GeoVision GV-BX120D series Manuale utente

User's Manual

GV-IPCam H.264

Before attempting to connect or operate this product,

please read these instructions carefully and save this manual for future use. ICH264TIV30-B

Under the copyright laws, this manual may not be copied, in whole or in

part, without the written consent of GeoVision.

Every effort has been made to ensure that the information in this manual is

accurate. GeoVision, Inc. makes no expressed or implied warranty of any

kind and assumes no responsibility for errors or omissions. No liability is

assumed for incidental or consequential damages arising from the use of

the information or products contained herein. Features and specifications

are subject to change without notice. Note: no memory card slot or local

storage function for Argentina.

GeoVision, Inc.

9F, No. 246, Sec. 1, Neihu Rd.,

Neihu District, Taipei, Taiwan

Tel: +886-2-8797-8377

Fax: +886-2-8797-8335

http://www.geovision.com.tw

Trademarks used in this manual: GeoVision, the GeoVision logo and GV

series products are trademarks of GeoVision, Inc. Windows and Windows

XP are registered trademarks of Microsoft Corporation.

February 2015

Safety Notice

UL Certification for GV-MFD120 / 130 / 320

The GV-IPCAM H.264 uses a 3.0V CR2032 Lithium battery as the

power supply for its internal real-time clock (RTC). The battery should

not be replaced unless required!

If the battery does need replacing, please observe the following:

•Danger of Explosion if battery is incorrectly replaced

•Replace only with the same or equivalent battery, as

recommended by the manufacturer

•Dispose of used batteries according to the manufacturer's

instructions

Preface

Welcome to the GV-IPCAM H.264 User’s Manual.

The GV-IPCAM H.264 has a series of models designed to meet different

needs. This Manual is designed for the following models and firmware

versions:

Note:

1. To upgrade the camera firmware from V2.07 or earlier to the latest

version, back up the files in the camera’s storage device first

before the upgrade and it is required to re-format the memory card

after the upgrade.

2. The following models are not supported by firmware V3.0:

 BX120D / 130D / 140DW / 220D / 320D / 520D

 CB120 / 220

 Models installed with a 32 MB NAND flash

Model Model Number Firmware

Version

Box Camera

GV-BX120D

GV-BX140DW Varifocal Lens

V2.15

GV-BX130D-0 Varifocal Lens

V2.14

GV-BX130D-1 Fixed Lens

GV-BX220D-2

GV-BX220D-3

Varifocal Lens

GV-BX320D-0

GV-BX320D-1

GV-BX520D

Model Model Number Firmware

Version

GV-BX1200-0F ~ 2F

GV-BX1300-0F ~ 2F

GV-BX1500-0F ~ 2F

GV-BX2400-0F ~ 2F

GV-BX2500-0F ~ 2F

GV-BX3400-0F ~ 2F

Fixed Lens

GV-BX1200-3V

GV-BX1300-3V

GV-BX1500-3V

GV-BX2400-3V

GV-BX2500-3V

GV-BX2400-4V

GV-BX3400-4V

GV-BX3400-5V

GV-BX5300-6V

Varifocal Lens

Box Camera

GV-BX1500-8F

GV-BX2400-8F

GV-BX2500-8F

GV-BX3400-8F

GV-BX5300-8F

Fixed Lens

V3.0

Ultra Box

Camera

GV-UBX1301 Series

GV-UBX2301 Series

GV-UBX3301 Series

Fixed Lens V3.0

III

Model Model Number Firmware

Version

Target Box

Camera GV-EBX1100 Series Fixed Lens V1.03

GV-BX120D-E V2.15

GV-BX220D-E

GV-BX320D-E

GV-BX520D-E

V2.14

GV-BX1500-E

GV-BX2400-E

GV-BX3400-E

GV-BX5300-E

Varifocal Lens

IR Arctic Box

Camera

GV-BX2510-E

GV-BX5310-E

Motorized

Varifocal Lens

V3.0

GV-MFD120

GV-MFD130

GV-MFD320

Mini Fixed

Dome

GV-MFD1501 Series

GV-MFD2401 Series

GV-MFD2501 Series

GV-MFD3401 Series

GV-MFD5301 Series

Fixed Lens V3.0

Model Model Number Firmware

Version

Mini Fixed

Rugged Dome

GV-MDR220

GV-MDR320

GV-MDR520

GV-MDR1500 Series

GV-MDR3400 Series

GV-MDR5300 Series

Fixed Lens V3.0

Target Mini

Fixed Dome

GV-EFD1100 Series

GV-EFD2100 Series Fixed Lens V1.03

Target Mini

Fixed Rugged

Dome

GV-EDR1100 Series

GV-EDR2100 Series Fixed Lens V1.03

Target Bullet

Camera

GV-EBL1100-1F

GV-EBL1100-2F

GV-EBL2100-1F

GV-EBL2100-2F

Fixed Lens V1.03

GV-UBL1211

GV-UBL2411

GV-UBL3411

V3.0

GV-UBL1511

GV-UBL2511

Motorized

Varifocal Lens

Coming

Ultra Bullet

Camera

GV-UBL1301 Series

GV-UBL2401 Series

GV-UBL3401 Series

Fixed Lens V3.0

Model Model Number Firmware

Version

GV-BL120D

GV-BL130D

GV-BL220D

GV-BL320D

GV-BL1500

GV-BL2400

GV-BL2500

GV-BL3400

Varifocal Lens

GV-BL1210

GV-BL2410

GV-BL3410

GV-BL5310

GV-BL1510

V3.0

Bullet Camera

GV-BL2510

Motorized Varifocal

Lens

Coming

IR Arctic Bullet

Camera

GV-BL2510-E

GV-BL5310-E

Motorized Varifocal

Lens, extreme

temperature

tolerance

V3.0

NTSC

PTZ Camera GV-PTZ010D

PAL

V1.09

PT Camera

GV-PT130D

GV-PT220D

GV-PT320D

Fixed Lens V3.0

Model Model Number Firmware

Version

GV-VD120D

(IK10+, Transparent Cover)

GV-VD121D

(IK10+, Smoked Cover)

GV-VD122D

(IK7, Transparent Cover)

GV-VD123D

(IK7, Smoked Cover)

GV-VD220D

(IK10+, Transparent Cover)

GV-VD221D

(IK10+, Smoked Cover)

GV-VD222D

(IK7, Transparent Cover)

GV-VD223D

(IK7, Smoked Cover)

GV-VD320D

(IK10+, Transparent Cover)

GV-VD321D

(IK10+, Smoked Cover)

GV-VD322D

(IK7, Transparent Cover)

GV-VD323D

(IK7, Smoked Cover)

Vandal Proof

IP Dome

GV-VD1500

GV-VD2400

GV-VD2500

GV-VD3400

Varifocal Lens V3.0

VII

Model Model Number Firmware

Version

GV-VD1530

GV-VD2430

GV-VD2530

GV-VD3430

Varifocal Lens,

high power IR

LEDs

Vandal Proof

IP Dome GV-VD1540

GV-VD2440

GV-VD2540

GV-VD3440

GV-VD5340

Motorized

Varifocal Lens,

high power IR

LEDs

IR Arctic

Vandal Proof

IP Dome

GV-VD2540-E

GV-VD5340-E

Motorized

Varifocal Lens,

high power IR

LEDs, extreme

temperatures

V3.0

Advanced

Cube

Camera

GV-CA120

GV-CA220

GV-CAW120

GV-CAW220

Fixed Lens V3.0

Cube Camera GV-CB120

GV-CB220 Fixed Lens V2.14

VIII
