Dish Network 52.0 Manuale utente
Remote Set Up Guide
Standard_Remote_QSG.indd 1 9/2/2015 4:16:11 PM
1
1
16
12
13
14
7
89
10
17
15
11
18
3
2
45
6
To ensure you are in SAT mode, press the SAT button located
on the side of the remote (see page 2) to display programming
and to use the features described in this section.
Note: Some features may not be available depending on your
receiver model.
1. Using the Remote Buttons
20
19
Standard_Remote_QSG.indd 2 9/2/2015 4:16:15 PM
2
Arrow/Select Buttons
•Navigates you
through your
Hopper experience
SAT/TV/AUX
•Mode indicator lights
up when in that
mode
CH
•Channels up/down
•Navigates one full
page in menus
Skip Forward/Forward
•Press to skip
forward 30 seconds
in a program
•Press and hold to
forward through the
program
Skip Back/Back
•Press to skip back
10 seconds in a
program
•Press and hold to
reverse the program
Back/Live TV
•Returns to previous
menu
•Press and hold to
return to viewing
live TV
Pause/Play
•Pauses or plays
a live or recorded
program
Power
•Turns the receiver
on/off
Vol and Mute Buttons
•Controls TV volume
Programming required
Recall
•Returns to previously
viewed channel(s)
Number Buttons
•Enters a channel
number
•Navigates through
menus and program
guide
Home
•Displays Home
menu
Options
•Opens Options
menu
Apps
•Displays Apps menu
DVR
•Displays recorded
programs
Guide
•Displays the Guide
Search
•Searches for
programs
1
8
9
3
10
11
12
18
13
414
5
16
615
7
17
Info/Help
•Retrieves info on
programs
•Press and hold for
help
Input
•Swaps the tuner
19
20
SAT/TV/AUX Mode
•Changes which
device the remote
controls
2
Standard_Remote_QSG.indd 3 9/2/2015 4:16:15 PM
•Swaps the input in
TV mode
3
Push the tab toward the top
of the remote to release the
battery door latch and lift
the battery door from the
remote.
Insert 2 AA batteries, putting
thenegativeendsrst.
Match the plus (+) ends with
the plus markings on the
battery case.
Slide the top of the remote
battery cover back into place
and push the bottom of the
cover until it clicks closed.
2. Inserting the Batteries
a.
b.
c.
Standard_Remote_QSG.indd 3 9/2/2015 4:16:16 PM
4
3. Pairing the Remote to a Hopper
or Joey Receiver
Turn your receiver and TV
on.
Press SYSTEM INFO on the
front panel of the receiver.
Press the SAT button on
your remote. When the
remote is paired, it gives a
series of ascending tones.
Press the BACK/LIVE TV
button to return to live TV.
b.
a.
SYSTEM
INFO
SYS INFO
Joey:
OR
Hopper:
c.
d.
Standard_Remote_QSG.indd 4 9/2/2015 4:16:18 PM
5
Press the HOME button.
Press the UP Arrow to
access the tabs, then using
the LEFT Arrow highlight
Menu and press SELECT.
Highlight Settings and
press SELECT.
Highlight Diagnostics and
press SELECT.
Press the DOWN Arrow
to highlight Tools under
Receiver.
4. Restoring Your Remote Settings
a.
b.
c.
d.
e.
After your remote is paired, restore your remote settings
to update the remote with settings that were previously
backed-up. Use your remote to complete this step.
Standard_Remote_QSG.indd 5 9/2/2015 4:16:18 PM
6
Highlight Restore Settings
and press SELECT.
Highlight Restore to
Remote Control and press
SELECT.
Note: Do not move your
remote or receiver during
this process.
Highlight Finished and
press SELECT when the
remote settings have been
restored.
f.
g.
h.
Standard_Remote_QSG.indd 6 9/2/2015 4:16:18 PM
7
Press the HOME button.
Press the UP Arrow to
access the tabs, then using
the LEFT Arrow highlight
Menu and press SELECT.
Highlight Settings and
press SELECT.
Highlight Remote Control
and press SELECT.
a.
b.
c.
d.
If you would like the VOLUME and MUTE buttons on your
DISH remote to work with your TV or other devices, go to
the Remote Control Settings menu to program your DISH
remote. Use your remote to complete this step.
5. Accessing Your Remote Settings
Standard_Remote_QSG.indd 7 9/2/2015 4:16:18 PM
8
Highlight Devices,
Customizations, or
Advanced Features and
press SELECT to program
thatspecicsetting.
For additional information,
highlight the ?button and
press SELECT.
e.
f.
Standard_Remote_QSG.indd 8 9/2/2015 4:16:19 PM
9
6. Backing-up Your Remote and
Receiver Settings
Press the HOME button.
Press the UP Arrow to
access the tabs, then
using the LEFT Arrow
highlight Menu and
press SELECT.
Highlight Settings and
press SELECT.
Highlight Diagnostics
and press SELECT.
Using the DOWN Arrow,
highlight Tools under
Receiver.
a.
b.
c.
d.
e.
After changing your remote settings, it is recommended that
you back-up these settings. These steps back up both the
receiver and remote settings. Use your remote to complete
this step.
Standard_Remote_QSG.indd 9 9/2/2015 4:16:19 PM
