Contents and general instructions
IV Festo P.BE-CPX-CTEL-EN en 1205NH
3. Commissioning 3-1................................................
3.1 Description of the operating modes 3-3................................
3.1.1 Manual configuration (tool change mode) 3-3....................
3.1.2 Automatic configuration 3-5..................................
3.1.3 Address assignment in the CPX system 3-8......................
3.2 Procedure for commissioning 3-12.....................................
3.3 Preparing the CTEL system for commissioning 3-13.......................
3.3.1 Check the connected I-port devices 3-13.........................
3.4 Behaviour of the CTEL system with operating malfunctions 3-14.............
3.4.1 Start of the CPX terminal with system setting “Stored parameters” 3-14
3.5 Instructions on operation 3-15.........................................
3.6 Parameters 3-16....................................................
3.6.1 Overview of module parameters 3-16...........................
3.6.2 Parameter “Monitoring VOUT/VVAL”3-18.........................
3.6.3 Parameter “Behaviour after I-port short circuit” 3-19...............
3.6.4 Parameter “I-port configuration” 3-20...........................
3.6.5 Parameter “Device parameter I-port” 3-22.......................
3.7 Commissioning functions with the Handheld 3-23.........................
3.7.1 Menu commands of the CTEL master module on the Handheld 3-24...
3.7.2 Observe signal states (monitoring) 3-25.........................
3.7.3 Parameterisation with the Handheld 3-26........................
3.8 Commissioning functions with the Festo Maintenance Tool (FMT) 3-28........
4. Diagnostics and error handling 4-1...................................
4.1 Summary of diagnostics options 4-3...................................
4.2 Diagnostics/error messages 4-4......................................
4.2.1 Priorities of the diagnostics/error messages 4-4..................
4.2.2 Diagnostics/error messages by CPX error numbers 4-5............
4.3 Diagnostics via LEDs 4-9............................................
4.4 Diagnostics via the CPX fieldbus master 4-10.............................
4.4.1 Status bits of the CPX terminal 4-11.............................
4.4.2 I/O diagnostic interface and diagnostic memory 4-12..............
4.5 Diagnostic functions with the Handheld 4-13.............................
4.6 Diagnostic functions with the Festo Maintenance Tool (FMT) 4-14............
