Geemarc Jupiter 10 Manuale utente
T e l e p h o n e
JUPITER 10JUPITER 10
JUPITER 10JUPITER 10
JUPITER 10
Indexp2
Sommairep3
INDEX
DESCRIPTION 4
SETTING UP
- Installation 6
- Setting time 7
- Setting ringer volume 8
- Tone / Pulse switch (T/P) 8
USING THE PHONE
- Making a call 9
- Receiving a call 9
- Last number redial 9
- R button 10
- Mute button 10
- Storing numbers in memory 10
- Dialling numbers from memory 11
GUARANTEE 12
2
For product support and help visit our website at
www.geemarc.com
telephone 01707 384438
or fax 01707 372529
SOMMAIRE
DESCRIPTION 14
REGLAGES
- Installation 16
- Réglage de l’heure 17
- Réglage du volume de sonnerie 18
- Interrupteur Tone / Pulse (T/P) 18
UTILISATION DU TELEPHONE
- Appeler 19
- Répondre à un appel 19
- Rappel du dernier numéro composé (Touche BIS) 19
- Touche R 20
- Touche secret 20
- Mémoriser un numéro de téléphone 20
- Appel d’un numéro en mémoire 21
GARANTIE 22
3
TEL. SERVICE APRES VENTE :
03 28 58 75 99
Pour tout renseignement technique ou toute
commande visitez notre site web sur
www.geemarc.com.
Parc d’Activités du Basroch
2, rue Galilée
DESCRIPTION
Handset Hook Switch M1 M2 M3 SET
Wall Mounting
Clip
Speaker
R
Button
MUTE
Button
In use LED
STORE Button
4
RD./P
Button
MEM
Button
/P
DESCRIPTION
LINE Socket
(classified TNV-3 according to EN60950 standard)
Desktop
Brackets
Ringer
Volume
Switch
Switch
Tone/Pulse
NOTE: Above brackets are in wall mounting state, if you wish to put
your telephone on the destop,please turn around the brackets on
the desktop state as below:
5
Wall mount holes
1 - INSTALLATION
- Connect the handset cord.
- Connect the telephone line. (Classified TNV-3 according to EN60950 stan-
dard).
- Lift the handset to ensure that you can hear the dial tone. The call timer and
the in use LED will light.
- Replace the handset and the LCD display will show as follows:
Call timer indicate : Minutes Seconds
- The last 2 digits will start counting up.
The LCD display has 3 differents formats:
- Time display : this is the default format.
Hours Minutes Secondes
- Call timer display:
Minutes Secondes
6
00-00
16-45-30
05-18
SETTING UP
- Telephone Number Display : displays the telephone number (upto 10
digits) as the digits are being dialed from the telephone keypad, or from
memory. If the telephone number is more than 10 digits, only the last 10 digits
are displayed.
2 - SETTING TIME
- Lift the handset.
- Press the key, time display will appear and hour digit will flashes
- Press the *key to select the desired number.
- Press the #key to confirm and enter into the minute setting.
- Press the *key to select the desired number.
- Press the #key to select the desired number.
- Replace the handset on the cradle.
- The display will show time and will start counting up after few seconds.
For example as below :
Note: This is also the default display format when the unit is in the
idle state (On hook).
7
0123456789
16-45-30
SETTING UP
SETTING UP
3 - SETTING THE RINGER VOLUME
You can set the desired ringer level by using the ringer Hi / Low switch
located on the base of the unit.
4 - TONE / PULSE SWITCH (T/P)
A switch T/P located under the base allows to set the dialling mode.
The Tone/Pulse switch is factory pre-set to Tone position. In the UK, all
telephone exchanges now use Tone dialing. If your phone does not dial out
it is probably being used from an older private switch board (PBX). In this
case, the Tone/Pulse switch must be moved to Pulse.
8
For product support and help visit our website at
www.geemarc.com
telephone 01707 384438
or fax 01707 372529
USING THE PHONE
1 - MAKING A CALL
- Lift the handset.
The LCD will display the call timer as follows for example and the in use LED
will light:
- Use the dial keypad to dial the number. The digits being dialled will appear
on the LCD display at the same time. For example:
After about 3 seconds the LCD display will switch to the call timer mode.
- The Call Timer will stop when you replace the handset at the end of the call.
The LCD will revert back to the default mode after about 3 seconds.
2 - RECEIVING A CALL
When there is an incoming call, the Jupiter 10 will ring. Lift handset to answer the
call. The Call Timer will start soon after the call is answered and the in use LED
will light.
3 - LAST NUMBER REDIAL
The unit can store for subsequent redial the last number that you called.
- To redial the number, lift the handset.
9
00-18
0123456789
/P
USING THE PHONE
- Press the key once as soon as you hear the dial tone.
The previously dialled number will be automatically redialed.
4 - R BUTTON
These are used with the new services provided on digital exchanges. For
details please contact your network operator.
NOTE: If you don’t use the provided services on digital exchanges, the Rbutton
only cut the line if you press it to dial a new number for example without replace
the handset.
5 - MUTE BUTTON
If you wish to speak privately to someone else in the room without your caller
overhearing press and hold the button. Your caller may still be heard during
the MUTE operation. To resume normal conversation , release the button.
6 - STORING NUMBERS IN MEMORY
The Jupiter 20 can store upto 13 numbers of 20 digits each in the memories.
Of the 13 memories, 3 are direct access by pressing M1, M2, or M3 keys.
It is suggested you store the most frequently used numbers in these memories.
The other 10 memories can be accessed by pressing the MEM key followed by
digits 0 to 9 on the dial keypad.
To store numbers into memory :
- Lift the handset.
- Press the key once.
- Dial in the telephone number you wish to store into memory. The number
10
/P
