Foxconn 45CSX Manuale utente
45CSX
Motherboard
User’s Manual
Statement:
This manual is the intellectual property of Foxconn, Inc. Although the information
in this manual may be changed or modied at any time, Foxconn does not obligate
itself to inform the user of these changes.
Trademark:
All trademarks are the property of their respective owners.
Version:
User’s Manual V1.0 for 45CSX motherboard.
Symbol description:
Caution : refers to important information that can help you to use motherboard
better, and tells you how to avoid problems.
Warning : indicating a potential risk of hardware damage or physical injury may
exist.
WEEE:
The use of this symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased this product.
More information:
If you want more information about our products, please visit Foxconn’s
website: http://www.foxconnchannel.com
CAUTION
!
W
A
R
N
I
N
G
!
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
All images are for reference only, please refer to the physical motherboard for specic features.
Declaration of conformity
HON HAI PRECISION INDUSTRY COMPANY LTD
66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,
TAIPEI HSIEN, TAIWAN, R.O.C.
declares that the product
Motherboard 45CSX
is in conformity with
(reference to the specication under which conformity is declared in
accordance with 89/336 EEC-EMC Directive)
■ EN 55022:1998/A2: 2003 Limits and methods of measurements of radio
disturbance characteristics of information technology
equipment
■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits for harmonic current emissions
(equipment input current <= 16A per phase)
■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits of voltage uctuations and icker in low
voltage supply systems for equipment with rated current
<= 16A
■ EN 55024/A2:2003 Information technology equipment-Immunity
characteristics limits and methods of measurement
Signature : Place / Date : TAIPEI/2009
Printed Name : James Liang
Declaration of conformity
Trade Name: FOXCONN
Model Name: 45CSX
Responsible Party: PCE Industry Inc.
Address: 458 E. Lambert Rd.
Fullerton, CA 92835
Telephone: 714-738-8868
Facsimile: 714-738-8838
Equipment Classication: FCC Class B Subassembly
Type of Product: Motherboard
Manufacturer: HON HAI PRECISION INDUSTRY
COMPANY LTD
Address: 66 , CHUNG SHAN RD., TU-CHENG
INDUSTRIAL DISTRICT, TAIPEI HSIEN,
TAIWAN, R.O.C.
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Tested to comply with FCC standards.
Signature : Date : 2009
Installation Precautions
Please carefully read the following procedures to install your computer :
■ It is suggested to select high-quality, certied fans in order to avoid damage
to the motherboard and CPU due to high temperature. Never turn on the
computer if the CPU fan is not properly installed.
■ We cannot guarantee that your system can operate normally when your
CPU/Memory is overclocked. Normal operation depends on the overclocking
capacity of your device.
■ If there is any, when connecting USB, audio, 1394a, RS232 COM, IrDA or
S/PDIF cables to the internal connectors on the motherboard, make sure
their pinouts are matching with the connectors on the motherboard. Incorrect
connections might damage the motherboard.
■ When handling the motherboard, avoid touching any metal leads or connec-
tors.
■ If there is a PCI Express x16 graphics card installed in your system, we
recommend using a 24-pin ATX power supply to get the best performance.
■ Before turning on the power, please make sure the power supply AC input
voltage setting has been congured to the local standard.
■ To prevent damage to the motherboard, do not allow screws to come in contact
with the motherboard circuit or its components. Also, make sure there are no
leftover screws or metal components placed on the motherboard or within the
computer casing.
■ If you are uncertain about any installation steps or have a problem related to
the use of the product, please consult a certied computer technician.
CAUTION
!
■ Electrostatic discharge (ESD) is the sudden and momentary electric current
that ows between two objects at different electrical potentials. Normally it
comes out as a spark which will quickly damage your electronic equipment.
Please wear an electrostatic discharge (ESD) wrist strap when handling
components such as a motherboard, CPU or memory.
■ Ensure that the DC power supply is turned off before installing or removing
CPU, memory, expansion cards or other peripherals. It is recommended to
unplug the AC power cord from the power supply outlet. Failure to unplug
the power supply cord may result in serious damage to your system.
W
A
R
N
I
N
G
!
TABLE OF CONTENTS
Chapter 1 Product Introduction
Product Specications..................................................................2
Layout...........................................................................................4
Back Panel Connectors................................................................ 5
Chapter 2 Hardware Install
Install the Memory ........................................................................8
Install other Internal Connectors ..................................................9
Jumpers......................................................................................12
Chapter 3 BIOS Setup
Enter BIOS Setup....................................................................... 14
Main Menu..................................................................................14
System Information .................................................................... 16
Advanced BIOS Features...........................................................18
Fox Central Control Unit............................................................. 20
Advanced Chipset Features .......................................................23
Integrated Peripherals ................................................................ 26
Power Management Setup......................................................... 29
PC Health Status........................................................................ 31
BIOS Security Features..............................................................32
Load Optimal Defaults................................................................ 33
Save & Exit Setup ......................................................................33
Exit Without Saving ....................................................................33
Chapter 4 CD Instruction
Utility CD content........................................................................35
Install driver and utility................................................................ 36
FOX ONE
Main Page............................................................................. 38
CPU Control.......................................................................... 42
Frequency Control ................................................................ 44
Limit Setting .......................................................................... 45
Voltage Control .....................................................................47
Fan Control ........................................................................... 48
FOX LiveUpdate
Local Update......................................................................... 49
Online Update ....................................................................... 51
Congure .............................................................................54
About & Help......................................................................... 56
FOX LOGO.................................................................................57
FOX DMI .................................................................................... 58
Technical Support :
Website :
http://www.foxconnchannel.com
Support Website :
http://www.foxconnsupport.com
Worldwide online contact Support :
http://www.foxconnchannel.com/support/online.aspx
CPU, Memory, VGA Compatibility Supporting Website :
http://www.foxconnchannel.com/product/Motherboards/compatibility.aspx
Support
Thank you for buying Foxcon 45CSX motherboard. Foxconn products
are engineered to maximize computing power, providing only what
you need for break-through performance.
With a range of connectivity features for today multi-media computing
requirements, 45CSX enables you to unleash more power from your
computer.
This chapter includes the following information:
■ Product Specications
■ Layout
■ Back Panel Connectors
2
1
1-1 Product Specications
CPU Intel®AtomTM 330 processor mounted onboard
Front Side Bus 533 MHz FSB
Chipset North Bridge: Intel® 945GC
South Bridge: Intel® ICH7
Memory 1 x 240-pin DDR2 DIMM socket
Support up to 1GB of system memory
Single channel DDR2 800/667/533MHz architecture
Audio Realtek ALC662 codec
High Denition Audio
2/4/5.1-channel
LAN Realtek RTL8100C chip
Support 10/100Mb/s Ethernet
Expansion Slot 1 x PCI slot
Onboard Serial ATA 2 x SATA connectors
300MB/s data transfer rate
USB Support hot plug
Support up to 6 USB 2.0 ports (4 rear panel ports, 1 onboard USB
headers providing 2 extra ports)
Supports USB 2.0 protocol up to 480Mb/s
Internal Connectors 1 x 24-pin ATX main power connector
2 x SATA connectors
1 x USB 2.0 headers (supporting 2 x USB devices)
1 x Front panel connector
1 x Front audio connector
1 x S/PDIF_OUT connector
1 x TPM connector
1 x IrDA connector
Back Panel 1 x PS/2 keyboard port
Connectors 1 x PS/2 mouse port
1 x Serial port
1 x Parallel port
1 x VGA port
4 x USB 2.0 ports
1 x RJ-45 LAN port
6-channel Audio ports
Hardware Monitor System voltage detection
CPU/System temperature detection
System fan speed detection
CPU overheating shutdown
3
1
Green Function Low power consumption and power management features
Support ACPI (Advanced Conguration and Power Interface)
Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4
(Suspend to disk), and S5 (soft - off)
Operating System Support for Microsoft®Windows® Vista/XP
Form Factor Mini-ITX Form Factor, 170mm x 170mm
Indice
Altri manuali Foxconn Scheda madre
Foxconn
Foxconn H55M-S Manuale utente
Foxconn
Foxconn D250S Manuale utente
Foxconn
Foxconn P35AP-S Series Manuale utente
Foxconn
Foxconn 945GZ7MC Manuale utente
Foxconn
Foxconn Q67M-S Manuale utente
Foxconn
Foxconn 661FX4MR-ES Layout Scheda tecnica
Foxconn
Foxconn P45A Series Manuale utente
Foxconn
Foxconn 945GZ Manuale utente
Foxconn
Foxconn A75M Series Manuale utente
Foxconn
Foxconn 45CTD Istruzioni operative originali
Foxconn
Foxconn P55MX Series Manuale utente
Foxconn
Foxconn P43A Series Manuale utente
Foxconn
Foxconn A6VMX Series Istruzioni operative originali
Foxconn
Foxconn 755FXK8AA series Manuale utente
Foxconn
Foxconn D51S series Manuale utente
Foxconn
Foxconn A7GMX-K Manuale utente
Foxconn
Foxconn H61S Series Manuale utente
Foxconn
Foxconn H55MX-S Series Manuale utente
Foxconn
Foxconn P31A-S Manuale utente
Foxconn
Foxconn G31MX 2.0 Series Manuale utente
Manuali Scheda madre popolari di altre marche
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuale utente
Gigabyte
Gigabyte GA-9IVDT Manuale utente
Texas Instruments
Texas Instruments ADS8372EVM Manuale utente
Commell
Commell MS-C73 Manuale utente
IBT Technologies
IBT Technologies MB860 Manuale utente
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuale utente
