Geemarc BDP400 Manuale utente
English
BDP400
BDP400 TALKING TELEPHONE
WITH LARGE LCD DISPLAY
1
Caution: This telephone product is specifically
designed for people with hearing difficulties and is
provided with a handset earpiece volume control for
individual requirements. Due care must be taken by
all users that the handset earpiece volume control is
set to the lowest level acceptable by each
respective user. Care should therefore be exercised
to ensure that any new users are familiar with this
requirement.
2
BDP400 Talking telephone with large LCD
display
Please retain these instructions for future reference.
General Description ··················································3
yImportant safety instructions·····································3
Items supplied with the telephone ···························5
Accessories ·······························································5
Orientation ·································································6
Getting started ·························································13
ySetting up ·······························································13
yWall mounting·························································15
Operation··································································16
yMenu navigation ·····················································16
ySettings···································································17
yUsing the telephone················································22
yCaller display ··························································27
yPhone book ····························································32
yQuick-dial································································38
Technical specification ···········································39
Troubleshooting ······················································40
Safety information ···················································42
yGeneral···································································42
yCleaning ·································································42
yEnvironmental·························································43
Regulatory compliance ···········································44
Guarantee·································································47
CONTENTS
3
IMPORTANT SAFETY INSTRUCTIONS
When using your device equipment, basic safety
precautions should always be followed to reduce the risk
of fire, electric shock and injury to persons, including the
following:
1. Do not use this product near water, for example, near a
bath tub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
2. Avoid using a device (other than a cordless type) during
an electrical storm. There may be a remote risk of
electric shock from lightning.
3. Do not use the device to report a gas leak in the vicinity
of the leak.
4. Use only the power cord and batteries indicated in this
manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special
disposal instructions.
SAVE THESE INSTRUCTIONS!
GENERAL DESCRIPTION
4
This is a multi-function telephone developed in
collaboration with Sonic Alert, the leading charity
supporting blind and partially sighted people. The
telephone offers voice announcements throughout, making
it user-friendly, particularly for someone who is blind or
partially sighted. All buttons have been designed to be
easy to identify and locate.
Features include:
•adjustable extra large LCD display is 7cm x 11.7cm in
size with characters 2.3cm high. choose from light
characters on a dark background or dark characters on
a light background
•self-recordable talking phone book with option of storing
up to 50 contacts. When using the recording feature you
can scroll through the phone book and hear the
names/numbers of friends and families stored in your
phone book. When receiving calls the phone will also
announce, if you subscribe to caller ID, the
name/number of the person calling
•extra loud hands free speakerphone with volume setting
•extra loud ringer with an extra bright visual ring indicator
•hearing aid compatible with internal built in loop and
extra boost button which when pressed activates the
built in amplifier allowing the phone to reach high levels
of volume and tone control. This offers compensation for
low or high frequency loss which is the most common
case when it comes to hearing loss
GENERAL DESCRIPTION
5
Items supplied with the telephone
•Telephone
•Handset cord
•Mains adaptor
•Telephone line cord
•Large print instruction guide
•Two screws for wall fixing
ACCESSORIES
As an optional extra you can also purchase a headset and
microphone from Sonic Alert. It is ideally suited for high
background noise environments and handsfree use and is
also hearing aid compatible.
ITEMS / ACCESSORIES
6
Front
With the front of the telephone facing towards you, you will
notice that there is a large LCD display towards the top end
of the telephone. This display is almost the same width as
the telephone and can be moved backwards and forwards
from a horizontal position to a vertical stance of about 90-
degrees. The display can be felt as it is slightly recessed
from the outer case. Towards the top right corner of the
display you will feel a small, raised, circular shape. This is a
red LED light that flashes when a new call has been
received (but only if you have subscribed to the Caller
Display service from your network provider).
The specific details of the LCD display and what is shown is
covered in more detail below, under Orientation: Display.
On the left of the telephone is the handset, and underneath
this is the speaker. Just below the top part of the telephone
cradle is a small hook. This can be rotated either clockwise
or anti-clockwise, and should be turned 180-degrees if
intending to wall mount the telephone. One
part of the hook is flat to touch and this should be used
(facing towards top of telephone) in regular use. The hook
should be rotated so the rounded edge is facing towards top
of the telephone for wall mounting use. This will ensure that
the handset stays in place when wall mounted.
The remaining space on the front of the telephone is
covered by function buttons. Towards the top edge of the
telephone, just below the LCD display, are a series of
buttons in close proximity. This will be referred to as row one.
On the left (at the top) is a round button with the letter C on
it (which is also tactile). This is the "Delete" button. To the
Front ORIENTATION
7
right of this are two triangular-shaped buttons, one facing
upwards and the other, below it, facing downwards. These
are the " /" scroll buttons. To the right of these buttons
is another circular button with the letters OK on it (which is
also tactile). This is the "OK/Confirm" button, which also acts
as the "Call back" button.
Below these buttons is another row (row two), with three
circular-shaped buttons, all with a small recessed mark at
the top of the button. The left button has the letters CID
printed next to it, and this is the "Caller ID" button. The
middle button has the word Menu printed above it, and this
is the "Menu" button. The right button has the letters PB
printed next to it, and this is the "Phone book" button.
Below these three buttons is the number keypad in four
rows of three buttons in the following sequence: 1, 2, 3; 4,
5, 6; 7, 8, 9; Asterisk, 0, hash. (The number five is denoted
by a small tactile dot).
Below the keypad, and towards the bottom edge of the
telephone are four, circular-shaped buttons, each with a
semi-circular recess on one side of the button. They are
from left to right as follows: The left button has a recess on
the right side and has the word Boost below it. This is the
"Boost" button to amplify the volume. The next button has a
recess on the bottom edge and has the word Recall below it.
This is the "Recall" button which is used for
accessing network services, such as double calls, three-
party conference calls and call transfer. The next button has
a recess on the left side and has the word Redial below it.
This is the "Redial" button, and when pressed, this calls the
ORIENTATION Front
8
last number dialled (stored in the memory). The button on
the right of this row has a red LED situated at the top edge
of the button and has the word Headset below it. This is the
"Headset" button, which should be pressed to activate the
telephone when making a call using a headset. The headset
should be plugged into the top edge of the telephone.
The last few buttons on the front of the telephone are
situated on the right towards the edge. Towards the top of
the telephone are three circular-shaped buttons, one above
the other. Above these buttons are the letters Mem, and
these are the three quick-dial memory buttons. The top
button (memory one - M1) has one tactile dot on it, the
middle button (memory two - M2) has two tactile dots on it,
and the bottom of the three buttons (memory three - M3)
has three tactile dots on it. Once a telephone number is
programmed to one of these three buttons it can be dialled
instantly by just pressing the button.
Third Memory key labeled CS with the 3 dots is pre
programmed with the Sonic Alert/ Geemarc customer service
number. For customer service help or technical questions
press this key to dial customer service.
Directly below the third memory button is slightly larger
round button with clock hands and markings at 12, 3, 6 and
9 o'clock positions. This button when pressed will tell you
the time and date.
Below this button is the speaker button, and has a symbol of
a speaker on it " ". It is used when you want to make
hands-free calls. There is a small, red, LED light at the top
of this button.
Front ORIENTATION
9
Back
On the back of the telephone you will feel four round, non-
slip feet in each corner. There are two protruded oval-
shaped parts, one located at the top part on the back of
the telephone, in between the two non-slip feet. The other
part is located about three inches below. Both of these
protruding parts have a round recess. These parts attach
to a screw if affixing the telephone to a wall.
In between the other two non-slip feet on the back of the
telephone is the battery compartment. A small, semi-
circular clip can be felt at the top part of the compartment,
and when this is pulled in towards the compartment, the lid
can be removed away from the telephone to expose the
battery compartment.
On the left side on the back of the telephone is a small
catch, that when pulled away from the telephone, removes
the "Memo card cover" (full details included below under
"right edge orientation").
Front ORIENTATION
ORIENTATION Back
Altri manuali per BDP400
1
Indice
Altri manuali Geemarc Telefono
Geemarc
Geemarc Ampli500 Manuale utente
Geemarc
Geemarc Ampli550 Manuale utente
Geemarc
Geemarc CL1100 Manuale utente
Geemarc
Geemarc PhotoPhone Manuale utente
Geemarc
Geemarc CL10+ Manuale utente
Geemarc
Geemarc Dallas 30 Manuale utente
Geemarc
Geemarc Ampli455 Manuale utente
Geemarc
Geemarc AMPLIDECT 280 Manuale utente
Geemarc
Geemarc Ampli100VM Manuale utente
Geemarc
Geemarc Clear Sound CL455 Manuale utente
Geemarc
Geemarc 250 Manuale utente
Geemarc
Geemarc AMPLIPOWER60+ Manuale utente
Geemarc
Geemarc Madrid Manuale utente
Geemarc
Geemarc Ampli DECT150 Manuale utente
Geemarc
Geemarc combi dect 295 Manuale utente
Geemarc
Geemarc Clearsound CL600 Manuale utente
Geemarc
Geemarc CL1100 Manuale utente
Geemarc
Geemarc AMPLIDECT COMBI 595 Manuale utente
Geemarc
Geemarc Ampli1100 Manuale utente
Geemarc
Geemarc CL8350 Manuale utente
