Panel Meter AP 11

Technical documentation U-19

www.apoelmos.cz

ISO 9001

AP11 - 37 - Counter

A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01

tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz

january 2015, TD-U-19-25

A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01

tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz

1 Introduction .............................................................................................. 5

1.1 Ordering code ........................................................................................ 6

2 Technical data ........................................................................................... 7

3 Panel meter description ............................................................................. 9

3.1 Front panel ........................................................................................... 9

3.2 Dimensions of panel meter and assembly opening ....................................... 10

4 Connection ................................................................................................ 11

4.1 Description of back panel ........................................................................ 11

4.2 Instruction for making installations and connections to panel ...................... 11

4.2.1 Reducing of interference inﬂuence ....................................................................... 11

4.3 Connection to supply voltage. ................................................................... 12

4.3.1 Connection of power supply conductors in terminal board ....................................... 12

4.4 Connection of input signals ..................................................................... 13

4.4.1 Current signal 4 - 20 mA ..................................................................................... 14

4.4.2 Current signal 0/4 - 20 mA .................................................................................. 14

4.4.3 Auxiliary digital inputs ........................................................................................ 14

4.4.4 Pulse signal input (max. 10 kHz) .......................................................................... 15

5 Analogue output ......................................................................................... 16

5.1 Connection of analogue output ................................................................. 16

5.2 Block diagram of analogue output function ................................................. 17

6 Communication .......................................................................................... 18

7 Connection of contact outputs .................................................................... 19

8 Panel meter functions ................................................................................. 20

8.1 Block diagram of counter ....................................................................... 20

8.2 Panel meter switch on ............................................................................. 20

8.3 Panel meter reset ................................................................................... 20

8.4 Display setting ....................................................................................... 21

8.5 Bargraph ............................................................................................... 22

8.6 Functions of limit switch ......................................................................... 23

8.6.1 Functional characteristics of limit switches ............................................................ 24

9 Panel meter menu functions ....................................................................... 26

9.1 Functions of buttons in setting mode ......................................................... 26

9.2 Working mode ........................................................................................ 26

CONTENTS

A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01

tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz

9.3 Conﬁguration mode ................................................................................ 27

9.3.1 Simpliﬁed block diagram of counter menu ........................................................... 27

9.3.2 Conﬁguracetion of pulse input in menu CONF ....................................................... 28

9.3.3 Conﬁguration of limit switches ALA-1 up to ALA-4 ................................................ 29

9.3.4 Conﬁguration of current sensor SENS .................................................................. 30

9.3.5 Conﬁguration of analogue output - DACO ............................................................. 31

9.3.6 Conﬁguration of parameters OSTAT ..................................................................... 32

9.3.7 Conﬁguration bargraph - BARGF ......................................................................... 33

9.3.8 Conﬁguration of diplay - DIS-1, DIS-2 ................................................................. 34

9.3.9 Reset of sum CL-S1, CL-S2 ................................................................................. 35

9.3.10 Reseting thre measured value CL-IN .................................................................... 35

9.4 Limit values of parameters ........................................................................ 36

10 Control software ...................................................................................... 37

11 ES Declaration of conformity .................................................................... 38

12 Certiﬁcate of quality and completness ....................................................... 39

13 Guarantee conditions ............................................................................... 39

CONTENTS

A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01

tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz

AP11-37 Counter is 5 digit programmable panel meter for measuring in time dependent current signal.De-

vice is controlled with digital signal processor with A/D transducer.Counter is operated with key-board pla-

ced on front panel or with control software that is used for setting of all parameters and archiving measu-

red values. Panel meter has tobe provided with communication line, variants of communication lines are in

ordering code. Control software is included in standard delivery. Counter is equipped with three-colour dis-

play allowing for a quick check of limits within measured value oscillates. Visually interesting element is au-

xiliary horizontal bargraph. AP11 Counter inputs are assembled for uniﬁed outputs from sensors of techno-

logical processes

(0/4-20 mA, 0/2-10 V).There is an variant with analogue output that can be galvanic separated in panel me-

ter ordering code.With multi-stage types of panel meters analogue output can be assigned to any input by a

program, eventually to sum. Any of the communication line variants can be used for communication of panel

meter with PC.Communication lines RS232 or RS485 (can be galvanic separated) are in ordering code. Com-

bination of two communication lines RS232 and RS485 can be used for above standard applications. Com-

munication enables not only setting of parameters and data archiving, but regarding the possibility of ad-

dressing of individual panel meters it can be also used for interconnection of bigger number of panel me-

ters and controlling of complete technological lines.

INTRODUCTION

A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01

tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz

This technical documentation refers to the following chart of ordering codes

ﬁg.1

1.1 Ordering code

1INTRODUCTION

AP 11 - XX - X - X - X - X - X - XXX

Input

37 1 x current signal input 0/4 - 20 mA

1 x pulse signal input

Contact output

0empty

12 x relay (switching contacts 250 VAC, 2A)

24 x relay (switching contacts 250 VAC, 2A

Analogue output

0empty

1current/voltage without galvanic separ

2current/voltage with galvanic separ. GS

Communication

0empty

1RS232

3RS485 with GS

6RS485 with GS + RS232

Power supply

180 - 253 VAC

218 - 36 V AC/DC

Display

4three colour

Software

001 Counter

xxx special requirement

AP 11 - 37 - 2 - 2 - 3 - 1 - 4 - 001

Example of order code

A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01

tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz

TECHNICAL DATA

Power supply

Power supply voltage 80 - 253 VAC, 50 Hz

18 - 36 VDC / 18 - 36 VAC, 50 Hz

Consumption max. 12 VA

Display

Display -9999 ~ 0 ~ 99999 (5-digit LED)

Height of digits 14 mm

Decimal point Adjustable with program

Bargraph 30 LED

Resolution According to position of decimal point

Auxiliary power

supply

> 18 VDC @ 25 mA for feeding of sensors

Max. load of auxiliary power supply 40 mA

Outputs

Contact 2x relay (switching contact 250 VAC, 2A or 30 VDC, 2A)

or 4x relay (switching contact 250 VAC, 2A or 30 VDC, 2A)

Analogue 13.5 bit D/A transducer without galvanic separation or with galvanic se-

paration current 0 (4) – 20 mA, loading resistance max. 400 Ω

voltage 0 – 10 V, loading resistance min. 10 kΩ

Communication

RS485 without galvanic separation or with galvanic separation,

two way communication

RS232 without galvanic separation

Input signals, accuracy

Type Input signal meas.range Accuracy of

measurement

(% of sca-

le)

Code

Process 1x current signal (AI) 1x 0/4-20mA ± 0,25% 37

Pulse 1x pulse signal (CI) 0-10KHz 37

Comparator level LOW 3,9 V/2,4 V ± 0,5 V

HIGH 7,5 V/6 V

A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01

tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz

2TECHNICAL DATA

Operating conditions

Working conditions 0 - 60 °C

Temperature coefﬁcient 25 ppm/°C

Stabilizing time Within 5 min after activation

Shielding IP 54 (front panel)

IP 20 (terminal board)

Calibration at 25 °C and 40% relative humidity

Data back-up electrically (EEPROM), bat.CR2032SLF (RAM)

Auxiliary input Voltage free contact, digital inputs

Connection

Connector terminal board

Max. section of condu-

ctor

2.5 mm2 for power supply and contact outputs

1 mm2 for other connectors

Safety class I

Electromagnetic compatibility

ČSN EN 61326

Seismic resistibility

ČSN IEC 980: 1993, čl. 6

Electric safety

ČSN EN 61010-1: 2003

Mechanical properties

Type AP11 panel meter

Dimensions 96 x 48 x 119 mm

Opening in panel 90,5 x 43,5 (openings in corners ø 3 mm with pitch 89,5 x 42,5 mm)

Keyboard 4 keys, foil

Weight 400 g

A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01

tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz

PANEL METER DESCRIPTION

DOWn Set

Ap 11

In Out

3456 7

2 - Input „IN“ indicators

No. of of selected input (functions IN-1,IN-2,SUM1,SUM2 )is indicated with respective indicator. Individual

inputs are selected with keys „UP“ and „DOWN“.

1 - Display

Five-digit display for indication of measured value. With parameter programming display show clear reports.

8 - Output „OUT“ indicators

Indicators OUT 1 to OUT 4 indicates state of individual outputs in the following manner: indicator ﬂashing

– output switched, indicator is not ﬂashing – output is off.

7 - Key „SET“

Key „SET“ is used for setting data, programming termination, data uploading into EEPROM and return to

operating mode.

6 - Key „DOWN“

Key „DOWN“ is used for browsing parameters and setting of numeric data when programming. Pushing and

keeping down of the key speeds up browsing and setting procedure.

5 - Key „UP“

Key „UP“ is used for browsing parameters and setting of numeric data when programming. Pushing and kee-

ping down of the key speeds up browsing and setting procedure.

4 - Key „MENU“

Key „MENU“ is used for entering conﬁguration menu and setting mode.

ﬁg. 2

3 - Bargraph

Bargraph relates to measured value that is determined with pre-set range of STR and END.

E.g. if start of range (STR) is 0 and end (END) 200 and measured value shall be on level 100, bargraph shall in-

dicate half of the scale. Bargraphs is formed with column of LED diodes.

3.1

Front panel

A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01

tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz

3PANEL METER DESCRIPTION

ﬁg. 3a

Dimensions for power supply 80 - 253 VAC, 50 Hz (g. 3a)

Dimensions for power supply 18 - 36 VDC / 18 - 36 VAC, 50 Hz (g. 3b)

ﬁg. 3b

3.2 DIMENSIONS OF Panel meter AND ASSEMBLY OPENING

Front view

Front view Side view

Side view
