Dwyer Instruments BPI Series Istruzioni per l'installazione e il funzionamento

Series BPI/R D Battery Powered emperature Indicator

Specifications - Installation and Operating Instructions

Bulletin E-90-BPI/R D

DWYER INS RUMEN S, INC.

Phone: 219/879-8000 www.dwyer-inst.com

P.O. BOX 373 • MICHIGAN CI Y, INDIANA 46361, U.S.A. Fax: 219/872-9057 e-mail: info@dwyer-inst.com

The S ri s BPI is a range of battery powered temperature

indicators. The Series B I-XX1 accepts an RTD sensor; the

Series B I-XX2 accepts a thermocouple sensor. The sensor

type, temperature units and other flexible configuration settings

are selectable via a simple to use menu system, which is

navigated by the use of three push-button keys located on the

rear of the display. The entire assembly is sealed into a cap that

fits directly onto the connecting heads.

lease inspect the packaging and instrument thoroughly for any

signs of transit damage. If the instrument has been damaged,

please notify your shipper immediately.

INSTALLATION

Configuration - Fit the battery as described in Battery section,

then follow the simple configuration menus printed on the

reverse side of this sheet. This procedure can be performed with

or without the sensor connected. Fit the correct units legend to

the front panel face.

Enclosur - The case offers various options for sensor entry.

lease refer to the data sheet for further details. The sensor

may be fixed directly to the housing, or remotely connected

using cable and gland. Cable length must be no greater than 20

meters to comply with CE certification. All external

cabling/sensor entries must maintain I 67 rating.

Wiring

BPI/RTD Conn ction

SPECIFICATION @ 68°F (20°C)

Inputs: Thermocouple or RTD depending on model.

Accuracy: Thermocouple input: ±0.1% FS, ±0.5°C

(plus sensor); RTD: ±0.2°C ±0.1% of reading (plus sensor error).

Pow r R quir m nts: 3.6 V Lithium battery.

Batt ry Lif : >2 years.

Display: 4-digit LCD.

R solution: 0.1°C.

Ambi nt Op rating T mp ratur : 14 to 158°F (-10 to 70°C).

Storag T mp ratur : -4 to 185°F (-20 to 85°C).

W ight: 6.0 oz (170 g).

Front Pan l Prot ction: NEMA 4X (I 65).

Ag ncy Approval: CE.

Batt ry

To install battery, first gain access to the battery by unscrewing

the cap retaining nut and removing cap from base. To remove

old battery, ease out the positive end of the battery from the

holder, using a screw driver blade. To fit battery, insert battery

negative into the spring contact end of the battery holder, then

press battery into place.

The units monitor their batteries. When the battery approaches

the end of its lifetime (over 2 years under normal conditions), the

display will toggle the message “LO BAT”.

lease observe the battery warning.

Ensure the instrument is installed with adequate protection

against the environment. I 67 rating must be maintained.

Try to avoid installing the equipment close to sources of extreme

temperature and electrical or electromagnetic interference.

Any cleaning of the instrument should be carried out using a mild

detergent and a soft cloth. No solvents or abrasive cleaner

should be used.

BH1

DEC

INC CYC

RTD

Connection

13/16

[20.7]

13/64

[5]

Ø2-5/8

[Ø66.7]

Ø2-7/8

[Ø73]

Fire, Explosion and severe burn hazard, DO NOT

Recharge, Crush, Disassemble, Heat above

100°C (212°F), Incinerate or expose contents to water. NEVER

short circuit the battery. Disposal, the battery may be regulated

by national and local regulations. lease follow the instructions

of the proper regulator.

WARNING

There are three buttons, which the operator must

press in various combinations in order to configure

the device. These buttons are located on the

underside of the indicator’s circuit board. Viewed

from the front, the three buttons (CYCle ,

INCrement and DECrement

) are shown in the diagram

to the left. ressing 2 buttons

simultaneously causes ENTer

or ESCape actions.

©Copy ight 2011 Dwye Inst uments, Inc. P inted in U.S.A. 4/11 FR# R5-443914-00

DWYER INS RUMEN S, INC.

Phone: 219/879-8000 www.dwyer-inst.com

P.O. BOX 373 • MICHIGAN CI Y, INDIANA 46361, U.S.A. Fax: 219/872-9057 e-mail: info@dwyer-inst.com

MAINTENANCE

Apart from battery replacement this equipment requires no user

maintenance. If re-calibration is required please contact your

supplier for further information. Under certain circumstances, it

may be possible to re-calibrate the device while it is still out in an

application.

SERIES BPI/RTD CONFIGURATION MENU GUIDE

Run-Time

then

INC

DEC

CYC

If no buttons are pressed for a minute or more, the

device assumes run-time mode. The display shows

the V (if the input is in range) or shows or

to indicate over/under range. In order to access

menu configuration mode, the user must press

ENTer followed immediately by CYCle . In

order to exit the menu and return to run-time, a user

must press ESCape .

CYCle around menu

When cycling around menu, the

title (e.g. TY E, UNIT, etc.) is

displayed for a second, then the

menu entry is displayed ready for

editing. Then use INC/DEC to

move through entries in a list, or

to edit a real number.

INCrement menu entry

DECrement menu entry

ENTer to confirm entry, or:

CYCle to next menu entry

ESCape

The Series B I Battery owered Temperature Indicator is not

field serviceable and should be returned if repair is needed (field

repair should not be attempted and may void warranty). Be sure

to include a brief description of the problem plus any relevant

application notes. Contact customer service to receive a return

goods authorization number before shipping.
