Directed Electronics Cyber 76XV Manuale utente

[ Put a stop to crime ]

[ User guide ]

MODELMODEL

S e c u r i t y s y s t e m a n d c o n v e n i e n c e

76XV

Limited Lifetime

Consumer Warranty

For a period of five calendar year from the date of purchase of this auto-security

device, Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or

replace (with a comparable reconditioned model), free of cost, any electronic control

module which proves to be defective in workmanship or material under normal use,

SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL

AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY

INSTALLED. If warranty service is necessary you must have a clear copy of your sales

receipt containing all of the information shown on the following page.

After the first calendar year, from the date of purchase of this auto-security device,

Directed Electronics, Inc., promises to the ORIGINAL PURCHASER to repair or replace

(with a comparable reconditioned model) any electronic control module which proves

to be defective in workmanship or material under normal use FOR A CHARGE OF

$45.00, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PRO-

FESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS

ORIGINALLY INSTALLED. If warranty service is necessary you must have a clear copy

of your sales receipt containing all of the information shown on the following page.

This warranty contains the entire agreement relating to warranty and supersedes all

previous and contemporaneous representations or understandings, whether written or

oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS

CONTENTS.

This warranty is void if the product has been damaged by accident, unreasonable use,

neglect, improper service or other causes not arising out of defects in materials or

construction. This warranty is nontransferable and does not apply to any unit that

has been modified or used in a manner contrary to its intended purpose and does not

cover batteries. The unit in question must be returned to the manufacturer, postage

prepaid. This warranty does not cover labor costs for the removal, diagnosis, trou-

bleshooting or reinstallation of the unit. For service on an out-of-warranty product a

flat rate fee by model is charged. Contact your authorized dealer to obtain the ser-

vice charge for your unit.

These systems are a deterrent against possible theft. Directed Electronics, Inc. is not

offering a guarantee or insuring against the theft of the automobile or its contents

and disclaims any liability for the theft of the vehicle and/or its contents. Directed

Electronics does not authorize any person to create for it any other obligation or lia-

bility in connection with this security system.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD-

ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM-

MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU-

SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR-

RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF

NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR

ABROAD. NEITHER THE MANUFACTURER OR ANY ENTITIES CONNECTED THEREWITH

SHALL BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT

NOT LIMITED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOWING,

REPAIR, REPLACEMENT, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL

LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE

ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR

THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or

consequential damages. This warranty gives you specific legal rights, and you may

also have other rights which vary from state to state.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

■Date of purchase

■Your full name and address

■Authorized dealer's company name and address

■Type of alarm installed

■Year, make, model and color of the automobile

■Automobile license number

■Vehicle identification number

■All security options installed on automobile

■Installation receipts

iii

Table of Contents

Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

What Is Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Your Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

FCC/ID Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Transmitter Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Using Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Disarming Without a Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Remote-Controlled Silent Arm/Disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Remote-Controlled Valet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Nuisance Prevention Circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Arming Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Disarming Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Table of Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Stealth Coding™Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

High Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Security & Convenience Expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Installation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Glossary Of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Quick Reference Guide (Removable) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Standard Configuration

What is Included

■A control module

■Two 3-button remote transmitters

■A zone 2 impact sensor on-board the control module

■A high-powered siren

■A fault-proof starter interrupt on-board the control module

■An LED Blue system status indicator

■A push-button Valet®switch

Important Information

Congratulations on the purchase of your state-of-the-art vehicle

security system. This system has been designed to provide years of

trouble-free operation. By carefully reading this guide prior to

using your system, you will maximize the use of this product and

its features.

Your vehicle security system has no specific maintenance require-

ments. The remote transmitter is powered by a lightweight 3-volt

lithium battery that will last approximately one year under normal

use. When the battery begins to weaken, the LED on the remote

transmitter will dim and you will notice reduced operating range

System Maintenance

when using the remote transmitter. To access the battery for

replacement, remove the rear cover of the remote with a small,

flat-blade screwdriver.

Your warranty card must be returned and the barcode serial num-

ber must not be removed. If the warranty card is not returned, no

warranty will be honored on your unit. It is also necessary to keep

your proof of purchase, which reflects that the product was

installed by an authorized dealer. Make sure you receive the war-

ranty card from your dealer.

This device complies with Part 15 of FCC rules. Operation is subject

to the following conditions: (1) This device may not cause harmful

interference, and (2) This device must accept any interference

received, including interference that may cause undesired operation.

Caution: Changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority to

operate this device.

FCC/ID Notice

Your Warranty
