Duronic HS90 Manuale utente
HS90 - Handheld Steam Iron
PLEASE READ ALL THE INSTRUCTIONS BEFORE USE
2
3
English Manual
Manuel d’utilisation en français
Gebrauchsanleitung auf Deutsch
Manual de Instrucciones en Español
Manuale D’istruzioni In Italiano
Instrukcja obsługi. Polski
Gebruikershandleiding Nederlands
5
18
31
44
57
70
83
Contents
4
5
English Manual
6
Features and Specications
Components
MODEL POWER VOLTAGE
RATING
WATER TANK
CAPACITY
HS90 1000-1190W 220-240V ~
50/60Hz
90ml
1. Handle rotation button
2. Power button
3. Steam button
4. Handle
5. Power cable
6. Water level window
7. Main body
• 2 steam functions
• Water tank capacity: 90ml
• Temperature range: 90-180°c
• Soleplate size: 17.7x7.5cm
• Power light indicator: Blue
8. Sole plate
9. Base
10. Water tank hole
11. Water tank cap
12. Water ller jug
13. Storage bag
• Size: L17.7 x W7.5 x H10 cm
• Weight: 871g
• Power cable length: 200cm
110 11
8
9
2 3 4 5
6
7
12 13
7
Safety Instructions
PLEASE READ THIS MANUAL CAREFULLY AND RETAIN FOR FUTURE
REFERENCE
• This appliance is for light or occasional indoor/household use only. This
iron is not intended for professional laundry services.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be closely supervised at all times to ensure that they do
not play with the appliance.
• Do not operate this appliance if the power cable or plug is damaged.
If either is damaged return it to Duronic for service or repair by a
professional technician.
• Please ensure the mains power supply is 220-240V ~ 50/60Hz.
• Do not use this appliance on an extension lead or multi-way plug adapter.
• Do not yank the power cable to remove it from the plug socket. Always
grasp the plug and pull it out to disconnect it.
• Never try to replace the parts or repair the appliance by yourself.
• To reduce the risk of electric shock, never operate this product with wet
hands, spill liquid on it or submerge it in water or any other liquid.
• Do not place the iron on or near a hot gas or on a heated oven.
• Do not let the power cable hang over the edge of a table or counter or
touch a hot surface.
• Pay close attention to the iron whilst in use. The iron must not be left
unattended while it is connected to the mains socket.
8
• Ensure that the iron is switched off and unplugged from the electrical
mains socket and fully cooled down before storing away.
• Do not use any attachments which are not listed in this manual.
• Always hold the iron by the handle. Keep the hot soleplate away from
body parts and heat-sensitive objects.
• Do not turn the iron upside down; there may be hot water in the water
tank.
• Do not leave water in the water tank when the iron is not in use - this can
corrode and damage the soleplate.
• Keep the iron well away from surfaces and objects that can be damaged
by heat.
• Ensure there is adequate space to operate the iron.
• When not ironing, place the iron down onto the iron base, on a level
surface.
• When ironing garments, use this iron only with a purpose-built ironing
board, on a at even surface.
• Observe all of the ironing instructions and ironing temperature dot settings
given by the garment manufacturer. These guidelines are normally on the
label/s inside the garment.
• Always ensure the water lling does not exceed the MAX mark.
• Always switch off and unplug the iron when relling the water tank.
• Do not ll the water tank with hot water or corrosive cleaning agents which
could cause damage to the iron.
• Do not iron buttons or fasteners. This could damage the iron soleplate.
9
• During operation do not use the iron when the light is ashing, this means
the iron is heating up. When the light stays constantly lit up the iron has
reached the correct temperature and you can use the iron.
• Do not iron directly onto synthetic or silk fabric - instead iron the fabric
inside out or with the synthetic fabric covered by another material to
protect it.
• If the steam iron falls over, check it for visible signs of damage or leakage.
If any is found, stop using the iron immediately.
• Do not put the iron in the storage bag or store away whilst hot. Wait for it
to cool before storing it away.
10
Ironing Temperatures
Garment Label Fabric Type Thermostat
Regulation
Synthetic Low temperature
Silk-wool Medium temperature
Cotton-linen High temperature
Fabric not to be ironed
How to Use
FIRST USE
Fill the water tank using the jug provided.
Plug in and switch on the iron and allow it to heat up for 5 minutes before
using at the rst time. Then switch the iron off, unplug the cable and empty the
water from the iron.
FILLING THE IRON
Only ll the iron with water if you intend to use the steam function. For
dry ironing, you do not need to ll the tank with water.
1. Make sure the iron is turned off and unplugged from the mains socket.
2. Fill the water jug with fresh water from the tap. If you live in a hard water
area, it is advisable to use distilled water. Avoid using water containing
softeners, perfumes or additives.
