Hach FilterTrak 660 Manuale utente

52364-89

FilterTrak™ 660 Calibration Kit

General Information

The Calibration Kit, shown in Figure 1, is shipped with the calibration body (stand mounted),

a 1-liter bottle of 800 mNTU StablCal®Standard, and a funnel to reduce bubbles when

pouring the standard. The 800 mNTU StablCal Standard is assayed and the value is

reported on the label to the nearest 1 mNTU. The tolerance of the standard is ±50 mNTU.

Figure 1 Calibration Kit Components

Calibration Procedure

1. Remove the cover.

2. Rinse the calibration body with deionized water.

3. Drain all deionized water from the body and replace the drain plug.

4. Clean the FilterTrak 660 Nephelometer head assembly as described in the FilterTrak

660 Laser Nephelometer Instrument Manual (Cat. No. 52300-18).

5. Gently invert the StablCal Standard bottle 50 times to mix. Each inversion should last

1-3 seconds. Do not shake the standard.

6. Place the funnel into the end of the bubble trap, opposite the water intake. See Figure 2.

7. Slowly pour the standard into the funnel.

8. Install the FilterTrak 660 head assembly on the calibration body. See Figure 3.Allowthe

standard to sit undisturbed in the body for approximately 10–20 minutes before

proceeding with the calibration.

9. Calibrate using the instructions in the FilterTrak 660 Laser Nephelometer

Instrument Manual.

Calibration Body

Funnel

800 mNTU StablCal

1-liter Bottle

FilterTrak™ 660 Calibration Kit

HACH COMPANY

WORLD HEADQUARTERS

Telephone: (970) 669-3050

FAX: (970) 669-2932

FORTECHNICAL ASSISTANCE, PRICE INFORMATION AND ORDERING:

Call 800-227-4224

Contact the HACH office or distributor serving you.

www.hach.com [email protected]

In the U.S.A.–

Outside the U.S.A.–

On the Worldwide Web –; E-mail –

toll-free

10. When the calibration is complete, drain the calibration body. The standard cannot be

stored for future use.

11. Remove the head assembly and carefully rinse the head assembly and calibration body.

Immediately reinstall the head assembly back on the FilterTrak 660 body.

12. Store the calibration body with the cover securely in place.

Figure 2 Pouring the StablCal Standard

Figure 3 Calibration Body with FilterTrak 660 Head Assembly in Place

Place the funnel into the body.

Slowly pour the StableCal

Standard into the funnel

Drain

CONFIGURE

STATUS

POWER

REMOTE

Laser Turbidimeter

FilterTrak 660

™

FilterTrak 660

™
