Fujitsu Siemens Computers D1332 Manuale utente

COMPONENT

.com Additional Technical Manual

System Board D1332, D1331, D1330

Are there ...

... any technical problems or other

questions you need clarified?

Please contact:

·Our Hotline:

Mo-Fr: 8 a.m. - 6 p.m.

Sat: 9 a.m. - 2 p.m.

Tel.: ++49 (0) 180 3777 005

·your sales outlet

The latest information on our products, tips, updates, etc., can be found on the Internet

under: http://www.fujitsu-siemens.com/mainboards

Dieses Handbuch wurde auf Recycling-Papier gedruckt.

This manual has been printed on recycled paper.

Ce manuel est imprimé sur du papier recyclé.

Este manual ha sido impreso sobre papel reciclado.

Questo manuale è stato stampato su carta da riciclaggio.

Denna handbok är tryckt på recyclingpapper.

Dit handboek werd op recycling-papier gedrukt.

Herausgegeben von/Published by

Fujitsu Siemens Computers GmbH

Bestell-Nr./Order No.: A26361-D1332-Z180-1-7619

Printed in the Federal Republic of Germany

AG 0102 01/02

A26361-D1332-Z180-1-7619

SYSTEM BOARD D1332,

D1331, D1330

ADDITIONAL TECHNICAL MANUAL

System Board

D1332

D1331

D1330

Additional Technical Manual

January 2002 edition

Intel, Pentium and Celeron are registered trademarks of Intel Corporation, USA.

Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.

PS/2 and OS/2 Warp are registered trademarks of International Business Machines, Inc.

Magic Packet is a registered trademark of Advanced Micro Devices, Inc.

Rambus, RDRAM, and the Rambus Logo are registered trademarks of Rambus Inc. Direct

Rambus, RIMM, SO-RIMM, and Direct RDRAM are trademarks of Rambus Inc.

All other trademarks referenced are trademarks or registered trademarks of their respective

owners, whose protected rights are acknowledged.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

even of parts are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved. Delivery subject to availability.

Right of technical modification reserved.

A26361-D1332-Z180-1-7619

Contents

Introduction........................................................................................................................................1

Features............................................................................................................................................2

Mechanics.........................................................................................................................................3

Connectors........................................................................................................................................5

Power supply monitoring....................................................................................................5

Fan 1 connector.................................................................................................................5

Fan 2 connector.................................................................................................................5

Front panel connector........................................................................................................6

Intrusion connector for case open detect for optional push-button (opener).......................7

USB port C / D 1 - Dual channel ........................................................................................7

Wake On LAN (WOL) connector........................................................................................8

CD-ROM audio connector (internal)...................................................................................8

Audio front panel (internal).................................................................................................8

Auxiliary (MPEG, TV) audio connector (internal)................................................................9

Configuration.............................................................................................................................9

Functions controlled by the configuration switch................................................................9

Power......................................................................................................................................10

Power requirement for onboard components (worst case)...............................................10

Power loadability..............................................................................................................10

Documentation ................................................................................................................................10

Installing drivers...............................................................................................................................11

Upgrading main memory..................................................................................................................11

Troubleshooting...............................................................................................................................11

Message BIOS update.............................................................................................................11

The screen stays blank............................................................................................................11

A26361-D1332-Z180-1-7619 English - 1

Introduction

Depending on the configuration chosen, some of the hardware components described

may not be available on your system board.

You will find further information e. g. in the complete system board Technical Manual and in the

"BIOS Setup" description.

Further information regarding drivers is provided on the supplied drivers diskettes or on the

"Drivers & Utilities" or "ServerStart" CD. For detailed information please read the "Installing drivers"

chapter. The latest BIOS version and drivers can be found on the internet under

http://www.fujitsu-siemens.com/en/service.

!Computer system boards and components contain very delicate IC chips. To protect them

against damage caused by static electricity, you must follow these precautions:

·Use a grounded wrist strap.

·Unplug your computer before you remove any part of the casing.

·Place the system board and the components on a grounded antistatic pad whenever

you remove them from the computer.

Hold components by the edge, do not touch any pins or connectors on them.

Once you have installed the system board, you should remove the battery protection (i.e.

the thin plastic plate between battery and contact spring).

Features

2 - English A26361-D1332-Z180-1-7619

Features

The table shows assembly versions of this system board as an example.

Features D1330-B D1331-A D1332-A

D1332-D

Chipset Intel 845D

Board Size m-ATX m-ATX m-ATX

VGA onboard - - -

Audio onboard (AC '97) üüü

LAN onboard / with Alert-on-LAN - / - ü/ - ü/ ü

Thermal Management onboard - - ü

System Monitoring onboard - - ü

Fujitsu Siemens Keyboard Power Button Support --ü

Buzzer onboard / int. Speaker Support ü/ - ü/ - - / ü

Internal Connectors

DIMM Sockets (DDR) 2 2 2

AGP Slot (1/2/4x, 32 Bit, 66 Mhz, 1.5 V) 1 1 1

PCI Slots (32Bit, 33 MHz, 5 V and 3,3 V) 3 3 D1332-A: 3

D1332-D: 1

ISA Slot - - -

CNR Slot 1 - -

IDE Interfaces (Ultra DMA/100) 2 2 2

Floppy Interface (up to 1,44 MB) 1 1 -

Floppy Interface (up to 1,44 MB) with SMD - - 1

CD / AUX Audio Input 1 / 1 1 / 1 1 / 1

Front Panel Audio Output 1 1 1

Wake-on-LAN 1 1 1

Int. Serial Port / with SmartCard Support - / - - / - -/ -

Int. USB Connectors with SmartCard Support 1 1 1

Int. USB Connectors/shared with CNR 2 / 1 2 / - 2 / -

External Connectors

VGA - - -

Audio Mic. / in / out (2 x 0.5 W / 8 W) 1 / 1 / 1 1 / 1 / 1 1 / 1 / 1

Game/MIDI 1 1 1

LAN (RJ-45) - 1 1

PS/2 Mouse/Keyboard 1 / 1 1 / 1 1 / 1

Ext. Serial Port (FIFO, 16550 compatible) 2 2 2

Parallel Port (EPP/ECP) 1 1 1

USB Connectors external 2 2 2
