ems75vr
Royal Vending Installation and User Guide
THURSDAY, 27 FEBRUARY 2014 PAGE 2 OF 31
EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
Contents
1.0 Installation requirements --------------------------------------------------------------------------------------------------------------------4
1.1 Wiring harness -------------------------------------------------------------------------------------------------------------------------------4
1.2 Ground continuity ---------------------------------------------------------------------------------------------------------------------------4
1.3 Installation kit --------------------------------------------------------------------------------------------------------------------------------4
1.4 Tools required --------------------------------------------------------------------------------------------------------------------------------5
1.5 Before installation ---------------------------------------------------------------------------------------------------------------------------5
2.0 Install the ems75vr -----------------------------------------------------------------------------------------------------------------------------6
2.1 ems75vr installation ------------------------------------------------------------------------------------------------------------------------6
2.2 How to install the ems75vr ----------------------------------------------------------------------------------------------------------------6
2.3 How to connect to the compressor ------------------------------------------------------------------------------------------------------7
2.4 How to connect to the mains supply ----------------------------------------------------------------------------------------------------9
2.5 How to connect to the lights ------------------------------------------------------------------------------------------------------------ 11
3.0 Mount the motion sensor ------------------------------------------------------------------------------------------------------------------ 13
3.1 Motion sensor installation--------------------------------------------------------------------------------------------------------------- 13
3.2 How to mount the motion sensor------------------------------------------------------------------------------------------------------ 13
4.0 Mount the appliance sensor --------------------------------------------------------------------------------------------------------------- 16
4.1 Appliance sensor installation ----------------------------------------------------------------------------------------------------------- 16
4.2 How to mount the appliance sensor -------------------------------------------------------------------------------------------------- 16
5.0 ems75vr wiring diagram -------------------------------------------------------------------------------------------------------------------- 19
5.1 -------------------------------------------------------------------------------------------------------------------------------------------------------- 19
6.0 How to run the test routine---------------------------------------------------------------------------------------------------------------- 20
THURSDAY, 27 FEBRUARY 2014 PAGE 3 OF 31
EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
6.1 Test routine --------------------------------------------------------------------------------------------------------------------------------- 20
7.0 Troubleshooting------------------------------------------------------------------------------------------------------------------------------- 22
7.1 Alarms ---------------------------------------------------------------------------------------------------------------------------------------- 22
7.2 How to troubleshoot appliance sensor (PF1) alarms------------------------------------------------------------------------------ 23
7.3 How to troubleshoot motion sensor alarms----------------------------------------------------------------------------------------- 24
7.4 How to troubleshoot not cooling problems ----------------------------------------------------------------------------------------- 25
8.0 Annex –UL information--------------------------------------------------------------------------------------------------------------------- 26
8.1 Additional information ------------------------------------------------------------------------------------------------------------------- 27
9.0 Parameter set---------------------------------------------------------------------------------------------------------------------------------- 28
For use with the following models:
RVCCR-550, RVCCR-660, RVCCR-780, RVCCR-804, RVCC-550, RVCC-660, RVCC-780, and
RVCC804
THURSDAY, 27 FEBRUARY 2014 PAGE 4 OF 31
EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
1.0 Installation requirements
1.1 Wiring harness
The ems75vr is provided with a wiring harness that is suitable for internal wiring only. The mounting, secureness,
segregation requirements and acceptability of the wiring harness are to be investigated and considered under
the requirements of the ultimate end-use application.
1.2 Ground continuity
The metal bracket used to mount the ems75vr is secured in position using two self-drilling screws. After securing
the bracket into position, ground continuity tests must be performed to ensure that the installation meets local
regulations for grounding of metal parts. If the ground continuity tests fail, a separate ground wire should be
used between the metal bracket and vending machine, and the ground continuity tests repeated.
1.3 Installation kit
The ems75vr installation kit consists of the following:
ems75vr controller mounted on a bracket complete with a remote display, wiring harness, appliance
sensor, and motion sensor (not attached to cable).
No. 4 self-tapping screws (x2) to secure the motion sensor.
No. 8 self-drilling screws (x2) to secure the bracket.
Note: The motion sensor is supplied detached from the cable to facilitate installation.
THURSDAY, 27 FEBRUARY 2014 PAGE 5 OF 31
EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
1.4 Tools required
The following tools are required (not supplied):
Drill driver
5/64”drill bit
1/2” deep well socket
1/4” nut setter
11/32” nut driver
No. 2 Phillips head bit
No. 2 Phillips head screwdriver
Cable ties.
Note: Do not over tighten cable ties.
Note: Cable ties must not be used to secure the sensor head. This will invalidate the warranty.
1.5 Before installation
The vending machine should be checked to ensure that it is in good working order before the ems75vr kit is
installed.
THURSDAY, 27 FEBRUARY 2014 PAGE 6 OF 31
EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
2.0 Install the ems75vr
2.1 ems75vr installation
Mount the bracket fitted with the ems75vr controller and remote display in the base of the vending machine.
Then, connect the ems75vr controller to the mains supply, compressor, and lights.
2.2 How to install the ems75vr
Install the ems75vr as follows:
1. Ensure that the mains supply is switched off.
High voltages, surfaces with high temperatures, and sharp edges are
present within the vending machine.
if you have any doubts, contact your supervisor before starting this
procedure
2. Open the vending machine door and place the ems75vr and bracket in the location shown below.
THURSDAY, 27 FEBRUARY 2014 PAGE 7 OF 31
EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
3. Secure the bracket using the two no.8 self-drilling screws (supplied) as shown below.
2.3 How to connect to the compressor
Connect the ems75vr to the compressor as follows:
1. Identify the mains compressor cable and connector as shown below.
2. Disconnect the compressor plug as shown below.
THURSDAY, 27 FEBRUARY 2014 PAGE 8 OF 31
EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
3. Identify the compressor plug and socket on the wiring harness of the ems75vr as shown below.
4. Unplug compressor plug and connect the ems75vr plug to the compressor socket and the ems75vr
socket to the compressor plug as shown below.
THURSDAY, 27 FEBRUARY 2014 PAGE 9 OF 31
EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
2.4 How to connect to the mains supply
Connect the ems controller to the mains supply as follows:
5. Identify the mains filter as shown below.
6. Cut the insulation of the wiring harness live (red) wire as shown below.
THURSDAY, 27 FEBRUARY 2014 PAGE 10 OF 31
EMS75VR-ROYAL-VENDING-INSTALLATION AND USER GUIDE-ISS3
7. Disconnect the smooth black wire (line) from the filter as shown below.
8. Connect the single red wire of the supplied power jumper to the filter and reconnect the smooth black
wire to the other end of power jumper as shown below.
