Geemarc AMPLI600 Manuale utente

CONTENTS 2

INTRODUCTION

Unpacking the Ampli600 3

INSTALLATION

Setting Up 4

Wall mount installation 5

DESCRIPTION 6-10

SETTINGS

Ringer Volume 11

Ringer Tones 11

Alarm & Ringer Settings 11

Dialling Mode 12

Date/time format & setting 13

Language Setting 14

Screen Contrast Adjustment 15

Auto On Hook 15

Auto screen Sizing 16

Area & LDS Code Setting 17

USING THE TELEPHONE

Answering a Call 18

Making a Call 18

Switching between Speakerphone

and Handset 19

Call Time Counter 19

Last Number Redial 19

Recalling Recent Numbers 20

Deleting Recent Numbers 20

Mute function 20

Flash 21

One Touch Memory Keys 22

EMERGENCY CONTACT 23

Create Emergency Contact SOS

Numbers 23

Create the Emergency Message 24

Play the Emergency Message 25

Using the Emergency Contact

Telephone 25

Testing the Remote Band 26

Change the Remote Band Battery 26

Cancel and Emergency Contact Call 26

REMOTE MONITORING

Remote Audio Monitoring 26

Activate Remote Audio Monitoring 26

Setttting the Remote Audio

Monitoring Access PIN Code 27

Using Remote Audio Monitoring 27

OPTIONAL ACCESSORIES

Headset 29

Neckloop 29

Shaker 30

VOLUME AND TONE

Sending Level Adjustment 31

Receiving Level Adjustment 31

Handset Ampliﬁer 32

PHONEBOOK

Create a Phonebook Entry 33

Create and Entry from the

Caller Display Log 34

Make a Call from a Phonebook Entry 35

Delete a Phonebook entry 35

Modify a Phonebook Entry 36

CALLER DISPLAY 37

Use a Number from the

Caller Display log 38

Delete a number from the

Caller Display Log 38

Delete all Numbers from the

Caller Display Log 39

Call Waiting 39

NEW CALL/MESSAGE LED 40

Message Waiting LED 40

TROUBLESHOOTING 43

SAFETY INFORMATION 44

REGULATORY COMPLIANCE 45

GUARANTEE 48

CONTENTS

INTRODUCTION

Congratulations on purchasing your AMPLI600 telephone.

This is a multifunction telephone which offers features such as hands free

use, phonebook and caller display*. It also has the added beneﬁts of send

and receive ampliﬁcation. There are two emergency features – the ﬁrst allows

you to call emergency contacts either using a remote band or with one touch

of a button on the base. The other feature is called remote audio monitoring,

this allows your contacts to call and speak to you without the need for you to

pick up the phone. Both feature are very useful in times of emergency.

Its is important that you read the instructions below in order to use your

AMPLI600 to its full potential. Keep this user guide in a safe place for future

reference.

*To use the caller display facility, you must subscribe to your network

provider’s caller display service

CAUTION: This telephone product is speciﬁcally designed for people with

hearing difﬁculties and is provided with a handset earpiece volume control

for individual requirements. Due care must be taken by all users that the

handset earpiece volume control is set to the lowest level acceptable by

each respective user. Care should therefore be exercised to ensure that

any new users are familiar with this requirement.

Unpacking the Ampli600

When unpacking the telephone, you should ﬁnd the following in the box:

• 1 Telephone base unit

• 1 Telephone handset

• 1 Handset curly cord

• 1 8 inch short telephone line

• 1 6ft telephone line cord

• 1 AC Adapter

• 1 Screwdriver

• 1 Wall plate adapter

• 1 User guide

Setting Up

Connect the curly cord and the handset.

Remove the screw of the battery compartment using the screwdriver pro-

vided and open the battery compartment.

Insert 4 good quality alkaline batteries (AAA size, 1.5V type, not supplied)

into the battery compartment located on the base of the telephone.

Note : Do not use rechargeable batteries. Do not put batteries into the

household rubbish, pay attention to battery regulations regarding battery

disposal.

Replace the battery cover.

Desk Installation

Connect the 6ft line cord to the jack located at rear of telephone then con-

nect the plug to the telephone wall socket.

Connect the power supply to the jack located on the back of the telephone

then plug into the wall socket. Please choose a socket near your telephone

socket to enable you to unplug the mains power quickly in case of a prob-

lem.

Lift the handset; if there is a dial tone, the telephone is ready for use. If there

is no dial tone, check that everything is plugged in as described above.

Note: Mains power is required to power the multifunction features of

the telephone. Fit 4 x AAA sized batteries in order to save and use

stored numbers in case of power failure. Without mains or battery

power, the telephone can still be used to answer calls or to manually

dial out calls but all stored numbers will be lost.

INSTALLATION

Wall mounting holes

screw

INSTALLATION

Wall Mount Installation

Slide the handset hanger bar out and rotate it 180 degrees. Slide it back

into place. The hook will now point up. This ensures the handset will not fall

out of the cradle when it is mounted on the wall.

Plug the 8in short phone cord into the telephone jack on the AMPLI600, now

run the phone cord under the wall plate adapter and through the opening.

Insert the Wall Plate adapter. Hold it so that the raised mounting pins line

up with the phone’s keyholes on the AMPLI600. Once the holes are lined

up, push the wall plate adapter in towards the AMPLI600 and then slide the

plate upwards until it is securely placed on the phone.

Once the Wall Plate adapter is installed, plug the 8 inch short cord into the

jack on the wall.

Holding the phone slightly above the mounting screws on the wall jack,

push the phone against the mounting screws so they are hooked into upper

and lower key-hole slots on the back of the phone. Slowly slide the phone

down until it snaps into place.

Connect the handset curly cord to the handset and the other end to the

telephone.

Lift the handset, if there is a dial tone, the telephone is ready for use. If there

is no dial tone, check that everything is plugged in as described above.

DESCRIPTION

Priority memories

P1,P2,P3

Tone reception

adjustment

Key to activate tone

and volume adjustment

function

Volume

reception adjustment

Direct memories

Memory storing key

Hands free

microphone

Headset button

Time break recall button

Flashing incoming call

indicator (strobe light)

Hands free

dialling & ampliﬁer

Last number redial

Mute button

Message waiting /

newcall LED

Aerial

SOS key stop

SOS key

Stop

SOS

key

Remote control

Speaker

Speaker volume

adjustment

DESCRIPTION

Hours

Minutes Power network icon

Day

Month

Cancel key

Up/down keys

Validation key

Screen example (On hook position)

OK button is used to conﬁrm action or a choice on the

screen.

▲▼“UP / DOWN arrow” buttons are used to high-

light or scroll through the menu.

C button is used to cancel or conﬁrm an action/entry

or clear a stored Caller ID call.

DESCRIPTION

Screen display

Your CL600 has a screen with different icons which

help you to use the telephone.

The telephone is supplied by battery +

battery indicator

The telephone is powered by AC adapter.

Memory storing is required.

Screen contrast level.

“Mute” is activated.

Speakerphone is activated.

Precede the CID call record number.

To show new records.
