Fujitsu PRIMERGY Econel 200 S2 Manuale utente

PRIMERGY

PRIMERGY Econel 200 S2

Server

Options Guide

Susanne Däschlein

Fujitsu Siemens Computers GmbH München

81730 Munich

e-mail: email: [email protected]

Tel.: (089) 61001-155

Fax: (++49) 700 / 372 00000

Econel200 S2

Sprachen: En

Edition January 2007

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Fax forms for sending us your comments are included in

the back of the manual.

There you will also find the addresses of the relevant

User Documentation Department.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

Econel200 S2 Options Guide

Contents

1Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Overview of the documentation . . . . . . . . . . . . . . . . . 5

1.2 Expansions and conversions . . . . . . . . . . . . . . . . . . 7

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . 8

2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . 17

4.2 Removing the processor fan 2 . . . . . . . . . . . . . . . . 18

4.3 Removing the system fan . . . . . . . . . . . . . . . . . . . 19

4.4 Removing the memory air duct . . . . . . . . . . . . . . . . 21

4.5 Removing the processor fan 1 . . . . . . . . . . . . . . . . 22

5 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

5.1 Installing a second processor . . . . . . . . . . . . . . . . 25

6 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 29

6.1 Slot population rules . . . . . . . . . . . . . . . . . . . . . 29

6.2 Installing/removing main memory . . . . . . . . . . . . . . 30

7 Accessible drives . . . . . . . . . . . . . . . . . . . . . . . 33

7.1 Installing an accessible drive . . . . . . . . . . . . . . . . . 33

7.2 Installing the 5-inch multibay . . . . . . . . . . . . . . . . . 35

Options Guide Econel200 S2

Contents

8 Hard disk drives . . . . . . . . . . . . . . . . . . . . . . . . 41

8.1 Installing SATA hard disk drives . . . . . . . . . . . . . . . 41

9 Expansion boards in PCI slots . . . . . . . . . . . . . . . . 45

9.1 Installing an expansion board . . . . . . . . . . . . . . . . . 45

10 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

10.1 Installing the processor fan 1 . . . . . . . . . . . . . . . . . 49

10.2 Installing the memory air duct . . . . . . . . . . . . . . . . 50

10.3 Installing the system fan . . . . . . . . . . . . . . . . . . . 51

10.4 Installing the processor fan 2 . . . . . . . . . . . . . . . . . 52

10.5 Closing the server . . . . . . . . . . . . . . . . . . . . . . . 53

11 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

11.1 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Econel200 S2 Options Guide 5

1Introduction

The PRIMERGY Econel 200 S2 server is an Intel-based server for workgroups

and small networks. The server is suitable for use as a file server and also as

an application, information or Internet server.

1.1 Overview of the documentation

IPRIMERGY manuals are available in PDF format on the ServerBooks

DVD which is supplied in the PRIMERGY ServerView Suite package for

every server system.

These PDF files can also be downloaded free of charge from the

Internet: at http://manuals.fujitsu-siemens.com you will find an overview

page with the online documentation available on the Internet. You can go

to the PRIMERGY Server documentation by clicking on industry standard

servers.

Concept and target groups

This Options Guide shows you how you can expand and upgrade the server.

The activities described in this manual may only be performed by technical

specialists.

Additional documentation about the server

The PRIMERGY Econel 200 S2 documentation comprises the following

additional manuals:

– “Safety notes and other important information” (print version delivered

together with the system, PDF file available on the ServerBooks DVD)

– “Warranty” (print version delivered together with the system, PDF file

available on the ServerBooks DVD)

– “Ergonomics” (PDF file available on the ServerBooks DVD)

– “Returning used devices” (PDF file available on the ServerBooks DVD)

– “PRIMERGY Econel 200 S2 Operating Manual” (PDF file available on the

ServerBooks DVD)

– Technical Manual for the system board D2530 (PDF file available on the

ServerBooks DVD)

6 Options Guide Econel200 S2

Overview of the documentation Introduction

– “BIOS Manual” (PDF file available on the ServerBooks DVD)

– “PRIMERGY ServerView Suite” includes the ServerStart Disc 1 and 2, the

ServerBooks DVD, the Software CD and the update CDs for Windows and

Linux. The PDF version of the manual “PRIMERGY ServerView Suite -

ServerStart” is also available on the ServerBooks DVD.

IIf you need a backup of the ServerBooks DVD, send the details of your

server via email address:

[email protected].

– “LSI SATA Software RAID User’s Guide“ (PDF file available on the

ServerBooks DVD)

Further sources of information:

– Manual on the monitor

– Manual on ServerView Server Management

– Manual on RemoteView Remote Server Maintenance

– Documentation on boards and drives

– Documentation on your operating system

– Information files on your operating system

(see also “Related publications” on page 59).

Econel200 S2 Options Guide 7

Introduction Expansions and conversions

1.2 Expansions and conversions

Second processor

The server can be upgraded to a so-called dual processor system. A dual

processor system needs a multi processor operating system. The second

processor must have the same type and clock rate as the first.

Extension of the main memory

The system board supports up to 8 Gbyte main memory. 4 slots (2 banks with

2 modules) are available for the main memory. Each memory bank can be

populated with 512 Mbyte, 1 Gbyte or 2 Gbyte FBD533/PC2-4200F Fully

Buffered DIMM memory modules. You find further information on the main

memory in the Technical Manual for the system board D2530.

Additional accessible drives

Three free 5.25-inch bays are available for additional accessible drives

(DVD-ROM, CD-RW/DVD, DVD-RW or tape backup drive).

The lowest bay can be equipped with a 5-inch multibay. In this multibay a

1.44 MB floppy disk drive and a slimline drive (CD-RW/DVD, DVD-RW) can be

installed.

Hard disk drives

Up to four SATA hard disk drives can be installed. One SATA hard disk drive is

already installed in the base unit.

Expansion boards in the PCI slots

The system board offers:

– 3 x PCI-X (133/100 MHz) slots

– 1 x PCI 33 MHz slot

– 1 x PCI-Express x16 slot (x8 wired)

– 1 x PCI-Express x8 slot (x4 wired)

8 Options Guide Econel200 S2

Notational conventions Introduction

1.3 Notational conventions

The following notational conventions are used in this manual:

text in italics indicate commands, menu items or software programs.

“quotation marks” indicate names of chapters and terms that are being

emphasized.

Êdescribes activities that must be performed in the order

shown

VCAUTION! Pay particular attention to texts marked with this

symbol. Failure to observe this warning may endanger

your life, destroy the system or lead to the loss of data.

Iindicates additional information, notes and tips

Table 1: Notational conventions

Econel200 S2 Options Guide 9

2Procedure

VCAUTION!

The actions described in these instructions should only be performed by

technical specialists. Equipment repairs should only be performed by

service personnel. Any unauthorized opening and improper repairs could

expose the user to risks (electric shock, energy hazards, fire hazards)

and could also damage the equipment. Please note that any unautho-

rized opening of the device will result in the invalidation of the warranty

and exclusion from all liability.

ÊFirst of all please familiarize yourself with the safety instructions in the

chapter “Safety notes” on page 11 et seq. .

ÊEnsure that all required manuals (see “Additional documentation about the

server” on page 5) are available, printing out the PDF files if necessary. You

will definitely need the Operating Manual for the server and the Technical

Manual for the system board.

ÊShut down the server correctly, switch it off, pull out the power plug, and

open the server as described in the chapter “Preparation” on page 17 et

seq. .

ÊExtend or upgrade your server as described in the relevant chapter.

ÊClose the server, connect it to the power outlet, and switch it on as described

in the chapter “Completion” on page 49 et seq. .

ÊStart the operating system and, if necessary, configure it as required (see

Operating Manual).
