Fujitsu D1170 Manuale utente

COMPONENTS

Technisches Handbuch / Technical Manual

Mainboard D1170

Sie haben ...

... technische Fragen oder Probleme?

Wenden Sie sich bitte an:

·Ihren zuständigen Vertriebspartner

·Ihre Verkaufsstelle

Weitere Informationen finden Sie in den Handbüchern "Sicherheit" und "Ergonomie".

Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet:

http://www.fujitsu-siemens.com

Are there ...

... any technical problems or other questions you need clarified?

Please contact:

·your sales partner

·your sales outlet

You will find further information in the manuals "Safety" and "Ergonomics".

The latest information on our products, tips, updates, etc., can be found on the Internet under:

http://www.fujitsu-siemens.com

Dieses Handbuch wurde auf Recycling-Papier gedruckt.

This manual has been printed on recycled paper.

Ce manuel est imprimé sur du papier recyclé.

Este manual ha sido impreso sobre papel reciclado.

Questo manuale è stato stampato su carta da riciclaggio.

Denna handbok är tryckt på recyclingpapper.

Dit handboek werd op recycling-papier gedrukt.

Herausgegeben von/Published by

Fujitsu Siemens Computers GmbH

Bestell-Nr./Order No.: A26361-D1170-Z120-1-7419

Printed in the Federal Republic of Germany

AG 0602 06/02

A26361-D1170-Z120-1-7419

MAINBOARD D1170 TECHNISCHES HANDBUCH

TECHNICAL MANUAL

Mainboard D1170

Technisches Handbuch

Technical Manual

Deutsch

English

Ausgabe Juni 2002

June 2002 edition

Intel, Pentium und Celeron sind eingetragene der Intel Corporation, USA.

Microsoft, MS, MS-DOS und Windows sind eingetragene Warenzeichen der Microsoft

Corporation.

PS/2 und OS/2 Warp sind eingetragene Warenzeichen von International Business Machines,

Inc.

Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen

der jeweiligen Inhaber und werden als geschützt anerkannt.

Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.

Zuwiderhandlungen verpflichten zu Schadenersatz.

Liefermöglichkeiten und technische Änderungen vorbehalten.

Dieses Handbuch wurde erstellt von

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Intel, Pentium and Celeron are registered trademarks of Intel Corporation, USA.

Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.

PS/2 and OS/2 Warp are registered trademarks of International Business Machines, Inc.

All other trademarks referenced are trademarks or registered trademarks of their respective

owners, whose protected rights are acknowledged.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

even of parts are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved. Delivery subject to availability.

Right of technical modification reserved.

This manual was produced by

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

A26361-D1170-Z120-5-7419

Contents

Introduction........................................................................................................................................1

Notational conventions ..............................................................................................................1

Important notes..................................................................................................................................1

Information about boards...........................................................................................................2

Features............................................................................................................................................3

Interfaces and connectors..........................................................................................................5

Hard disk connection.................................................................................................................6

PCI bus interrupts......................................................................................................................7

Screen resolution.......................................................................................................................7

Settings with switches .......................................................................................................................8

Recovering System BIOS - switch 2..........................................................................................9

Write protection for floppy disks - switch 3.................................................................................9

Add-on modules ..............................................................................................................................10

Installing and removing processors..........................................................................................11

Upgrading main memory..........................................................................................................12

Installing network board with WOL...........................................................................................13

Replacing the lithium battery....................................................................................................13

Glossary..........................................................................................................................................14

A26361-D1170-Z120-5-7419 English - 1

Introduction

Depending on the configuration chosen, some of the hardware components described

may not be available on your system board.

You will find further information in the "BIOS Setup" description.

Further information about drivers is provided in the readme files on the hard disk, on the supplied

drivers diskettes, on the "Drivers & Utilities" or on the "ServerStart" CD.

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

!Pay particular attention to text marked with this symbol. Failure to observe this warning

endangers your life, destroys the device, or may lead to loss of data.

Supplementary information, remarks, and tips follow this symbol.

ÊText which follows this symbol describes activities that must be performed in the order shown.

ËThis symbol indicates that you must enter a blank space (press the Space Bar) at this point.

ÚThis symbol indicates that you must press the Enter key.

Text in this typeface indicates screen outputs.

Text in this bold typeface indicates the entries you make via the keyboard.

Text in italics indicates commands or menu items.

"Quotation marks" indicate names of chapters or terms.

Important notes

Store this manual close to the device. If you pass the device on to third parties, you should pass this

manual on with it.

!Be sure to read this page carefully and note the information before you open the device.

You cannot access the system board components without first opening the device. How

to dismantle and reassemble the device is described in the Operating Manual

accompanying the device.

Please observe the safety information provided in the "Important notes" chapter in the

device’s operating manual.

Incorrect replacement of the lithium battery may lead to a risk of explosion. It is therefore

essential to observe the instructions in the "Add-on modules" - "Replacing the lithium

battery" section.

Important notes

2 - English A26361-D1170-Z120-5-7419

The shipped version of this board complies with the requirements of the EEC

directive 89/336/EEC "Electromagnetic compatibility".

Compliance was tested in a typical PC configuration.

When installing the board, refer to the specific installation information in the

Operating Manual or Technical Manual for the receiving device.

Connecting cables for peripherals must be adequately shielded to avoid interference.

!Components can become very hot during operation. Ensure you do not touch

components when making extensions to the system board. There is a danger of burns!

The warranty is invalidated if the device is damaged during the installation or

replacement of system expansions. Information on which system expansions you can

use is available from your sales outlet or the customer service centre.

Information about boards

To prevent damage to the system board or the components and conductors on it, please take great

care when you insert or remove boards. Take great care to ensure that extension boards are slotted

in straight, without damaging components or conductors on the system board, or any other

components, for example EMI spring contacts.

Be especially careful with the locking mechanisms (catches, centring pins etc.) when you replace

the system board or components on it, for example memory modules or processors.

Never use sharp objects (screwdrivers) for leverage.

Boards with electrostatic sensitive devices (ESD) are identifiable by the

label shown.

When you handle boards fitted with ESDs, you must, under all

circumstances, observe the following points:

·You must always discharge static build up (e.g. by touching a

grounded object) before working.

·The equipment and tools you use must be free of static charges.

·Remove the power plug from the mains supply before inserting or

removing boards containing ESDs.

·Always hold boards with ESDs by their edges.

·Never touch pins or conductors on boards fitted with ESDs.
