Fujitsu D2786 Manuale utente

System Board D2786

for RX200 S5

Technical Manual

Edition April 2009

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected]ujitsu.com.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

D2786 (RX200 S5) Technical Manual

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.1 Notes on safety . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.2 CE certificate of conformity . . . . . . . . . . . . . . . . . . 10

2.3 Environmental protection . . . . . . . . . . . . . . . . . . . 11

3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.2 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.3 PCI slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.4 Screen resolution . . . . . . . . . . . . . . . . . . . . . . . 21

3.5 Temperature / system monitoring . . . . . . . . . . . . . . . 22

3.6 Connectors and indicators . . . . . . . . . . . . . . . . . . 23

3.6.1 System board . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3.6.2 Connector panel . . . . . . . . . . . . . . . . . . . . . . . . . 27

3.6.3 Jumpers and switches . . . . . . . . . . . . . . . . . . . . . . 29

4 Replacing the lithium battery . . . . . . . . . . . . . . . . . 33

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

D2786 (RX200 S5) Technical Manual 5

1 Introduction

This technical manual describes the system board D2786, which is equipped

with one or two Intel® processors.

Further information you will find in the "BIOS Setup“.

For additional driver information, refer to the Readme files located on the server

hard disk and on the supplied CDs or DVDs.

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

Text in talics indicates commands or menu items.

Text in fixed

font

indicates system output on the monitor.

Text in semi-bold

fixed font

indicates values to be entered through the keyboard.

[Key symbol] indicates keys according to their representation on the

keyboard.

If capital letters are to be entered explicitly, then the

Shift key is shown, e.g. [SHIFT] - [A] for A.

If two keys need to be pressed at the same time, then

this is shown by placing a hyphen between the two key

symbols.

"Quotation marks" indicate names of chapters and terms that are being

emphasized.

Êdescribes activities that must be performed in the order

shown.

VCAUTION! describes activities that must be performed in the order

shown.

Iindicates additional information, notes and tips.

Table 1: Notational conventions

D2786 (RX200 S5) Technical Manual 7

2 Important notes

In this chapter you will find essential information regarding safety when working

with your server.

VCAUTION!

With the system board installed you must open the system to access the

system board. How to access the system board of your system is

described in the appropriate service supplement.

When handling the system board, refer to the specific notes on safety in

the operating manual and/or service supplement for the respective

server.

2.1 Notes on safety

VCAUTION!

●The actions described in these instructions should only be performed

by authorized, qualified personnel. Equipment repairs should only be

performed by qualified staff. Any failure to observe the guidelines in

this manual, and any unauthorized openings and improper repairs

could expose the user to risks (electric shock, fire hazards) and could

also damage the equipment. Please note that any unauthorized

openings of the device will result in the invalidation of the warranty

and exclusion from all liability.

●Transport the device only in the antistatic original packaging or in

packaging that protects it from knocks and jolts.

●Only install expansions that are allowed for the system board. If you

install other expansions, you may damage the requirements and rules

governing safety and electromagnetic compatibility or your system.

Information on which system expansions are approved for installation

can be obtained from our customer service center or your sales

outlet.

●The warranty expires if the device is damaged during the installation

or replacement of system expansions.

8 Technical Manual D2786 (RX200 S5)

Notes on safety Important notes

VCAUTION!

●Components can become very hot during operation. Ensure you do

not touch components when making extensions to the system board.

There is a danger of burns!

●Transmission lines to peripheral devices must be adequately

shielded.

●To the LAN wiring the requirements apply in accordance with the

standards EN 50173 and EN 50174-1/2. As minimum requirement

the use of a protected LAN line of category 5 for 10/100 Mbit/s

Ethernet, and/or of category 5e for Gigabit Ethernet is considered.

The requirements of the specification ISO/IEC 11801 are to be

considered.

●Never connect or disconnect data transmission lines during a storm

(risk of lightning hazard).

Batteries

VCAUTION!

●Incorrect replacement of lithium battery may lead to a risk of

explosion. The batteries may only be replaced with identical batteries

or with a type recommended by the manufacturer.

It is essential to observe the instructions in the chapter “Replacing the

lithium battery”.

D2786 (RX200 S5) Technical Manual 9

Important notes Notes on safety

Modules with electrostatic-sensitive components

Boards with electrostatic sensitive devices (ESD) are marked with the following

label:

Figure 1: ESD label

When you handle components fitted with ESDs, you must observe the following

points under all circumstances:

●You must always discharge yourself of static charges (e.g. by touching a

grounded object) before touching the components.

●The equipment and tools you use must be free of static charges.

●Shut-down the system and remove the power plug from the power socket

before inserting or removing boards containing ESDs.

●Always hold boards with ESDs by their edges.

●Never touch pins or conductors on boards fitted with ESDs.

●Use a grounding cable designed for this purpose to connect yourself to the

system unit as you install/deinstall the board.

●Place all components on a static-free surface.

IYou will find a detailed description for handling ESD components in the

relevant European or international standards (EN 61340-5-1,

ANSI/ESD S20.20).

10 Technical Manual D2786 (RX200 S5)

CE certificate of conformity Important notes

Notes about boards

●During installation/deinstallation of the board, observe the specific instruc-

tions described in the service supplement for the respective server.

●before you make modifications on an installed board.

●To prevent damage to the board, the components and conductors on it,

please take great care when you insert or remove boards. Take great care

to ensure that extension boards are slotted in straight, without damaging

components or conductors on the board, or any other components, for

example EMI spring contacts.

●Be careful with the locking mechanisms (catches, centring pins etc.) when

you replace the system board or components on it, for example memory

modules or processors.

●Never use sharp objects (screw drivers) for leverage.

2.2 CE certificate of conformity

The board complies with the requirements of the EC directives

2004/108/EC regarding “Electromagnetic Compatibility” and

2006/95/EC “Low Voltage Directive”. This is indicated by the CE

marking (CE = Communauté Européenne).

Compliance was tested in a typical PRIMERGY configuration.
