Geemarc Jupiter 20 Manuale utente
Hands-free speaker phone
JUPITER 20JUPITER 20
JUPITER 20JUPITER 20
JUPITER 20
Indexp2
Sommairep3
INDEX
DESCRIPTION 4
SETTING UP
-Installation 6
-Settingtime 7
-Settingringervolume 8
-Tone/Pulseswitch(T/P) 8
-Settingspeakervolume 8
USING THE PHONE
-Makingacall 9
-Receivingacall 9
-Last numberredial 10
-Rbutton 10
-Storingnumbersinmemory 10
-Diallingnumbersfrommemory 11
GUARANTEE 12
2
Forproductsupportandhelpvisitourwebsiteat
www.geemarc.com
telephone 01707 384438
orfax01707372529
SOMMAIRE
DESCRIPTION 14
REGLAGES
-Installation 16
-Réglagedel’heure 17
-Réglageduvolumedesonnerie 18
-InterrupteurTone/Pulse(T/P) 18
-Réglageduvolumeduhaut-parleur 18
UTILISATION DU TELEPHONE
-Appeler 19
-Répondreàunappel 19
-Rappelduderniernuméro composé(ToucheBIS) 20
-ToucheR 20
-Mémoriserunnumérodetéléphone 20
-Appeld’unnuméroenmémoire 21
GARANTIE 23
3
TEL. SERVICE APRES VENTE :
03 28 58 75 99
Pour tout renseignement technique ou toute
commande visitez notre site web sur
www.geemarc.com.
Parcd’ActivitésduBasroch
2, rue Galilée
DESCRIPTION
Handset Hook Switch M1 M2 M3 SET
Wall Mounting
Clip
Speaker
R
Button Button Button MEM
Button
In use LED
STORE Button
4
Microphone
NOTE: When you are in speakerphone mode ( button), you can
speak through the microphone to make or answer a call.
/P
DESCRIPTION
LINE Socket
(classified TNV-3 according to EN60950 standard)
Desktop
Brackets
Ringer
Volume
Switch
Switch
Tone/Pulse
Speaker Volume Switch
NOTE: Above brackets are in wall mounting state, if you wish to put
your telephone on the destop,please turn around the brackets on
the desktop state as below:
5
Wall mount holes
1 - INSTALLATION
-Connectthehandsetcord.
-Connectthetelephoneline.(ClassifiedTNV-3accordingtoEN60950stan-
dard).
-Liftthehandsettoensurethatyoucanhearthedialtone.Thecalltimerand
theinuseLEDwilllight.
-ReplacethehandsetandtheLCDdisplaywillshowasfollows:
Calltimerindicate: Minutes Seconds
-Thelast2digitswillstartcountingup.
TheLCDdisplayhas3differentsformats:
-Timedisplay:thisisthedefaultformat.
Hours Minutes Secondes
-Calltimer display:
Minutes Secondes
6
00-00
16-45-30
05-18
SETTING UP
-TelephoneNumberDisplay:displaysthetelephonenumber(upto10
digits)asthedigitsarebeingdialedfromthetelephonekeypad,orfrom
memory.Ifthetelephonenumberismorethan10digits,onlythelast10digits
aredisplayed.
2 - SETTING TIME
-Liftthehandset.
-Pressthe key,timedisplaywillappearandhourdigitwillflashes
-Pressthe *keytoselectthedesirednumber.
-Pressthe #keytoconfirmandenterintotheminutesetting.
-Pressthe *keytoselectthedesirednumber.
-Pressthe #keytoselectthedesirednumber.
-Replacethehandsetonthecradle.
-Thedisplaywillshowtimeandwillstartcountingupafterfewseconds.
Forexampleasbelow:
Note:This is also thedefault display format whenthe unit is in the
idlestate(Onhook).
7
0123456789
16-45-30
SETTING UP
SETTING UP
3 - SETTING RINGER VOLUME
YoucansetthedesiredringerlevelbyusingtheringerHi/Loswitch
locatedonthebaseoftheunit.
4 - TONE / PULSE SWITCH (T/P)
AswitchT/Plocatedunderthebaseallowstosetthediallingmode.
The Tone/Pulse switch is factory pre-set to Tone position. In the UK, all
telephoneexchangesnowuseTonedialing.Ifyourphonedoesnotdialout
it is probably being used from an older private switch board (PBX). In this
case,theTone/PulseswitchmustbemovedtoPulse.
5 - SETTING SPEAKER VOLUME
Youcansetthedesiredspeakervolume levelbyusingtheringerHi/Lo
switchlocatedonthebaseoftheunit.
8
For product support and help visit our website at
www.geemarc.com
telephone01707384438
orfax01707372529
USING THE PHONE
1-MAKINGACALL
-Pressthe keyonce(Speakerphonemode)orliftthehandset.
TheLCDwilldisplaythecalltimerasfollowsforexampleandtheinuseLED
willlight:
-Usethedialkeypadtodialthenumber.Thedigitsbeingdialledwillappear
ontheLCDdisplayatthesametime.Forexample:
Afterabout3secondstheLCDdisplaywillswitchtothecalltimermode.
-TheCallTimerwillstopwhenyoureplacethehandsetorpressthe key
againattheendofthecall.TheLCDwillrevertbacktothedefaultmodeafter
about3seconds.
Note: If using the handset, you can switch to using the
speakerphone….simplypressthe keyonce,andreplacethehandset.
2-RECEIVINGACALL
Whenthereisanincomingcall,theJupiter20willring.
Liftthehandsetorpress keytoanswerthecall.TheCallTimerwillstart
soonafterthecallisansweredandtheinuseLEDwilllight.
9
00-18
0123456789
USING THE PHONE
3 - LAST NUMBER REDIAL
Theunitcanstoreforsubsequentredialthelastnumberthatyoucalled.
-Toredialthenumber,liftthehandsetorpressthe keyonce.
-Pressthe /P keyonceassoonasyouhearthedialtone.
Thepreviouslydiallednumberwillbeautomaticallyredialed.
4 - R BUTTON
Theseareusedwiththenewservicesprovidedondigitalexchanges.For
detailspleasecontactyournetworkoperator.
NOTE:Ifyoudon’tusetheprovidedservicesondigitalexchanges,theRbutton
onlycutthelineifyoupressittodialanewnumberforexamplewithoutreplace
thehandset.
5 - STORING NUMBERS IN MEMORY
TheJupiter20canstoreupto13numbersof20digitseachinthememories.
Ofthe13memories,3aredirectaccessbypressingM1,M2,orM3keys.
Itissuggestedyoustorethemostfrequentlyusednumbersinthesememories.
Theother10memoriescanbeaccessedbypressingtheMEMkeyfollowedby
digits0to9onthedialkeypad.
Tostorenumbersintomemory:
-Liftthehandsetorpressthe keyonce.
- Press the key once.
-Dialinthetelephonenumberyouwishtostoreintomemory.Thenumber
willappearontheLCDdisplayasyoudialthedigits.
- Press key once again. 10
