Installing Your PCI Modem 5
7Connect the telephone cord: Plug one
end of the phone cord into the jack
marked LINE. Plug the other end into a
phone jack (typically the wall jack where
you would normally connect a phone).
Plug your phone into the PHONE jack if
you want to use a phone on the same
line.
LINE
LINE
PHONE (optional)
PHONE
8Plug in your computer and turn it on.
9Windows 95/98/Me Users: As Windows starts up, it de-
tects your new modem. Because the installation program
has already provided your computer with the required
files, you will see Windows reporting on its progress, but
no action is required on your part. Continue with
Completing the Installation.
Windows 2000 Users: A few seconds after startup, you
may see the Digital Signature Not Found dialog box.
You can safely ignore this message and click Yes. Con-
tinue with Completing the Installation.
Windows XP Users: When the Found New Hardware
Wizard dialog box appears, click Next. A standard dis-
claimer dialog box appears if your modem has not yet
been tested by Microsoft’s Windows Hardware Quality
Labs (WHQL). There is no cause for concern about the
stability of your modem or your PC. You can safely disre-
gard this box and click Continue Anyway. Then click
Finish. Continue with Completing the Installation.
Completing the Installation
Perform the following steps to complete the installation:
1Open the Control Panel (and, in Windows XP only, click
Printers and Other Hardware). Then double-click the
Modems or Phone and Modem Options icon.
