Geemarc AMPLI600 Manuale utente
CONTENTS 2
INTRODUCTION
Unpacking the Ampli600 3
INSTALLATION
Setting Up 4
Wall mount installation 5
DESCRIPTION 6-10
SETTINGS
Ringer Volume 11
Ringer Tones 11
Alarm & Ringer Settings 11
Dialling Mode 12
Date/time format & setting 13
Language Setting 14
Screen Contrast Adjustment 15
Auto On Hook 15
Auto screen Sizing 16
Area & LDS Code Setting 17
USING THE TELEPHONE
Answering a Call 18
Making a Call 18
Switching between Speakerphone
and Handset 19
Call Time Counter 19
Last Number Redial 19
Recalling Recent Numbers 20
Deleting Recent Numbers 20
Mute function 20
Flash 21
One Touch Memory Keys 22
EMERGENCY CONTACT 23
Create Emergency Contact SOS
Numbers 23
Create the Emergency Message 24
Play the Emergency Message 25
Using the Emergency Contact
Telephone 25
Testing the Remote Band 26
Change the Remote Band Battery 26
Cancel and Emergency Contact Call 26
REMOTE MONITORING
Remote Audio Monitoring 26
Activate Remote Audio Monitoring 26
Setttting the Remote Audio
Monitoring Access PIN Code 27
Using Remote Audio Monitoring 27
OPTIONAL ACCESSORIES
Headset 29
Neckloop 29
Shaker 30
VOLUME AND TONE
Sending Level Adjustment 31
Receiving Level Adjustment 31
Handset Amplifier 32
PHONEBOOK
Create a Phonebook Entry 33
Create and Entry from the
Caller Display Log 34
Make a Call from a Phonebook Entry 35
Delete a Phonebook entry 35
Modify a Phonebook Entry 36
CALLER DISPLAY 37
Use a Number from the
Caller Display log 38
Delete a number from the
Caller Display Log 38
Delete all Numbers from the
Caller Display Log 39
Call Waiting 39
NEW CALL/MESSAGE LED 40
Message Waiting LED 40
TROUBLESHOOTING 43
SAFETY INFORMATION 44
REGULATORY COMPLIANCE 45
GUARANTEE 48
2
CONTENTS
3
INTRODUCTION
Congratulations on purchasing your AMPLI600 telephone.
This is a multifunction telephone which offers features such as hands free
use, phonebook and caller display*. It also has the added benefits of send
and receive amplification. There are two emergency features – the first allows
you to call emergency contacts either using a remote band or with one touch
of a button on the base. The other feature is called remote audio monitoring,
this allows your contacts to call and speak to you without the need for you to
pick up the phone. Both feature are very useful in times of emergency.
Its is important that you read the instructions below in order to use your
AMPLI600 to its full potential. Keep this user guide in a safe place for future
reference.
*To use the caller display facility, you must subscribe to your network
provider’s caller display service
CAUTION: This telephone product is specifically designed for people with
hearing difficulties and is provided with a handset earpiece volume control
for individual requirements. Due care must be taken by all users that the
handset earpiece volume control is set to the lowest level acceptable by
each respective user. Care should therefore be exercised to ensure that
any new users are familiar with this requirement.
Unpacking the Ampli600
When unpacking the telephone, you should find the following in the box:
• 1 Telephone base unit
• 1 Telephone handset
• 1 Handset curly cord
• 1 8 inch short telephone line
• 1 6ft telephone line cord
• 1 AC Adapter
• 1 Screwdriver
• 1 Wall plate adapter
• 1 User guide
4
Setting Up
Connect the curly cord and the handset.
Remove the screw of the battery compartment using the screwdriver pro-
vided and open the battery compartment.
Insert 4 good quality alkaline batteries (AAA size, 1.5V type, not supplied)
into the battery compartment located on the base of the telephone.
Note : Do not use rechargeable batteries. Do not put batteries into the
household rubbish, pay attention to battery regulations regarding battery
disposal.
Replace the battery cover.
Desk Installation
Connect the 6ft line cord to the jack located at rear of telephone then con-
nect the plug to the telephone wall socket.
Connect the power supply to the jack located on the back of the telephone
then plug into the wall socket. Please choose a socket near your telephone
socket to enable you to unplug the mains power quickly in case of a prob-
lem.
Lift the handset; if there is a dial tone, the telephone is ready for use. If there
is no dial tone, check that everything is plugged in as described above.
Note: Mains power is required to power the multifunction features of
the telephone. Fit 4 x AAA sized batteries in order to save and use
stored numbers in case of power failure. Without mains or battery
power, the telephone can still be used to answer calls or to manually
dial out calls but all stored numbers will be lost.
INSTALLATION
5
Wall mounting holes
screw
INSTALLATION
Wall Mount Installation
Slide the handset hanger bar out and rotate it 180 degrees. Slide it back
into place. The hook will now point up. This ensures the handset will not fall
out of the cradle when it is mounted on the wall.
Plug the 8in short phone cord into the telephone jack on the AMPLI600, now
run the phone cord under the wall plate adapter and through the opening.
Insert the Wall Plate adapter. Hold it so that the raised mounting pins line
up with the phone’s keyholes on the AMPLI600. Once the holes are lined
up, push the wall plate adapter in towards the AMPLI600 and then slide the
plate upwards until it is securely placed on the phone.
Once the Wall Plate adapter is installed, plug the 8 inch short cord into the
jack on the wall.
Holding the phone slightly above the mounting screws on the wall jack,
push the phone against the mounting screws so they are hooked into upper
and lower key-hole slots on the back of the phone. Slowly slide the phone
down until it snaps into place.
Connect the handset curly cord to the handset and the other end to the
telephone.
Lift the handset, if there is a dial tone, the telephone is ready for use. If there
is no dial tone, check that everything is plugged in as described above.
6
DESCRIPTION
Priority memories
P1,P2,P3
Tone reception
adjustment
Key to activate tone
and volume adjustment
function
Volume
reception adjustment
Direct memories
Memory storing key
Hands free
microphone
Headset button
Time break recall button
Flashing incoming call
indicator (strobe light)
Hands free
dialling & amplifier
Last number redial
Mute button
Message waiting /
newcall LED
Aerial
SOS key stop
SOS key
Stop
SOS
SOS
key
Remote control
Speaker
Speaker volume
adjustment
8
DESCRIPTION
Hours
Minutes Power network icon
Day
Month
Cancel key
Up/down keys
Validation key
Screen example (On hook position)
OK button is used to confirm action or a choice on the
screen.
▲▼“UP / DOWN arrow” buttons are used to high-
light or scroll through the menu.
C button is used to cancel or confirm an action/entry
or clear a stored Caller ID call.
9
DESCRIPTION
Screen display
Your CL600 has a screen with different icons which
help you to use the telephone.
The telephone is supplied by battery +
battery indicator
The telephone is powered by AC adapter.
Memory storing is required.
Screen contrast level.
“Mute” is activated.
Speakerphone is activated.
Precede the CID call record number.
To show new records.
