Genie SUPER HOIST Manuale utente
Operator’s Manual Fourth Edition
Second Printing
Part No. 82297
with Maintenance Schedule
GenieSuperHoist PartNo.82297
Fourth Edition • Second PrintingOperator’sManual
Copyright © 1993 by Genie Industries
Fourth Edition: Second Printing, December 2003
"Genie" is a registered trademark of Genie
Industries in the USA and many other countries.
Printed on recycled paper
Printed in U.S.A.
Important
Read,understandandobeythesesafetyrulesand
operatinginstructionsbeforeoperatingthismachine.
Onlytrainedandauthorizedpersonnelshallbe
permitted to operate this machine. If you have any
questions, call Genie Industries.
Contents
Page
Safety Rules .............................................................. 1
Pre-operationInspection ............................................ 4
Function Tests........................................................... 6
WorkplaceInspection................................................. 8
OperatingInstructions................................................ 9
MaintenanceSchedule.............................................. 11
Decals ...................................................................... 12
Specifications ........................................................... 13
Contact us:
Internet:http://www.genielift.com
e-mail:[email protected]
PartNo.82297 GenieSuperHoist 1
Fourth Edition • Second Printing Operator’sManual
Safety Rules
Warning
Failure to obey the instructions and
safety rules in this manual may
result in death or serious injury.
Do Not Operate Unless:
You learn and practice the principles of safe
machineoperationcontainedinthisoperator's
manual.
1 Avoidhazardoussituations.
Knowandunderstandthesafetyrulesbefore
going on to the next section.
2 Alwaysperformapre-operationinspection.
3 Always perform function tests prior to use.
4 Inspect the workplace.
5 Only use the machine as it was intended.
Youread,understandandobeythe
manufacturer'sinstructionsand safety rules—
safetyandoperator'smanualsandmachine
decals.
Youread,understandandobeyemployer's
safety rules and worksite regulations.
Youread,understandandobeyallapplicable
governmentalregulations.
Youareproperlytrainedtosafelyoperate the
machine.
2 GenieSuperHoist PartNo.82297
Fourth Edition • Second PrintingOperator’sManual
Tip-over Hazards
Do not use this machine
to lift people. This
machineisintendedfor
lifting material only.
Do not stand on the
platform.
Do not raise the platform
unless the machine is on
a firm, level surface.
Do not raise the platform unless all four legs are
locked into the down position and each caster
brakehasbeenlocked.
Do not raise the platform unless the load is
centeredandsecuredwith rope or straps.
Do not move the machine while the platform is
raised.
Do not raise the platform in strong or gusty winds.
Increasingtheloadsurface area willdecrease
machine stability in windy conditions.
SAFETY RULES
GH 3.8: Do not exceed rated load capacity of
136 kg / 300 lbs.
GH 5.6: Do not exceed rated load capacity of
113 kg / 250 lbs.
Do not place ladders or scaffolds against any part
of this machine.
Do not use this machine on a moving or mobile
surface or vehicle.
Immediately lower the platform if side deflection or
bowingoccurs.
Electrocution Hazard
This machine is not electrically insulated and will
not provide protection from contact with or
proximity to electrical current.
Do not operate the machine within 10 feet / 3 m of
anyoverheadelectricalcurrent.
Keep away from the machine if it contacts
energizedpowerlinesorbecomeselectrically
charged.
PartNo.82297 GenieSuperHoist 3
Fourth Edition • Second Printing Operator’sManual
SAFETY RULES
Collision Hazards
Do not lower the platform unless the area below is
clearofpersonnel and obstructions.
Do not raise the platform unless the load is
centeredandsecuredwith rope or straps.
Donot standunderorallowpersonnelunderthe
machine when the load is raised.
Inspecttheworkplace to avoid overhead
obstructionsorotherpossiblehazards.
Do not use or raise the platform unless it has been
securely fastened to the mounting plug.
Do not add or remove the load while the platform is
raised. The platform will move if the load is added
orremovedwhileraisingorlowering.
Do not unplug the hose and hand control with a load
on the platform. Be aware of the position of the
hose and hand control and protect it from puncture,
crushingandsevering.
Damaged Machine Hazard
Donotuseadamagedormalfunctioning machine.
Improper Use Hazard
Do not leave the machine unattended. Use of this
machinebyunauthorizedpersonnel couldresultin
deathorseriousinjury.
4 GenieSuperHoist PartNo.82297
Fourth Edition • Second PrintingOperator’sManual
Pre-Operation Inspection
Do Not Operate Unless:
You learn and practice the principles of safe
machineoperationcontainedinthisoperator's
manual.
1 Avoidhazardoussituations.
2 Alwaysperformapre-operation
inspection.
Knowandunderstandthepre-operation
inspection before going on to the next
section.
3 Always perform function tests prior to use.
4 Inspect the workplace.
5 Only use the machine as it was intended.
Fundamentals
Thepre-operationinspection is a visual inspection
performed by the operator prior to each work shift.
This inspection is designed to discover if anything
isapparentlywrongwithamachine before the
operator tests it.
Refer to the list on the next page and check each
of the items.
Ifdamageor anyunauthorizedvariationfrom
factory delivered condition is discovered, the
machinemustbetaggedand removed from
service.
Repairs to the machine may only be made by a
qualified service technician, according to the
manufacturer'sspecifications. Afterrepairsare
completed,the operatormustperformapre-
operationinspection againbeforegoingontothe
function tests.
PartNo.82297 GenieSuperHoist 5
Fourth Edition • Second Printing Operator’sManual
Pre-operation Inspection
oBe sure that the operator’s manual is complete,
legibleandavailableforreference.
oBe sure that all decals are legible and in place.
See Decals section.
Checkthefollowingcomponentsorareasfor
damage,improperlyinstalledor missing parts and
unauthorizedmodifications:
Visually inspect all machine components.
oPlatformandT-nut
oCO2tank, CO2tank bracket and pressure
regulator
oHoseandhandcontrol
oCylinderassembly
oBase, legs, leg locks, leg lock springs and
casters
PRE-OPERATIONINSPECTION
6 GenieSuperHoist PartNo.82297
Fourth Edition • Second PrintingOperator’sManual
Function Tests
If any of the results listed under the following steps
are not observed or any other malfunction is
discovered, the machine must be tagged and
removedfromservice.
Setup
1 Select a firm, level area free of obstructions.
2 Stand the machine up on its base. Release the
leg locks one at a time and lower each leg to
thedownposition.
3 Firmly grasp the cylinder assembly and lift it
enough for each leg to lock into the down
position.
Result: All four leg locks should click into the
locked position.
4 Position the platform over the mounting plug and
fasten it securely with the T-nut.
5 Set the CO2tank bracket next to the CO2tank.
Wrap the straps around the tank and attach the
tank tightly to the bracket. Set the CO2tank
bracket with the tank on any one of the hoist
legs.
Note: Leave the tank on the bracket until it is
necessary to change tanks.
Function Tests
Do Not Operate Unless:
You learn and practice the principles of safe
machineoperationcontainedinthisoperator's
manual.
1 Avoidhazardoussituations.
2 Alwaysperformapre-operation
inspection.
3 Alwaysperformfunctiontests priorto
use.
Knowandunderstandthefunctiontests
before going on to the next section.
4 Inspect the workplace.
5 Only use the machine as it was intended.
Fundamentals
The function tests are designed to discover any
malfunctions before the machine is put into service.
Theoperatormustfollow the step-by-step
instructions to test all machine functions.
A malfunctioning machine must never be used. If
malfunctions are discovered, the machine must be
tagged and removed from service. Repairs to the
machine may only be made by a qualified service
technician,accordingtothemanufacturer's
specifications.
Afterrepairsarecompleted,theoperatormust
performapre-operationinspectionandfunction
tests again before putting the machine into service.
PartNo.82297 GenieSuperHoist 7
Fourth Edition • Second Printing Operator’sManual
PlatformRaiseandLower
9 Lock all four caster brakes.
10 Raise the platform by pressing the up button on
thehandcontrol.
Result: Each tube should extend individually and
smoothly. They should not stick.
11 Lowerthe platform by pressing the down button.
Result: The platform should descend at a
smooth,controlledrate.
12 Raise the platform again and then lower it by
opening the manual dump valve on top of the
handcontrol.
Result: The platform should descend at a
smooth, controlled rate, but more quickly.
Note:Raisingandlowering the platformtwice,
without a load, lubricates the columns.
FUNCTIONTESTS
6 Spinthe pressureregulatorconnectingnutonto
the CO2tank valve stem and hand tighten. It is
not necessary to use a wrench.
Tip-overhazard.Thepressure
regulatoroperatingpressureis
preset for the maximum load
capacity of the machine. Modifying
orusingany otherpressure
regulatororcompressorinexcess
of 600 kPa / 90 psi service could
result in death or serious injury.
UseonlyGenieapproved
replacementparts.
7 Connectthe hose and hand control by inserting
the hose plug end into the coupling on the side
ofthepressureregulator.Connectthehand
control hose to the valve at the base of the
cylinder assembly.
8 Open the CO2tank valve slowly by turning the
handlecounterclockwise.
Componentdamagehazard.Ifthe
CO2tank valve is opened quickly,
thepressureregulatordiaphragm
couldbedamaged.
8 GenieSuperHoist PartNo.82297
Fourth Edition • Second PrintingOperator’sManual
Workplace Inspection
Fundamentals
Theworkplaceinspectionhelpstheoperator
determine if the workplace is suitable for safe
machineoperation.Itshouldbeperformedby the
operator prior to moving the machine to the
workplace.
It is the operator's responsibility to read and
remembertheworkplacehazards,thenwatchfor
and avoid them while moving, setting up and
operatingthemachine.
Do Not Operate Unless:
You learn and practice the principles of safe
machineoperationcontainedinthisoperator's
manual.
1 Avoidhazardoussituations.
2 Alwaysperformapre-operation
inspection.
3 Always perform function tests prior to use.
4 Inspecttheworkplace.
Knowandunderstandtheworkplace
inspection before going on to the next
section.
5 Only use the machine as it was intended.
Workplace Inspection
Beawareof and avoidthefollowinghazardous
situations:
· drop-offsorholes
· bumps,floor obstructions or debris
· slopedsurfaces
· unstableor slippery surfaces
· overheadobstructionsandhighvoltage
conductors
· hazardouslocations
· inadequatesurfacesupport to withstandallload
forces imposed by the machine
· windandweatherconditions
· thepresenceofunauthorizedpersonnel
· otherpossible unsafeconditions
Indice
Altri manuali Genie Sistema di sollevamento
Genie
Genie TMZ-50/30 Manuale utente
Genie
Genie S-40 TRAX Manuale utente
Genie
Genie GS-2669 RT Manuale utente
Genie
Genie Super Tower ST-20 Manuale utente
Genie
Genie GTH-4013 EX Manuale utente
Genie
Genie gS-1530/32 Manuale utente
Genie
Genie SX-180 Manuale di installazione e funzionamento
Genie
Genie SUPERLIFT Contractor SLC-6 Guida rapida
Genie
Genie S-65 Manuale utente
Genie
Genie Z-80/60 Manuale utente
Genie
Genie SX-180 Manuale utente
Genie
Genie Lift Guard GR-15 Manuale utente
Genie
Genie GS-2668 RT Manuale utente
Genie
Genie Runabout GR-8 Manuale utente
Genie
Genie Z-30/20N Manuale utente
Genie
Genie GC-1530 Manuale utente
Genie
Genie Z-45/25 Manuale di installazione e funzionamento
Genie
Genie Lift Tools GS-2669 Manuale utente
Genie
Genie IWP Super Series Manuale utente
Genie
Genie Superlift SL-5 Guida rapida
Manuali Sistema di sollevamento popolari di altre marche
Screen Technics
Screen Technics INTERFIT Vertical Up Lift Manuale utente
Mortuary Lift
Mortuary Lift ULTIMATE 1000 Manuale utente
Custom Equipment
Custom Equipment Hy-Brid 3 Series Manuale di programmazione
Custom Equipment
Custom Equipment Hy-Brid Lifts 2 Series Manuale di programmazione
Hy-Brid Lifts
Hy-Brid Lifts HB-P3.6 Manuale di programmazione
BERG
BERG BeNomic EasyLeaf Manuale utente
