Geemarc Ampli1100 Manuale utente
2
DESCRIPTION 3
Introduction 5
Important safety information 5
Connecting the telephone 5
SETTING UP
Ringer settings 6
Tone / Pulse switch 7
Time break recall switch 7
VOLUME AND TONE ADJUSTMENT
Receiving volume and tone 8
Sending volume level adjustment 9
USING THE PHONE
Answering incoming call 10
Making a call 10
Last number redial 10
Recall, * & # buttons 10
Mute button 10
Storing telephone numbers 11
Dialling stored number 11
REGULATORY COMPLIANCE 12
GUARANTEE 14
CONTENTS
3
Tone reception
adjustment
Last number redial
Memory storing key
Mute button
Flashing incoming ring
Direct memory buttons
Volume reception adjust-
ment
Extra volume and tone
activation
Time break recall
button
Phonebook insert card
DESCRIPTION
4
Sending level
switch
Volume & Tone
adjustment ON/OFF
switch
Time break recall
switch
Tone / Pulse
switch
Line cord
socket*
Ringer level
adjustment
switch
Reception Tone
adjustment
Reception volume
adjustment
(*) Classified TNV-3 according to EN60950 standard.
DESCRIPTION
5
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and injury to
persons, including the following:
1. Do not use this product near water, for example, near a bath tub, wash
bowl,kitchen sink or laundry tub, in a wet basement or near a swimming
pool.
2. Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use batteries indicated in this manual. Do not dispose of batteries in a
fire. They may explode. Check with local codes for possible special disposal
instructions.
SAVE THESE INSTRUCTIONS!
1 - CONNECTING THE TELEPHONE
1 - Connect the handset cord.
2 - Open the battery compartment by pulling back the latch.
3 - Insert correctly 4 x AAA 1.5V alkaline batteries (not supplied) in
the battery compartment (*). Batteries are required if you wish to
increase the ringer level up to 10 dB.
4 - Snap the battery door back in place.
5 - Connect the line cord to the socket (*).
(*) Classified TNV-3 according to EN60950 standard.
INTRODUCTION
6
1 - RINGER SETTINGS
A switch located on the upper side allows the ringer to be switched
: Off,
: Low, : Hi
Your phone comes with the ringer switched to «High» and the melody set
to «6»:
Low Middle High
Melody 1 1 2 3
Melody 2 4 5 6 (by default)
Melody 3 7 8 9
If you don’t like the ringer melody, you can choose a new one by changing
the settings as per instructions below:
- Lift the handset.
- Press PROG button.
- Press #button.
- Press any of the 1 - 9 dial keys.
The new ringer settings will be activated with the next incoming call..
Note: The ringer level will be increased up to 10 dB if you insert batteries
into the battery compartment.
SETTINGS
7
2 - TONE/PULSE SWITCH (T/P)
The Tone/Pulse switch is factory pre-set to Tone position (T). In the US,all
telephone exchanges now use Tone dialling.If your phone does not dial out,
it is probably being used from an older private switch- board (PBX). In this
case,theTone/Pulse switch must be moved to Pulse.
3 - TIME BREAK RECALL SWITCH (600/100)
Check the Time Break Recall setting of your Ampli1100. For the US, the
Time Break Recall should be set to 600 mS. It can be switched to 100 mS
for other locations or PBX’s.
SETTING UP
8
1- RECEIVING VOLUME AND TONE ADJUSTMENT
You can adjust the receiving volume and tone according to your own hear-
ing requirements.
The button AMPLIFY allows extra volume and tone functions to be activated
or deactivated during the conversation.
Tone and volume adjustment (15dB to 30dB) is only activated when the
switch located at the rear side of your phone is set to ON. When this
button is set to OFF only the volume can be adjusted from 0dB to 15dB.
When the function is activated, the red light of extra receiving and tone
function button AMPLIFY
is lit.
Note: When the tone (treble), earpiece volume and sending levels
are set to the maximum, whistling may occur. If whistling occurs the
sending level settings should be decreased with the switch
If you are using your Ampli1100 with a hearing aid, set your hearing
aid to “T” position.
VOLUME AND TONE ADJUSTMENT
9
Adjust the TONE and VOLUME buttons to fit the levels to your own hearing
requirements.
2 - SENDING VOLUME LEVEL ADJUSTMENT
If your voice is quiet or called parties have difficulty hearing you, you can
increase the sending level volume with the switch located on the upper
side. You can also decrease the sending volume if required.
Min Normal Maxi
TONE
Bass
+10dB max
Treble
+10dB max
Normal
Volume
+20dB max
Normal
0dB
15dB
15dB
OFF
35dB
ON
VOLUME AND TONE ADJUSTMENT
10
1 - ANSWERING INCOMING CALLS
- When an incoming call is received the phone will ring and the incoming
call indicator will flash. To answer the call lift the handset and speak.
- On completion of the call, carefully replace the handset in the cradle to
release the line.
2 - MAKING A CALL
- Lift the handset.
- Await the dial tone and dial required number.
- On completion of the call, carefully replace the handset in the cradle.
3 - LAST NUMBER REDIAL
- Lift the handset.
- Await the dial tone and press REDIAL button.
- A previously dialled number will be automaticaly redialled (not in use for
memory numbers).
4 - RECALL, * & # BUTTONS
These are used with the new services provided on digital exchanges. For
details please contact your network operator.
5 - MUTE BUTTON
If you wish to speak privately to someone else in the room without your
caller overhearing,press and hold the MUTE button.You will still be able
to hear the callers but they cannot hear you during the mute operation.To
resume normal conversation, release the MUTE button.
USING THE TELEPHONE
