Hanna Instruments HI 96107 Manuale utente

pHep®

HI96107

Pocket-Sized

pHMeter

www.hannainst.com

SPECIFICATIONS

Range 0.0 to 14.0 pH

Resolution 0.1 pH

Accuracy (@20°C) ±0.1 pH

Calibration manual, 1 point

Environment RH 95% max;

0 to 50°C (32 to 122°F)

Batteries 3 x 1.5V alkaline

Life approx. 150 hours of use

Dimensions 150x30x21 mm

(5.9x1.2x0.8")

Weight 70 g (2.5 oz.)

ACCESSORIES

HI 70007P pH 7.01 solution (20 ml

sachet, 25 pcs)

HI 7007L pH 7.01 solution (500 ml)

HI 7007M pH 7.01 solution (230 ml)

HI 70300L Storage solution (500 ml)

HI 70300M Storage solution (230 ml)

Dear Customer,

Thank you for choosing a Hanna product.

If you need additional technical informa-

tion, do not hesitate to e-mail us at

[email protected].

This instrument is in compliance with the

directives.

WARRANTY

This meter is guaranteed for six months against de-

fects in workmanship and materials when used for

its intended purpose and maintained according to in-

structions. This warranty is limited to repair or

replacement free of charge. Damages due to acci-

dent, misuse, tampering or lack of prescribed

maintenance are not covered. If service is required,

contact the dealer from whom you purchased the in-

strument. If under warranty, report the model number,

date of purchase, serial number and the nature of the

failure. If the repair is not covered by the warranty,

you will be notified of the charges incurred. If the

instrument is to be returned to Hanna Instruments,

first obtain a Returned Goods Authorization Number

fromtheCustomerServicedepartmentandthensend

it with shipment costs prepaid. When shipping any

instrument,makesureitisproperlypackagedforcom-

pleteprotection. IST96107 12/04

OPERATION

• Remove the protective cap. Do

not be alarmed if white crystals

appear around the cap. This is

normal with pH electrodes and

they dissolve when rinsed with

water.

• Turn the meter on sliding the

switch on the top.

• Immerse into solution up to

the max immersion level.

• Stir gently and wait until the

display stabilizes.

• After use, rinse the electrode

with water to minimize con-

tamination and store it with a

few drops of storage (HI70300)

or pH 7 (HI 7007) solution in

the protective cap.

DO NOT USE DISTILLED OR DEIONIZED

WATER FOR STORAGE PURPOSES.

• Large fluctuations in readings could be due

to lack of calibration, dry electrode or run-

down batteries.

Recommendations for users

Before using this product, make sure that it is entirely

suitable for the environment in which it is used. Operation

of this instrument in residential areas could cause

interference to radio and TV equipment. The glass bulb

at the end of the pH electrode is sensitive to electrostatic

discharge. Avoid touching this glass bulb at all times. Any

variation introduced by the user to the supplied equipment

may degrade the instrument's EMC performance. To avoid

electrical shock, do not use this instrument when voltages

at the measurement surface exceed 24 Vac or 60 Vdc.

To avoid damage or burns, do not perform any

measurement in microwave ovens.

CALIBRATION

• Immerse the tester up to the

maximum immersion level

in pH 7 buffer (HI 7007)

• Allow the reading to stabi-

lize and using a small

screwdriver adjust the cali-

bration trimmer to read 7.0.

Calibration is now complete.

ALWAYSUSEFRESHBUFFERSFORCALIBRATION.

BATTERY REPLACEMENT

When the meter cannot be

switched on or the display

fades, pull out the battery

compartment and replace all

three 1.5V batteries, while

paying attention to their po-

larity.

Batteries should only be re-

placed in a safe area using

the battery type specified in

this instruction manual.

pHep is a registered Trademark of

"Hanna Instruments"
