Geemarc CL60 Manuale utente

CL60

Amplified Classic Phone

Téléphone Vintage Amplifié

Lautverstärktes Retrotelefon

English1~12

Français13~24

Deutsch25~36

User manual to be read carefully before use!

CAUTION: this telephone is specifically designed for people with

hearing difficulties and is provided with a handset earpiece volume

control for individual requirements. Due care must be taken by all

users that the handset earpiece volume control is set to the lowest

level acceptable by each respective user. Care should therefore be

exercised to ensure that any naive users are familiar with this

requirement.

CONTENTS 2

DESCRIPTION 3

General Description 3

SETTING UP 5

1 - Connecting the telephone 5

2 - Ringer volume setting 5

3 –Ringer Tone / Time Break Recall setting (300/100) 5

4 –Auto Dial Switch 6

5 –Auto On Hook 6

VOLUME AND TONE ADJUSTMENT 7

1 - Receiving volume and tone adjustment 7

2 - Sending volume adjustment 8

USING THE PHONE 9

1 - Answer a call 9

2 - Making a call 9

3 - Last number redial 9

4 - Recall (R), * & # buttons 9

5 - Storing telephone numbers 9

6 - Dialing stored numbers 10

GUARANTEE 11

GENERAL INFORMATION 12

CONTENTS

General Description

7890

STUVWXYZ

Battery low LED

Ringer LED &

AMPLIFY On LED

Auto turn off Switch

Auto Dial SOS

Number Switch

Recall/Ringer Selector

100msec UK/100msec EURO/

300msec EURO

Amplify ON/OFF

slide switch

Ringer Loud/High/

Low/Off Switch

Lock the

Battery Door

4XAA Size

Battery

Compartment

Store Button

DESCRIPTION

Slide Volume

Control

Send Amplify

-3 / 0 / +3dB

Slide Tone

Control

DESCRIPTION

1 - Connecting the telephone

- Connect the handset cord.

- Open the battery door by turning around the locking tab.

Insert 4 alkaline batteries (type AA 1.5V, not supplied) in the

compartment (*). Batteries are required if you wish to

increase the ringer level up to 10 dB and if you wish to use

the “Mechanical Bell” ringer.

Battery door back in place and turn the tab to lock the lid in

place.

- Connect the line cord plug into the line socket into the rear of

the unit (*).

- Connect the other end of the line cord into the wall PTT

socket (*).

2 - Ringer volume setting

A switch located on the right side allows the ringer to be switched to

Hi, Low or Off:

: Off

: Low

: Hi

: LOUD

Note: The ring level will be increased of 10 dB if you insert

batteries.

(*) Classified TNV-3 according to EN60950 standard.

SETTING UP

3 –Ringer Tone / Time Break Recall setting

(300/100)

The phone is equipped with “Mechanical Bell” ringers which can be

selected between UK (tring..tring) & European (triiiiiiiiiiiing) style

bells, via the switch located in the battery compartment.

The mechanical bell sound is functional only when the batteries are

inserted and are not run down.

If there are no batteries or the batteries are “low” the Battery low

indicator flashes and the ringer sound will be the normal two tone

electronic ring.

Your phone works with a time break recall for United Kingdom

(R=100msec). It can be switched to 300msec for other locations or

PBXs. Use the same switch as used to select the Ringer tone, to

select the Recall time

4 –Auto Dial Switch

When this switch is in ON position ( ), upon lifting the handset the

phone will automatically dial out the number stored in the SOS

memory if no other dial button is pressed for 4 seconds. Set this

switch as per your requirement.

5 –Auto On Hook

When this switch is in the On position ( ) , the phone will

automatically go On Hook (disconnect the telephone line) when the

person at the other end disconnects the line, even if the handset is

not replaced on the cradle.

In case the handset is removed from the cradle and there is a phone

call, the phone will still ring as usual. To answer the call, pick up the

handset, press and release the hook button once.

SETTING UP

1 - Receiving volume and tone adjustment

You can increase the volume and adjust the receiving tone

according to your own hearing requirements.

The button (AMPLIFY ON/OFF switch) allows extra receiving

and tone functions to be activated or not during the conversation.

When the function is activated, the red light of extra receiving and

tone function located near the REDIAL/RECALL buttons is lit.

Adjust the TONE and VOLUME buttons to fit the levels to your own

hearing requirements.

VOLUME AND TONE ADJUSTMENT

Note: When the tone (treble), earpiece volume and sending levels

are set to the maximum, whistling may occur. Then the sending

level settings should be decreased with the switch .

When the switch located under the phone is ON ( ), the extra-

receiving and tone functions are automatically activated each time

you use the phone. When this switch is OFF ( ), you will need to

activate the function by switching the button to ON ( ).

Tone and volume (15dB to 30dB) adjustment is only activated when

the button is set to ON ( ). When this button is set to OFF

( ) only the volume can be adjusted from 0dB to 15dB.

2 - Sending volume adjustment

If your voice is quiet or called parties have difficulty hearing you, you

can increase the sending level volume with the switch located on

the hand side. You can also decrease the sending volume if

required.

VOLUME AND TONE ADJUSTMENT

If you are using this telephone with a hearing aid, set your

hearing aid to the T setting.

1 -Answer a call

- When an incoming call is received the phone will ring and

flash, to answer the call lift the handset and speak.

- On completion of the call, carefully replace the handset in the

cradle to release the line. See also section on Auto/Manual

switch

2 - Making a call

- Lift the handset.

- Await the dial tone and dial the required number.

- On completion of the call, carefully replace the handset in the

cradle.

See also section on Auto Dial On/Off switch

3 - Last number redial

- Lift the handset.

- Await the dial tone and press button.

- The previously dialled number will be automatically redialled

(not in use for memory numbers).

Note: If Auto Dial On/Off switch is set to ON position ( ), if the

Last Number Redial Button is not pressed within 4 secs of lifting

the handset, the number stored in SOS memory will

automatically dial out.

4 - Recall (R), * & # buttons

These are used with the new services provided on digital

exchanges. For details please contact your network operator.

USING THE PHONE
