Supports unbuffered DIMMs

Note:

The system board does not support 16Mx8 DRAM.

BIOS

• Award BIOS

• 4Mbit flash memory

Energy Efficient Design

• Supports ACPI specification and OS Directed Power

Management

• Supports ACPI STR (Suspend to RAM) function

• Wake-On-Events include:

- Wake-On-PS/2 Keyboard/Mouse

- Wake-On-USB Keyboard/Mouse

Introduction

- Wake-On-Ring (external modem)

- Wake-On-LAN

- RTC timer to power-on the system

• AC power failure recovery

Hardware Monitor

• Monitors CPU/system temperature and overheat alarm

• Monitors Vcore/V3SB/Vcc3/Vcc5/12V/V5SB/VBAT voltages

• Monitors the speed of the CPU/system fan

• CPU Overheat Protection function monitors CPU temperature

and fan during system boot-up - automatic shutdown upon

system overheat

Onboard VGA Features

• Built-in Intel Graphics Media Accelerator 900

Onboard Audio Features

• 6-channel audio CODEC

• Full-duplex codec with independent variable sampling rate

• True stereo line level outputs

• S/PDIF-in/out interface

Onboard LAN Features

• 915G-TMGF

- Realtek RTL8110SB PCI Gigabit LAN controller

- Supports 10/100/1Gbps

- IEEE 802.3ab compliant

915GV-TML

- Realtek RTL8100C PCI LAN controller

- Supports 10/100Mbps

- IEEE 802.3 compliant

• Integrated power management functions

• Supports wire for management

Serial ATA Interface

• Supports four SATA (Serial ATA) interfaces which are compliant

with SATA 1.0 specification (1.5Gbps interface)

IEEE 1394 Interface (915G-TMGF only)

• Supports two 100/200/400 Mb/sec ports

Introduction

IDE Interface

• One IDE connector supports up to two UltraDMA100Mbps

hard drives

Rear Panel I/O Ports

• 1 mini-DIN-6 PS/2 mouse port

• 1 mini-DIN-6 PS/2 keyboard port

• 1 DB-9 serial port

• 1 DB-25 parallel port

• 1 DB-15 VGA port

• 1 IEEE 1394 port (915G-TMGF only)

• 1 RJ45 LAN port

• 4 USB 2.0/1.1 ports

• Line-in, line-out and mic-in jacks

I/O Connectors

• 2 connectors for 4 additional external USB 2.0/1.1 ports

• 1 connector for 1 external IEEE 1394 port (915G-TMGF only)

• 1 front audio connector for external line-out and mic-in jacks

• 1 CD-in internal audio connector

• 1 S/PDIF connector

• 1 IR connector

• 4 Serial ATA connectors

• 1 IDE connector

• 1 floppy connector

• 1 24-pin ATX power connector

• 1 4-pin ATX 12V power connector

• 1 front panel connector

• 2 fan connectors

Expansion Slots

• 1 PCI Express x16 slot (915G-TMGF only)

• 1 PCI Express x1 slot

• 2 PCI slots

PCB

• microATX form factor

• 24.4cm (9.6") x 24.4cm (9.6")

Introduction

1.2 Special Features of the System Board

PCI Express

PCI Express is a high bandwidth I/O infrastructure that possesses

the ability to scale speeds by forming multiple lanes. The system

board currently supports the physical layer of x1 and x16 (915G-

TMGF only) lane widths.

The x1 PCI Express lane supports transfer rate of 2.5 Gigabytes

(250MBbps) per second. The PCI Express architecture also provides

a high performance graphics infrastructure by doubling the capability

of the existing AGP 8x designs over a x16 PCI Express lane that

provides 4 Gigabytes per second transfer rate.

Intel Graphics Media Accelerator 900

The graphics flexibility of the built-in Intel®Graphics Media

Accelerator (GMA) 900 supports enhanced 2D, 3D and video

capabilities. It also support widescreen LCD displays, accelerated

DirectX* 9 3D and PCI Express graphics cards.

Hyper-Threading Technology Functionality Requirements

The system board supports Intel processors with Hyper-Threading

Technology. Enabling the functionality of Hyper-Threading Technology

for your computer system requires ALL of the following platforms.

Components:

• CPU - an Intel®Pentium®4 Processor with HT Technology

• Chipset - an Intel®chipset that supports HT Technology

• BIOS - a BIOS that supports HT Technology and has it enabled

• OS - an operating system that includes optimizations for HT

Technology

Please refer to Appendix A for information a bout enabling the

functionality of the Hyper-Threading Technology. For more information

on Hyper-Threading Technology, go to: www.intel.com/info/

hyperthreading.

Altri manuali per 915G-TMGF

Questo manuale è adatto per i seguenti modelli

Indice

Manuali Scheda madre popolari di altre marche

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuale utente
