Directed Electronics 544T Manuale utente

555544TT

➤

OOwwnneerr’’ssGGuuiiddee

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy

Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or

replace with a comparable reconditioned model any Directed unit (hereafter the "unit"),

excluding without limitation the siren, the remote transmitters, the associated sensors and

accessories, which proves to be defective in workmanship or material under reasonable use

during the lifetime of the vehicle provided the following conditions are met: the unit was

professionally installed and serviced by an authorized Directed dealer; the unit will be pro-

fessionally reinstalled in the vehicle in which it was originally installed by an authorized

Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy

of the bill of sale or other dated proof of purchase bearing the following information: con-

sumer's name, telephone number and address; the authorized dealers name, telephone

number and address; complete product description, including accessories; the year, make

and model of the vehicle; vehicle license number and vehicle identification number. All

components other than the unit, including without limitation the siren, the remote trans-

mitters and the associated sensors and accessories, carry a one-year warranty from the date

of purchase of the same. This warranty is non-transferable and is automatically void if: the

original purchaser has not completed the warranty card and mailed it within ten (10) days

of the date of purchase to the address listed on the card; the unit's date code or serial num-

ber is defaced, missing or altered; the unit has been modified or used in a manner con-

trary to its intended purpose; the unit has been damaged by accident, unreasonable use,

neglect, improper service, installation or other causes not arising out of defects in materi-

als or construction. The warranty does not cover damage to the unit caused by installa-

tion or removal of the unit. Directed, in its sole discretion, will determine what consti-

tutes excessive damage and may refuse the return of any unit with excessive damage. TO

THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD-

ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY,

WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE

AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY,

ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR

AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,

OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.

DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY

AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-

ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS

UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT

OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAM-

AGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND

HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD-

ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR

VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR

MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY

CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM

OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER

VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.

CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY

AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY

CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE

AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT.

DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV-

ER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,

INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF

EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY

AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER

DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-

TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or con-

sequential damages. This warranty gives you specific legal rights and you may also have

other rights that vary from State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your autho-

rized Directed dealer for details of the plan or call Directed Customer Service at 1-800-

876-0800. Directed security systems, including this unit, are deterrents against possible

theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft

of the automobile, its parts or contents; and hereby expressly disclaims any liability what-

soever, including without limitation, liability for theft, damage and/or vandalism.

Directed does not and has not authorized any person or entity to create for it any other

obligation, promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤Date of purchase

➤Your full name and address

➤Authorized dealer's company name and address

➤Type of alarm installed

➤Year, make, model, and color of the automobile

➤Automobile license number

➤Vehicle identification number

➤All security options installed on automobile

➤Installation receipts

ttrraannsscceeiivveerrddiiaaggrraamm................................22

ssttaannddaarrddttrraannsscceeiivveerrccoonnffiigguurraattiioonnss........33

wwhhaattiissiinncclluuddeedd......................................44

iimmppoorrttaannttiinnffoorrmmaattiioonn............................44

warning! safety first . . . . . . . . . . . .5

system maintenance . . . . . . . . . . . .7

your warranty . . . . . . . . . . . . . . . . .7

fcc/id notice . . . . . . . . . . . . . . . . . .8

caution . . . . . . . . . . . . . . . . . . . . . .8

ttrraannsscceeiivveerrffuunnccttiioonnss..............................99

standard button configurations . . .9

standard icon configurations . . . .11

function button configurations . .15

rreemmootteeooppeerraattiioonn..................................1177

system signal paging features . . . .17

uussiinnggyyoouurrssyysstteemm................................1188

active arming . . . . . . . . . . . . . . . .18

passive arming . . . . . . . . . . . . . . .18

vehicle protection . . . . . . . . . . . . .19

warn away® response description .20

triggered response description . . .21

arming/disarming while driving . .22

multi-level security arming . . . . . .23

disarming . . . . . . . . . . . . . . . . . . .24

high security disarm . . . . . . . . . . .25

disarming without a transceiver . .25

silent mode . . . . . . . . . . . . . . . . . .26

panic mode . . . . . . . . . . . . . . . . .27

valet mode . . . . . . . . . . . . . . . . . .27

remote start . . . . . . . . . . . . . . . . .29

valet take-over . . . . . . . . . . . . . . .31

setting the clock . . . . . . . . . . . . . .32

temperature check mode . . . . . . .32

ssaaffeettyyffeeaattuurreess........................................3333

starter anti-grind circuitry . . . . . .33

disabling the remote start system .33

over and under rev protection . . .34

shut down inputs . . . . . . . . . . . . .34

nuisance prevention circuitry . . . .34

ddiiaaggnnoossttiiccss............................................3366

arming diagnostics . . . . . . . . . . . .36

disarming diagnostics . . . . . . . . . .36

system status chirps . . . . . . . . . . .37

table of zones . . . . . . . . . . . . . . . .37

interpreting zone diagnostics . . . .38

ccooddeehhooppppiinngg........................................3399

oowwnneerrrreeccooggnniittiioonn................................4400

rraappiiddrreessuummeellooggiicc................................4400

ppoowweerrssaavveerrmmooddee................................4411

pprrooggrraammmmiinnggooppttiioonnss..........................4422

sseeccuurriittyy&&ccoonnvveenniieenncceeeexxppaannssiioonnss......4455

gglloossssaarryyoofftteerrmmss..................................4466

ttaabblleeooffccoonntteennttss

ttrraannsscceeiivveerrddiiaaggrraamm

17 18

ssttaannddaarrddttrraannsscceeiivveerrccoonnffiigguurraattiioonnss

1 Vehicle Interior Temperature Indicator

2 Numeric Display

3 AM/PM Indicator

4 Alarm Clock Mode Indicator

5 Timer Function Indicator

6 Transmit Range Indicator

7 Transmission Indication

8 Vibrate/Beep Mode Indicator

9 Power Saver Mode Indicator

10 Remote Start Timer Mode Indicator

11 No Function

12 Vehicle Page Mode Indicator

13 Full Trigger Shock Sensor Indicator

14 Hood/Trunk Open or Trigger Indicator

15 Parking Light Indicator

16 Door Open or Trigger Indicator

17 Arm/Lock Button

18 Disarm/Unlock Button

19 Remote Start Indicator

20 Hood/Trunk Open or Trigger Indicator

21 Panic Mode Button

22 Valet Mode Indicator

23 Remote Start Safety Shutdown Indicator

24 Battery Level Indicator

25 Auxiliary Button

26 Temperature-Controlled Remote Start Indicator

27 Silent Arm/Disarm Mode Indicator

28 Full Trigger Alert Indicator

29 Arm/Disarm Indicator

30 Function Button

31 Celsius/Fahrenheit Indicator

wwhhaattiissiinncclluuddeedd

➤Control module

➤A.S.K. Receiver

➤One four-button two-way transceiver

➤One four-button transmitter

➤Stinger™ DoubleGuard® two-stage shock sensor

➤Revenger™ Soft Chirp™ six-tone programmable siren

➤Red status LED indicator light

➤Push-button Valet® switch

➤Your warranty registration

➤FailSafe® Starter Kill

➤Shut-down toggle switch

iimmppoorrttaannttiinnffoorrmmaattiioonn

Congratulations on the purchase of your combination remote

start alarm system. Due to the complexity of this system, it must

only be installed by an authorized dealer. Installation of this

product by anyone other than an authorized dealer voids the

warranty. All dealers are provided with a preprinted dealer certif-

icate to verify authorization.

By carefully reading this Owner's Guide prior to using your

system, you will maximize the use of this system and its features.

You can print additional or replacement copies of this manual by

accessing our web site at www.directed.com.

warning! safety first

The following safety warnings must be observed at all times:

➤Due to the complexity of this system, installation of this product

must only be performed by an authorized Directed dealer.

➤When properly installed, this system can start the vehicle via

a command signal from the transceiver. Therefore, never

operate the system in an enclosed area or partially enclosed

area without ventilation (such as a garage). When parking in

an enclosed or partially enclosed area or when having the

vehicle serviced, the remote start system must be disabled

using the installed toggle switch. It is the user's sole respon-

sibility to properly handle and keep out of reach from chil-

dren all transceiver to assure that the system does not unin-

tentionally remote start the vehicle. TTHHEEUUSSEERRMMUUSSTT

IINNSSTTAALLLLAACCAARRBBOONNMMOONNOOXXIIDDEEDDEETTEECCTTOORRIINN

OORRAABBOOUUTTTTHHEELLIIVVIINNGGAARREEAAAADDJJAACCEENNTTTTOOTTHHEE

VVEEHHIICCLLEE..AALLLLDDOOOORRSSLLEEAADDIINNGGFFRROOMMAADDJJAACCEENNTT

LLIIVVIINNGGAARREEAASSTTOOTTHHEEEENNCCLLOOSSEEDDOORRPPAARRTTIIAALLLLYY

EENNCCLLOOSSEEDDVVEEHHIICCLLEESSTTOORRAAGGEEAARREEAAMMUUSSTTAATT

AALLLLTTIIMMEESSRREEMMAAIINNCCLLOOSSEEDD..These precautions are

the sole responsibility of the user.

➤Use of this product in a manner contrary to its intended

mode of operation may result in property damage, personal

warning! THIS SYSTEM PROVIDES REMOTE NOTI-

FICATION OF SECURITY SYSTEM TRIGGER

EVENTS. CONTACT POLICE OR SECURITY PER-

SONNEL IMMEDIATELY. NEVER CONFRONT A

CAR THIEF OR VANDAL.

➜

injury, or death. (1) Never remotely start the vehicle with the

vehicle in gear, and (2) Never remotely start the vehicle with

the keys in the ignition. The user must also have the neutral

safety feature of the vehicle periodically checked, wherein

the vehicle must not remotely start while the car is in gear.

This testing should be performed by an authorized Directed

dealer in accordance with the Safety Check outlined in the

product installation guide. If the vehicle starts in gear, cease

remote start operation immediately and consult with the

authorized Directed dealer to fix the problem.

➤After the remote start module has been installed, contact your

authorized dealer to have him or her test the remote start

module by performing the Safety Check outlined in the

product installation guide. If the vehicle starts when performing

the Neutral Safety Shutdown Circuit test, the remote start unit

has not been properly installed. The remote start module must

be removed or the installer must properly reinstall the remote

start system so that the vehicle does not start in gear. All instal-

lations must be performed by an authorized Directed dealer.

OOPPEERRAATTIIOONNOOFFTTHHEERREEMMOOTTEESSTTAARRTTMMOODDUULLEEIIFF

TTHHEEVVEEHHIICCLLEESSTTAARRTTSSIINNGGEEAARRIISSCCOONNTTRRAARRYYTTOO

IITTSSIINNTTEENNDDEEDDMMOODDEEOOFFOOPPEERRAATTIIOONN..OOPPEERR--

AATTIINNGGTTHHEERREEMMOOTTEESSTTAARRTTSSYYSSTTEEMMUUNNDDEERR

TTHHEESSEECCOONNDDIITTIIOONNSSMMAAYYRREESSUULLTTIINNPPRROOPPEERRTTYY

DDAAMMAAGGEEOORRPPEERRSSOONNAALLIINNJJUURRYY..YYOOUUMMUUSSTTIIMMMMEE--

DDIIAATTEELLYYCCEEAASSEETTHHEEUUSSEEOOFFTTHHEEUUNNIITTAANNDDSSEEEEKK

TTHHEEAASSSSIISSTTAANNCCEEOOFFAANNAAUUTTHHOORRIIZZEEDDDDIIRREECCTTEEDD

Indice

Altri manuali Directed Electronics Allarme auto

Directed Electronics

Directed Electronics Model 3000 ESP Manuale utente

Directed Electronics

Directed Electronics 592 Manuale utente

Directed Electronics

Directed Electronics 690XV Manuale utente

Directed Electronics

Directed Electronics Clifford RS2.1 Manuale utente

Directed Electronics

Directed Electronics PYTHON 480XP Manuale utente

Directed Electronics

Directed Electronics 7900 Manuale utente

Directed Electronics

Directed Electronics Python 450 ESP Manuale utente

Directed Electronics

Directed Electronics Hornet 742T Manuale utente

Directed Electronics

Directed Electronics Automate 640M Manuale utente

Directed Electronics

Directed Electronics 2000 MAX Manuale utente

Directed Electronics

Directed Electronics Python 571XP Manuale utente

Directed Electronics

Directed Electronics Python 460HP Manuale utente

Directed Electronics

Directed Electronics 3000 Manuale utente

Directed Electronics

Directed Electronics Python 881XP Manuale utente

Directed Electronics

Directed Electronics Python 3000 ESP Manuale utente

Directed Electronics

Directed Electronics 551R Series Manuale utente

Directed Electronics

Directed Electronics Valet 561T Manuale utente

Directed Electronics

Directed Electronics Viper 4704 Manuale utente

Directed Electronics

Directed Electronics Cyber 130XV Manuale utente

Directed Electronics

Directed Electronics Python 990 Manuale utente

Directed Electronics

Directed Electronics VIPER 3203 Manuale utente

Directed Electronics

Directed Electronics Car Alarm Manuale utente

Directed Electronics

Directed Electronics 554R Manuale utente

Directed Electronics

Directed Electronics PS-7870TWE-FM Manuale utente

Manuali Allarme auto popolari di altre marche

Clifford

Clifford 3606X Manuale utente

Ultra Start

Ultra Start 2500M SERIES Manuale utente

Ultra Start

Ultra Start 650 Series Manuale utente

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuale utente

Sparkrite

Sparkrite SRA8 Manuale utente

Viper

Viper 4708V Manuale utente

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuale

Falcon

Falcon Predator XL3 Guida utente

Audiovox

Audiovox Auto Security XR91 Istruzioni operative

Clifford

Clifford Sabre II Manuale utente

CrimeStopper

CrimeStopper CS-8717 Guida rapida

Ultra Start

Ultra Start 450 SERIES Manuale utente

Scytek electronic

Scytek electronic Vectra X3 Manuale utente

Excalibur

Excalibur AL-1860-EDPB Manuale utente

Clifford

Clifford CYBER 2 Manuale utente

Gemini

Gemini 7057 Manuale utente

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuale utente

Magicar

Magicar FAI-440 Manuale utente
