Service Supplement - English

PRIMERGY RX600 S6 Server

Service Supplement

August 2011

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to E-

Mail: [email protected]su.com.

Certified documentation

according to DIN EN ISO 9001:2008

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2008.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

– The contents of this manual may be revised without prior notice.

– Fujitsu assumes no liability for damages to third-party copyrights or other rights arising from

the use of any information in this manual.

– No part of this manual may be reproduced in any form without the prior written permission

of Fujitsu.

Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of

Microsoft Corporation in the USA and other countries.

Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries

in the USA and other countries.

RX600 S6 Service Supplement

Before reading this manual

For your safety

This manual contains important information for safely and correctly using this

product.

Carefully read the manual before using this product. Pay particular attention to

the accompanying manual "Safety Notes and Regulations" and ensure these

safety notes are understood before using the product. Keep this manual and the

manual "Safety Notes and Regulations" in a safe place for easy reference while

using this product.

Radio interference

This product is a "Class A" ITE (Information Technology Equipment). In a

domestic environment this product may cause radio interference, in which case

the user may be required to take appropriate measures. VCCI-A

Aluminum electrolytic capacitors

The aluminum electrolytic capacitors used in the product's printed circuit board

assemblies and in the mouse and keyboard are limited-life components. Use of

these components beyond their operating life may result in electrolyte leakage

or depletion, potentially causing emission of foul odor or smoke.

As a guideline, in a normal office environment (25°C) operating life is not

expected to be reached within the maintenance support period (5 years).

However, operating life may be reached more quickly if, for example, the

product is used in a hot environment. The customer shall bear the cost of

replacing replaceable components which have exceeded their operating life.

Note that these are only guidelines, and do not constitute a guarantee of

trouble-free operation during the maintenance support period.

High safety use

This product has been designed and manufactured for general uses such as

general office use, personal use, domestic use and normal industrial use. It has

not been designed or manufactured for uses which demand an extremely high

level of safety and carry a direct and serious risk to life or body if such safety

cannot be ensured.

Service Supplement RX600 S6

These uses include control of nuclear reactions in nuclear power plants,

automatic airplane flight control, air traffic control, traffic control in mass

transport systems, medical devices for life support, and missile guidance

control in weapons systems (hereafter, "high safety use"). Customers should

not use this product for high safety use unless measures are in place for

ensuring the level of safety demanded of such use. Please consult the sales

staff of Fujitsu if intending to use this product for high safety use.

Measures against momentary voltage drop

This product may be affected by a momentary voltage drop in the power supply

caused by lightning. To prevent a momentary voltage drop, use of an AC

uninterruptible power supply is recommended.

(This notice follows the guidelines of Voltage Dip Immunity of Personal

Computer issued by JEITA, the Japan Electronics and Information Technology

Industries Association.)

Technology controlled by the Foreign Exchange and Foreign Trade

Control Law of Japan

Documents produced by Fujitsu may contain technology controlled by the

Foreign Exchange and Foreign Trade Control Law of Japan. Documents which

contain such technology should not be exported from Japan or transferred to

non-residents of Japan without first obtaining authorization in accordance with

the above law.

Harmonic Current Standards

This product conforms to harmonic current standard JIS C 61000-3-2.

Only for the Japanese market: About SATA hard disk drives

The SATA version of this server supports hard disk drives with SATA / BC-SATA

storage interfaces. Please note that the usage and operation conditions differ

depending on the type of hard disk drive used.

Please refer to the following internet address for further information on the

usage and operation conditions of each available type of hard disk drive:

http://primeserver.fujitsu.com/primergy/harddisk/

RX600 S6 Service Supplement

Only for the Japanese market:

IAlthough described in this manual, some sections do not apply to the

Japanese market. These options and routines include:

– CSS (Customer Self Service)

Service Supplement RX600 S6

RX600 S6 Service Supplement

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.1 Concept and target groups . . . . . . . . . . . . . . . . . . . 9

1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 10

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 13

2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 17

4 Replacement routines . . . . . . . . . . . . . . . . . . . . . 21

4.1 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.1.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 21

4.1.2 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 22

4.2 Replacing the local service display . . . . . . . . . . . . . 24

4.3 Replacing the I/O riser card . . . . . . . . . . . . . . . . . . 26

4.4 Replacing the Remote Management Module . . . . . . . . 26

4.5 Replacing the SAS/SATA RAID controller card . . . . . . . 26

4.6 Replacing the front panel fan board . . . . . . . . . . . . . 27

4.7 Replacing the control panel . . . . . . . . . . . . . . . . . . 29

4.8 Replacing the IDTEMP combo . . . . . . . . . . . . . . . . 30

4.9 Replacing the hot-swap backplane (HSBP) . . . . . . . . . 32

4.10 Replacing the optical drive . . . . . . . . . . . . . . . . . . 35

4.11 Replacing the system board . . . . . . . . . . . . . . . . . 38

4.12 Replacing the power distribution board . . . . . . . . . . . 47

4.13 Replacing the TPM . . . . . . . . . . . . . . . . . . . . . . . 48

4.14 Replacing the UFM . . . . . . . . . . . . . . . . . . . . . . . 51

Service Supplement RX600 S6

Contents

5 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

5.1 Board layout . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

5.1.1 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

5.1.2 Hot-swap backplane . . . . . . . . . . . . . . . . . . . . . . . 56

5.1.3 SAS/SATA controller card D2607 . . . . . . . . . . . . . . . . 57

5.1.4 SAS/SATA controller card D2616 . . . . . . . . . . . . . . . . 58

5.1.5 I/O riser card . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

5.1.6 Front panel fan board . . . . . . . . . . . . . . . . . . . . . . 60

5.1.7 Power distribution board . . . . . . . . . . . . . . . . . . . . . 61

RX600 S6 Service Supplement 9

1 Introduction

The scalable PRIMERGY RX600 S6 is an Intel-based rack server for critical

company scenarios, e.g. a database management system for medium or large-

sized databases or as a consolidation basis to run a vast number of different

applications using virtualization technologies.

Thanks to its highly developed hardware and software components, the server

offers a high level of data security and availability. These include hot-plug

HDD/SDD modules, hot-plug system fans, hot-plug power supply units, the

Server Management ServerView Suite, Prefailure Detection and Analysis

(PDA) and Automatic Server Reconfiguration and Restart (ASR&R).

Security functions in the BIOS setup and on the system board protect the data

on the server against manipulation. Additional security is provided by the

lockable rack door.

The server offers a whole host of configuration options but only uses four height

units (HU) in the 19-inch rack.

1.1 Concept and target groups

This Service Supplement completes the information given in the Operating

Manual, the Options Guide and the Technical Manual of the system board.

The activities described in this manual may only be performed by service

personnel.

10 Service Supplement RX600 S6

Introduction

1.2 Documentation overview

Service DVD

Service partners of Fujitsu Technology Solutions can order a Service DVD

PRIMERGY. On the DVD the following manuals are available in pdf format:

– "Safety notes and regulations" manual

– "PRIMERGY RX600 S6 Server Operating Manual"

– "PRIMERGY RX600 S6 Server Options Guide"

– "System Board D3141 for PRIMERGY RX600 S6 Technical Manual"

– "PRIMERGY RX600 S6 Server Service Supplement"

– "System Board D3141 BIOS Setup Utility for PRIMERGY RX600 S6"

manual

Information/procedure Manual

Detailed safety notes "Safety notes and

regulations" manual

Features and technical data of the server Operating Manual

Installation and operation, among other things:

– External connectors

– Operation

– Configuration of the server

– Installation of the rack mounting kit

Troubleshooting

Installation/removal of all CSS components:

– Hot-plug power supply units

– Hot-plug hard HDD/SSD modules

– Hot-plug fans

– Memory boards and modules

– Controllers

– Hot-plug expansion cards

Table 1: Overview of the documentation for PRIMERGY RX600 S6
